6KVD

Crystal structure of human nucleosome containing H2A.J


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.21 Å
  • R-Value Free: 0.257
  • R-Value Work: 0.213
  • R-Value Observed: 0.215

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


This is version 1.2 of the entry. See complete history


Literature

Biochemical and structural analyses of the nucleosome containing human histone H2A.J.

Tanaka, H.Sato, S.Koyama, M.Kujirai, T.Kurumizaka, H.

(2020) J Biochem 167: 419-427

  • DOI: https://doi.org/10.1093/jb/mvz109
  • Primary Citation of Related Structures:
    6KVD

  • PubMed Abstract:

    Histone H2A.J, a histone H2A variant conserved in mammals, may function in the expression of genes related to inflammation and cell proliferation. In the present study, we purified the human histone H2A.J variant and found that H2A.J is efficiently incorporated into the nucleosome in vitro. H2A.J formed the stable nucleosome, which accommodated the DNA ends. Mutations in the H2A.J-specific residues did not affect the nucleosome stability, although the mutation of the H2A.J Ala40 residue, which is conserved in some members of the canonical H2A class, reduced the nucleosome stability. Consistently, the crystal structure of the H2A.J nucleosome revealed that the H2A.J-specific residues, including the Ala40 residue, did not affect the nucleosome structure. These results provide basic information for understanding the function of the H2A.J nucleosome.


  • Organizational Affiliation

    Laboratory of Chromatin Structure and Function, Institute for Quantitative Biosciences, The University of Tokyo, 1-1-1 Yayoi, Bunkyo-ku, Tokyo 113-0032, Japan.


Macromolecules

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
Histone H3.1C [auth A],
G [auth E]
139Homo sapiensMutation(s): 0
Gene Names:
UniProt & NIH Common Fund Data Resources
Find proteins for P68431 (Homo sapiens)
Explore P68431
Go to UniProtKB:  P68431
PHAROS:  P68431
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP68431
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChains Sequence LengthOrganismDetailsImage
Histone H4D [auth B],
H [auth F]
106Homo sapiensMutation(s): 0
Gene Names:
UniProt & NIH Common Fund Data Resources
Find proteins for P62805 (Homo sapiens)
Explore P62805
Go to UniProtKB:  P62805
PHAROS:  P62805
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP62805
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 4
MoleculeChains Sequence LengthOrganismDetailsImage
Histone H2A.JE [auth C],
I [auth G]
132Homo sapiensMutation(s): 0
Gene Names: H2AFJ
UniProt & NIH Common Fund Data Resources
Find proteins for Q9BTM1 (Homo sapiens)
Explore Q9BTM1
Go to UniProtKB:  Q9BTM1
PHAROS:  Q9BTM1
GTEx:  ENSG00000246705
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9BTM1
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 5
MoleculeChains Sequence LengthOrganismDetailsImage
Histone H2B type 1-JF [auth D],
J [auth H]
129Homo sapiensMutation(s): 0
Gene Names: HIST1H2BJH2BFR
UniProt & NIH Common Fund Data Resources
Find proteins for P06899 (Homo sapiens)
Explore P06899
Go to UniProtKB:  P06899
PHAROS:  P06899
GTEx:  ENSG00000124635
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP06899
Sequence Annotations
Expand
  • Reference Sequence
Find similar nucleic acids by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains LengthOrganismImage
DNA (146-MER)A [auth I],
B [auth J]
146Homo sapiens
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 2 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
MN (Subject of Investigation/LOI)
Query on MN

Download Ideal Coordinates CCD File
K [auth I]
L [auth I]
M [auth I]
N [auth I]
O [auth I]
K [auth I],
L [auth I],
M [auth I],
N [auth I],
O [auth I],
P [auth I],
Q [auth I],
R [auth J],
S [auth J],
T [auth J],
U [auth J],
V [auth J],
X [auth D]
MANGANESE (II) ION
Mn
WAEMQWOKJMHJLA-UHFFFAOYSA-N
CL (Subject of Investigation/LOI)
Query on CL

Download Ideal Coordinates CCD File
AA [auth G],
W [auth A],
Y [auth D],
Z [auth E]
CHLORIDE ION
Cl
VEXZGXHMUGYJMC-UHFFFAOYSA-M
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.21 Å
  • R-Value Free: 0.257
  • R-Value Work: 0.213
  • R-Value Observed: 0.215
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 99.64α = 90
b = 108.791β = 90
c = 171.177γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
XDSdata reduction
XDSdata scaling
PDB_EXTRACTdata extraction
PHASERphasing

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Japan Society for the Promotion of ScienceJapanJP17H01408
Japan Society for the Promotion of ScienceJapanJP18H05534
Japan Society for the Promotion of ScienceJapanJP18K14677
Japan Society for the Promotion of ScienceJapanJP19K21177
Japan Society for the Promotion of ScienceJapanJP19K06609
Japan Agency for Medical Research and Development (AMED)JapanJP19am0101076
Japan Science and TechnologyJapanJPMJCR16G1
Japan Society for the Promotion of ScienceJapanJP18J13668

Revision History  (Full details and data files)

  • Version 1.0: 2019-12-18
    Type: Initial release
  • Version 1.1: 2020-04-08
    Changes: Database references
  • Version 1.2: 2023-11-22
    Changes: Data collection, Database references, Derived calculations, Refinement description
