43IG | pdb_000043ig

Cryo-EM structure of H3.X-containing human nucleosome.

• PDB DOI: https://doi.org/10.2210/pdb43IG/pdb
• EM Map EMD-81904: EMDB EMDataResource
• NAKB: 43IG

• Classification: NUCLEAR PROTEIN
• Organism(s): Homo sapiens, synthetic construct
• Expression System: Triticum aestivum
• Mutation(s): No


• Deposited: 2026-07-02 Released: 2026-09-16
• Deposition Author(s): Okimune, K.I., Azuma, T., Takasuka, E.T.
• Funding Organization(s): Other private

---

Experimental Data Snapshot

• Method: ELECTRON MICROSCOPY
• Resolution: 3.14 Å
• Aggregation State: PARTICLE
• Reconstruction Method: SINGLE PARTICLE

Literature

Cryo-EM structural determination of human nucleosomes reconstituted under near physiological conditions

Okimune, K.I., Azuma, T., Banko, P., Haga, J., Terashi, G., Morishita, R., Kita, S., Kihara, D., Maenaka, K., Takasuka, E.T.

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Hetero 8-mer - A2B2C2D2 Pseudo Symmetry: Cyclic - C2  (Explore in 3D)
Pseudo Stoichiometry: Hetero 8-mer - A6B2

Biological assembly 1 assigned by authors and generated by (software)

Biological Assembly Evidence: electron microscopy

Macromolecule Content

• Total Structure Weight: 456.63 kDa
• Atom Count: 11,558
• Modeled Residue Count: 1,015
• Deposited Residue Count: 2,128
• Unique protein chains: 4
• Unique nucleic acid chains: 2

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Histone H3.X	A, E	147	Homo sapiens	Mutation(s): 0  Gene Names: H3Y2
UniProt & NIH Common Fund Data Resources
Find proteins for P0DPK5 (Homo sapiens) Explore P0DPK5  Go to UniProtKB:  P0DPK5
GTEx:  ENSG00000268799

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
Histone H4	B, F	103	Homo sapiens	Mutation(s): 0  Gene Names:  H4C1, H4/A, H4FA, HIST1H4A, H4C2, H4/I, H4FI, HIST1H4B, H4C3, H4/G, H4FG, HIST1H4C, H4C4, H4/B, H4FB, HIST1H4D, H4C5, H4/J, H4FJ, HIST1H4E, H4C6, H4/C, H4FC, HIST1H4F, H4C8, H4/H, H4FH, HIST1H4H, H4C9, H4/M, H4FM, HIST1H4I, H4C11, H4/E, H4FE, HIST1H4J, H4C12, H4/D, H4FD, HIST1H4K, H4C13, H4/K, H4FK, HIST1H4L, H4C14, H4/N, H4F2, H4FN, HIST2H4, HIST2H4A, H4C15, H4/O, H4FO, HIST2H4B, H4C16, H4-16, HIST4H4
UniProt & NIH Common Fund Data Resources
Find proteins for P62805 (Homo sapiens) Explore P62805  Go to UniProtKB:  P62805
PHAROS:  P62805 GTEx:  ENSG00000274618 ENSG00000197238 ENSG00000197837 ENSG00000158406 ENSG00000278705 ENSG00000197061 ENSG00000270882 ENSG00000270276 ENSG00000273542 ENSG00000277157 ENSG00000276966 ENSG00000276180 ENSG00000278637 ENSG00000275126

Entity ID: 3
Molecule	Chains	Sequence Length	Organism	Details	Image
Histone H2A type 2-A	C, G	130	Homo sapiens	Mutation(s): 0  Gene Names: H2AC18, H2AFO, HIST2H2AA, HIST2H2AA3, H2AC19, HIST2H2AA4
UniProt & NIH Common Fund Data Resources
Find proteins for Q6FI13 (Homo sapiens) Explore Q6FI13  Go to UniProtKB:  Q6FI13
PHAROS:  Q6FI13

Entity ID: 4
Molecule	Chains	Sequence Length	Organism	Details	Image
Histone H2B type 1-C/E/F/G/I	D, H	126	Homo sapiens	Mutation(s): 0  Gene Names:  H2BC4, H2BFL, HIST1H2BC, H2BC6, H2BFH, HIST1H2BE, H2BC7, H2BFG, HIST1H2BF, H2BC8, H2BFA, HIST1H2BG, H2BC10, H2BFK, HIST1H2BI
UniProt & NIH Common Fund Data Resources
Find proteins for P62807 (Homo sapiens) Explore P62807  Go to UniProtKB:  P62807
PHAROS:  P62807 GTEx:  ENSG00000180596 ENSG00000277224 ENSG00000278588 ENSG00000273802 ENSG00000274290

Entity ID: 5
Molecule	Chains	Length	Organism	Image
DNA (141-MER)	I	558	synthetic construct

Entity ID: 6
Molecule	Chains	Length	Organism	Image
DNA (141-MER)	J	558	synthetic construct

Experimental Data & Validation

Experimental Data

• Method: ELECTRON MICROSCOPY
• Resolution: 3.14 Å
• Aggregation State: PARTICLE
• Reconstruction Method: SINGLE PARTICLE

EM Software:

Task	Software Package	Version
MODEL REFINEMENT	PHENIX	1.21.2_5419
RECONSTRUCTION	cryoSPARC	v4.7.1

Structure Validation

Entry History

& Funding Information

Deposition Data

• Released Date: 2026-09-16
Deposition Author(s): Okimune, K.I., Azuma, T., Takasuka, E.T.

---

Funding Organization	Location	Grant Number
Other private	Japan	G-2025-2-039

Revision History

• Version 1.0: 2026-09-16
  Type: Initial release
