6UB1 | pdb_00006ub1

Crystal structure of a GH128 (subgroup III) curdlan-specific exo-beta-1,3-glucanase from Blastomyces gilchristii (BgGH128_III) in complex with laminaribiose at -3 and -2 subsites


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.60 Å
  • R-Value Free:
    0.197 (Depositor), 0.207 (DCC)
  • R-Value Work:
    0.160 (Depositor), 0.172 (DCC)
  • R-Value Observed:
    0.162 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 6UB1

Ligand Structure Quality Assessment


This is version 2.3 of the entry. See complete history

Literature

Structural insights into beta-1,3-glucan cleavage by a glycoside hydrolase family.

Santos, C.R.Costa, P.A.C.R.Vieira, P.S.Gonzalez, S.E.T.Correa, T.L.R.Lima, E.A.Mandelli, F.Pirolla, R.A.S.Domingues, M.N.Cabral, L.Martins, M.P.Cordeiro, R.L.Junior, A.T.Souza, B.P.Prates, E.T.Gozzo, F.C.Persinoti, G.F.Skaf, M.S.Murakami, M.T.

(2020) Nat Chem Biol 16: 920-929

  • DOI: https://doi.org/10.1038/s41589-020-0554-5
  • Primary Citation Related Structures:
    6UAQ, 6UAR, 6UAS, 6UAT, 6UAU, 6UAV, 6UAW, 6UAX, 6UAY, 6UAZ, 6UB0, 6UB1, 6UB2, 6UB3, 6UB4, 6UB5, 6UB6, 6UB7, 6UB8, 6UBA, 6UBB, 6UBC, 6UBD, 6UFL, 6UFZ

  • PubMed Abstract:

    The fundamental and assorted roles of β-1,3-glucans in nature are underpinned on diverse chemistry and molecular structures, demanding sophisticated and intricate enzymatic systems for their processing. In this work, the selectivity and modes of action of a glycoside hydrolase family active on β-1,3-glucans were systematically investigated combining sequence similarity network, phylogeny, X-ray crystallography, enzyme kinetics, mutagenesis and molecular dynamics. This family exhibits a minimalist and versatile (α/β)-barrel scaffold, which can harbor distinguishing exo or endo modes of action, including an ancillary-binding site for the anchoring of triple-helical β-1,3-glucans. The substrate binding occurs via a hydrophobic knuckle complementary to the canonical curved conformation of β-1,3-glucans or through a substrate conformational change imposed by the active-site topology of some fungal enzymes. Together, these findings expand our understanding of the enzymatic arsenal of bacteria and fungi for the breakdown and modification of β-1,3-glucans, which can be exploited for biotechnological applications.


  • Organizational Affiliation
    • Brazilian Biorenewables National Laboratory, Brazilian Center for Research in Energy and Materials, Campinas, São Paulo, Brazil.

Macromolecule Content

  • Total Structure Weight: 113.18 kDa
  • Atom Count: 8,197
  • Modeled Residue Count: 920
  • Deposited Residue Count: 1,044
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
GLYCOSIDE HYDROLASE
A, B, C, D
261Blastomyces gilchristiiMutation(s): 0
UniProt
Find proteins for A0A179UGT5 (Blastomyces gilchristii (strain SLH14081))
Explore A0A179UGT5
Go to UniProtKB:  A0A179UGT5
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A179UGT5
Sequence Annotations
Expand
Reference Sequence

Oligosaccharides

Help
Entity ID: 2
MoleculeChains Length2D Diagram GlycosylationD Interactions
beta-D-glucopyranose-(1-3)-beta-D-glucopyranose
E, F, G
2N/A
Glycosylation Resources
GlyTouCan: G36535HU
GlyCosmos: G36535HU

Small Molecules

Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
BGC
(Subject of Investigation/LOI)

Query on BGC



Download:Ideal Coordinates CCD File
H [auth B]beta-D-glucopyranose
C6 H12 O6
WQZGKKKJIJFFOK-VFUOTHLCSA-N

Biologically Interesting Molecules (External Reference)

1 Unique

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.60 Å
  • R-Value Free:  0.197 (Depositor), 0.207 (DCC)
  • R-Value Work:  0.160 (Depositor), 0.172 (DCC)
  • R-Value Observed: 0.162 (Depositor)
Space Group: P 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 56.323α = 69.67
b = 60.804β = 78.24
c = 63.545γ = 77.86
Software Package:
Software NamePurpose
REFMACrefinement
XDSdata reduction
XSCALEdata scaling
MOLREPphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Sao Paulo Research Foundation (FAPESP)Brazil15/26982-0

Revision History  (Full details and data files)

  • Version 1.0: 2020-05-20
    Type: Initial release
  • Version 1.1: 2020-06-10
    Changes: Database references
  • Version 2.0: 2020-07-29
    Type: Remediation
    Reason: Carbohydrate remediation
    Changes: Advisory, Atomic model, Data collection, Derived calculations, Structure summary
  • Version 2.1: 2020-08-05
    Changes: Database references
  • Version 2.2: 2023-10-11
    Changes: Data collection, Database references, Refinement description, Structure summary
  • Version 2.3: 2024-10-23
    Changes: Structure summary
