3GFU

FaeE-FaeG chaperone-major pilin complex of F4 ac 5/95 fimbriae


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.99 Å
  • R-Value Free: 0.286
  • R-Value Work: 0.239
  • R-Value Observed: 0.241

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


This is version 1.4 of the entry. See complete history


Literature

Structural and thermodynamic characterization of pre- and postpolymerization states in the F4 fimbrial subunit FaeG

Van Molle, I.Moonens, K.Garcia-Pino, A.Buts, L.De Kerpel, M.Wyns, L.Bouckaert, J.De Greve, H.

(2009) J Mol Biol 394: 957-967

  • DOI: https://doi.org/10.1016/j.jmb.2009.09.059
  • Primary Citation of Related Structures:
    3GEA, 3GEW, 3GFU, 3GGH, 3HLR

  • PubMed Abstract:

    Enterotoxigenic Escherichia coli expressing F4 fimbriae are the major cause of porcine colibacillosis and are responsible for significant death and morbidity in neonatal and postweaned piglets. Via the chaperone-usher pathway, F4 fimbriae are assembled into thin, flexible polymers mainly composed of the single-domain adhesin FaeG. The F4 fimbrial system has been labeled eccentric because the F4 pilins show some features distinct from the features of pilins of other chaperone-usher-assembled structures. In particular, FaeG is much larger than other pilins (27 versus approximately 17 kDa), grafting an additional carbohydrate binding domain on the common immunoglobulin-like core. Structural data of FaeG during different stages of the F4 fimbrial biogenesis process, combined with differential scanning calorimetry measurements, confirm the general principles of the donor strand complementation/exchange mechanisms taking place during pilus biogenesis via the chaperone-usher pathway.


  • Organizational Affiliation

    Structural Biology Brussels, Vrije Universiteit Brussel, Pleinlaan 2, 1050 Brussels, Belgium.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Chaperone protein faeEA [auth C],
C [auth A]
224Escherichia coliMutation(s): 0
Gene Names: faeE
UniProt
Find proteins for P25401 (Escherichia coli)
Explore P25401
Go to UniProtKB:  P25401
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP25401
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
FaeGB [auth D],
D [auth B]
251Escherichia coliMutation(s): 0
Gene Names: faeG
UniProt
Find proteins for Q6T3W5 (Escherichia coli)
Explore Q6T3W5
Go to UniProtKB:  Q6T3W5
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ6T3W5
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
SO4
Query on SO4

Download Ideal Coordinates CCD File
E [auth C]
F [auth C]
G [auth C]
H [auth C]
I [auth D]
E [auth C],
F [auth C],
G [auth C],
H [auth C],
I [auth D],
J [auth A],
K [auth A],
L [auth A],
M [auth A],
N [auth A],
O [auth B]
SULFATE ION
O4 S
QAOWNCQODCNURD-UHFFFAOYSA-L
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.99 Å
  • R-Value Free: 0.286
  • R-Value Work: 0.239
  • R-Value Observed: 0.241
  • Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 74.924α = 90
b = 90.108β = 114.49
c = 86.544γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
PDB_EXTRACTdata extraction
MAR345dtbdata collection
DENZOdata reduction
SCALEPACKdata scaling
PHASERphasing
PHENIXrefinement

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2009-10-20
    Type: Initial release
  • Version 1.1: 2011-07-13
    Changes: Version format compliance
  • Version 1.2: 2014-01-29
    Changes: Database references
  • Version 1.3: 2017-08-09
    Changes: Refinement description, Source and taxonomy
  • Version 1.4: 2023-11-01
    Changes: Data collection, Database references, Derived calculations, Refinement description
