3GEA | pdb_00003gea

Donor strand complemented FaeG monomer of F4 variant ad

PDB DOI: https://doi.org/10.2210/pdb3GEA/pdb

Classification: CELL ADHESION
Organism(s): Escherichia coli
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2009-02-25 Released: 2009-10-20
Deposition Author(s): Van Molle, I., Moonens, K., Garcia-Pino, A., Buts, L., Bouckaert, J., De Greve, H.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.70 Å
R-Value Free:
0.183 (Depositor), 0.177 (DCC)
R-Value Work:
0.159 (Depositor), 0.155 (DCC)
R-Value Observed:
0.160 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

This is version 1.4 of the entry. See complete history.

Literature

Structural and thermodynamic characterization of pre- and postpolymerization states in the F4 fimbrial subunit FaeG

Van Molle, I., Moonens, K., Garcia-Pino, A., Buts, L., De Kerpel, M., Wyns, L., Bouckaert, J., De Greve, H.

(2009) J Mol Biology 394: 957-967

PubMed: 19799915 Search on PubMed
DOI: https://doi.org/10.1016/j.jmb.2009.09.059
Primary Citation Related Structures:
3GEA, 3GEW, 3GFU, 3GGH, 3HLR

PubMed Abstract:
Enterotoxigenic Escherichia coli expressing F4 fimbriae are the major cause of porcine colibacillosis and are responsible for significant death and morbidity in neonatal and postweaned piglets. Via the chaperone-usher pathway, F4 fimbriae are assembled into thin, flexible polymers mainly composed of the single-domain adhesin FaeG. The F4 fimbrial system has been labeled eccentric because the F4 pilins show some features distinct from the features of pilins of other chaperone-usher-assembled structures. In particular, FaeG is much larger than other pilins (27 versus approximately 17 kDa), grafting an additional carbohydrate binding domain on the common immunoglobulin-like core. Structural data of FaeG during different stages of the F4 fimbrial biogenesis process, combined with differential scanning calorimetry measurements, confirm the general principles of the donor strand complementation/exchange mechanisms taking place during pilus biogenesis via the chaperone-usher pathway.

Organizational Affiliation

Structural Biology Brussels, Vrije Universiteit Brussel, Pleinlaan 2, 1050 Brussels, Belgium.

Macromolecule Content

Total Structure Weight: 58.34 kDa
Atom Count: 4,453
Modeled Residue Count: 535
Deposited Residue Count: 548
Unique protein chains: 1

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
K88 fimbrial protein AD	A, B	274	Escherichia coli	Mutation(s): 0 Gene Names: faeG
UniProt
Find proteins for P14191 (Escherichia coli) Explore P14191 Go to UniProtKB: P14191
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P14191
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
SO4 Query on SO4 Download:Ideal Coordinates CCD File SDF format, chain E [auth A] SDF format, chain D [auth A] SDF format, chain C [auth A] MOL2 format, chain E [auth A] MOL2 format, chain D [auth A] MOL2 format, chain C [auth A] mmCIF format, chain E [auth A] mmCIF format, chain D [auth A] mmCIF format, chain C [auth A]	C [auth A], D [auth A], E [auth A]	SULFATE ION O₄ S QAOWNCQODCNURD-UHFFFAOYSA-L		Interactions Focus chain C [auth A] Focus chain D [auth A] Focus chain E [auth A] Interactions & Density Focus chain C [auth A] Focus chain D [auth A] Focus chain E [auth A]
GOL Query on GOL Download:Ideal Coordinates CCD File SDF format, chain J [auth B] SDF format, chain I [auth B] SDF format, chain H [auth A] SDF format, chain G [auth A] SDF format, chain F [auth A] MOL2 format, chain J [auth B] MOL2 format, chain I [auth B] MOL2 format, chain H [auth A] MOL2 format, chain G [auth A] MOL2 format, chain F [auth A] mmCIF format, chain J [auth B] mmCIF format, chain I [auth B] mmCIF format, chain H [auth A] mmCIF format, chain G [auth A] mmCIF format, chain F [auth A]	F [auth A], G [auth A], H [auth A], I [auth B], J [auth B]	GLYCEROL C₃ H₈ O₃ PEDCQBHIVMGVHV-UHFFFAOYSA-N		Interactions Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth B] Focus chain J [auth B] Interactions & Density Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth B] Focus chain J [auth B]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.70 Å
R-Value Free: 0.183 (Depositor), 0.177 (DCC)
R-Value Work: 0.159 (Depositor), 0.155 (DCC)
R-Value Observed: 0.160 (Depositor)

Space Group: P 3₁ 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 123.965	α = 90
b = 123.965	β = 90
c = 95.886	γ = 120

Software Package:

Software Name	Purpose
PHASER	phasing
PHENIX	refinement
PDB_EXTRACT	data extraction
ADSC	data collection
MOSFLM	data reduction
SCALA	data scaling

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2009-10-20

Deposition Author(s):

Revision History (Full details and data files)

Version 1.0: 2009-10-20
Type: Initial release
Version 1.1: 2011-07-13
Changes: Non-polymer description, Version format compliance
Version 1.2: 2014-01-29
Changes: Database references
Version 1.3: 2017-08-09
Changes: Refinement description, Source and taxonomy
Version 1.4: 2023-11-01
Changes: Data collection, Database references, Derived calculations, Refinement description
