2INN | pdb_00002inn

Structure of the Phenol Hydroxyalse-Regulatory Protein Complex


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.70 Å
  • R-Value Free:
    0.252 (Depositor), 0.251 (DCC)
  • R-Value Work:
    0.202 (Depositor), 0.164 (DCC)
  • R-Value Observed:
    0.206 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 2INN

This is version 1.4 of the entry. See complete history

Literature

X-ray Structure of a Hydroxylase-Regulatory Protein Complex from a Hydrocarbon-Oxidizing Multicomponent Monooxygenase, Pseudomonas sp. OX1 Phenol Hydroxylase.

Sazinsky, M.H.Dunten, P.W.McCormick, M.S.Didonato, A.Lippard, S.J.

(2006) Biochemistry 45: 15392-15404

  • DOI: https://doi.org/10.1021/bi0618969
  • Primary Citation Related Structures:
    2INN, 2INP

  • PubMed Abstract:

    Phenol hydroxylase (PH) belongs to a family of bacterial multicomponent monooxygenases (BMMs) with carboxylate-bridged diiron active sites. Included are toluene/o-xylene (ToMO) and soluble methane (sMMO) monooxygenase. PH hydroxylates aromatic compounds, but unlike sMMO, it cannot oxidize alkanes despite having a similar dinuclear iron active site. Important for activity is formation of a complex between the hydroxylase and a regulatory protein component. To address how structural features of BMM hydroxylases and their component complexes may facilitate the catalytic mechanism and choice of substrate, we determined X-ray structures of native and SeMet forms of the PH hydroxylase (PHH) in complex with its regulatory protein (PHM) to 2.3 A resolution. PHM binds in a canyon on one side of the (alphabetagamma)2 PHH dimer, contacting alpha-subunit helices A, E, and F approximately 12 A above the diiron core. The structure of the dinuclear iron center in PHH resembles that of mixed-valent MMOH, suggesting an Fe(II)Fe(III) oxidation state. Helix E, which comprises part of the iron-coordinating four-helix bundle, has more pi-helical character than analogous E helices in MMOH and ToMOH lacking a bound regulatory protein. Consequently, conserved active site Thr and Asn residues translocate to the protein surface, and an approximately 6 A pore opens through the four-helix bundle. Of likely functional significance is a specific hydrogen bond formed between this Asn residue and a conserved Ser side chain on PHM. The PHM protein covers a putative docking site on PHH for the PH reductase, which transfers electrons to the PHH diiron center prior to O2 activation, suggesting that the regulatory component may function to block undesired reduction of oxygenated intermediates during the catalytic cycle. A series of hydrophobic cavities through the PHH alpha-subunit, analogous to those in MMOH, may facilitate movement of the substrate to and/or product from the active site pocket. Comparisons between the ToMOH and PHH structures provide insights into their substrate regiospecificities.


  • Organizational Affiliation
    • Department of Chemistry, Massachusetts Institute of Technology, Cambridge, Massachusetts 02139, USA.

Macromolecule Content

  • Total Structure Weight: 238.88 kDa
  • Atom Count: 16,389
  • Modeled Residue Count: 1,956
  • Deposited Residue Count: 2,015
  • Unique protein chains: 4

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Phenol hydroxylase component phN
A, B
511Stutzerimonas stutzeriMutation(s): 17
Gene Names: phN
UniProt
Find proteins for Q84AQ2 (Stutzerimonas stutzeri)
Explore Q84AQ2
Go to UniProtKB:  Q84AQ2
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ84AQ2
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 2
MoleculeChains  Sequence LengthOrganismDetailsImage
Phenol hydroxylase component phL
C, D
333Stutzerimonas stutzeriMutation(s): 17
Gene Names: phL
UniProt
Find proteins for Q84AQ4 (Stutzerimonas stutzeri)
Explore Q84AQ4
Go to UniProtKB:  Q84AQ4
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ84AQ4
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 3
MoleculeChains  Sequence LengthOrganismDetailsImage
Phenol hydroxylase component phO
E, F
119Stutzerimonas stutzeriMutation(s): 5
Gene Names: phO
UniProt
Find proteins for Q84AQ1 (Stutzerimonas stutzeri)
Explore Q84AQ1
Go to UniProtKB:  Q84AQ1
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ84AQ1
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 4
MoleculeChains  Sequence LengthOrganismDetailsImage
Phenol hydroxylase component phMG [auth L]89Stutzerimonas stutzeriMutation(s): 6
Gene Names: phM
UniProt
Find proteins for Q84AQ3 (Stutzerimonas stutzeri)
Explore Q84AQ3
Go to UniProtKB:  Q84AQ3
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ84AQ3
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 3 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
MOO

Query on MOO



Download:Ideal Coordinates CCD File
N [auth B]MOLYBDATE ION
Mo O4
MEFBJEMVZONFCJ-UHFFFAOYSA-N
ZN

Query on ZN



Download:Ideal Coordinates CCD File
J [auth A],
M [auth B]
ZINC ION
Zn
PTFCDOFLOPIGGS-UHFFFAOYSA-N
FE

Query on FE



Download:Ideal Coordinates CCD File
H [auth A],
I [auth A],
K [auth B],
L [auth B]
FE (III) ION
Fe
VTLYFUHAOXGGBS-UHFFFAOYSA-N
Modified Residues  1 Unique
IDChains TypeFormula2D DiagramParent
MSE
Query on MSE
A, B
L-PEPTIDE LINKINGC5 H11 N O2 SeMET

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.70 Å
  • R-Value Free:  0.252 (Depositor), 0.251 (DCC)
  • R-Value Work:  0.202 (Depositor), 0.164 (DCC)
  • R-Value Observed: 0.206 (Depositor)
Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 87.453α = 90
b = 146.925β = 90
c = 189.787γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
PDB_EXTRACTdata extraction
ADSCdata collection
DENZOdata reduction
SCALEPACKdata scaling
SnBphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2007-01-16
    Type: Initial release
  • Version 1.1: 2008-05-01
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
  • Version 1.3: 2017-10-18
    Changes: Refinement description
  • Version 1.4: 2024-11-13
    Changes: Data collection, Database references, Derived calculations, Structure summary
