The cold-intermediate state (C2M, 4C), menthol-bound mouse TRPM8-I846V in complex with AITC and PIP2

PDB DOI: https://doi.org/10.2210/pdb9Y69/pdb
EM Map EMD-72557: EMDB EMDataResource

Classification: MEMBRANE PROTEIN
Organism(s): Mus musculus
Expression System: Homo sapiens
Mutation(s): Yes

Deposited: 2025-09-08 Released: 2026-10-07
Deposition Author(s): Lee, H.J., Lee, S.Y.
Funding Organization(s): National Institutes of Health/National Institute of Environmental Health Sciences (NIH/NIEHS), National Institutes of Health/National Eye Institute (NIH/NEI)

Experimental Data Snapshot

Method: ELECTRON MICROSCOPY
Resolution: 3.30 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

This is version 1.0 of the entry. See complete history.

Literature

Molecular basis for cold and menthol sensing by mammalian TRPM8.

Lee, H.J., Park, C.G., Fedor, J.G., Peele, W.A., Borgnia, M.J., Lee, S.Y.

(2026) Nat Commun 17

PubMed: 42744822 Search on PubMed Search on PubMed Central
DOI: https://doi.org/10.1038/s41467-026-76926-1
Primary Citation Related Structures:
9PWE, 9PWF, 9PWG, 9PWH, 9Y69, 9Y6A, 9ZYR

PubMed Abstract:
The transient receptor potential melastatin member 8 (TRPM8) is a polymodal ion channel that senses cold and menthol in mammals. Despite prior structural studies, the mechanisms by which cold and menthol activate TRPM8 remain unresolved. Here, we present cryo-EM structures and extensive functional analyses to reveal cold- and menthol-dependent activation mechanisms. We observe that cold-sensing residues are widespread and that snapshots of cooling-dependent opening reveal dramatic pore rearrangement which suggest a mechanism for cold sensing. Menthol binds dynamically to drive channel activation toward a common gate with cold, but with specific outer pore conformations. Finally, we show how TRPM8 integrates cold and menthol modalities through overlapping but non-identical networks, revealing a coldspot that is central to cold activation of TRPM8 and is the location of allyl isothiocyanate (AITC) binding. These findings enhance our understanding of the molecular basis of physically and chemically induced cool sensation in mammals.

Organizational Affiliation

Department of Biochemistry, Duke University School of Medicine, Durham, NC, USA.

Macromolecule Content

Total Structure Weight: 514.98 kDa
Atom Count: 29,152
Modeled Residue Count: 3,876
Deposited Residue Count: 4,416
Unique protein chains: 1

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Transient receptor potential cation channel subfamily M member 8	A, B, C, D	1,104	Mus musculus	Mutation(s): 1 Gene Names: Trpm8, Ltrpc6, Trpp8
UniProt
Find proteins for Q8R4D5 (Mus musculus) Explore Q8R4D5 Go to UniProtKB: Q8R4D5
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q8R4D5
