9B1V

Crystal structure of PqqT with PQQ and Gd3+ bound


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.55 Å
  • R-Value Free: 0.186
  • R-Value Work: 0.178
  • R-Value Observed: 0.178

Starting Model: in silico
View more details

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.0 of the entry. See complete history


Literature

Structure-driven development of a biomimetic rare earth artificial metalloprotein.

Thompson, P.J.Boggs, D.G.Wilson, C.A.Bruchs, A.T.Velidandla, U.Bridwell-Rabb, J.Olshansky, L.

(2024) Proc Natl Acad Sci U S A 121: e2405836121-e2405836121

  • DOI: https://doi.org/10.1073/pnas.2405836121
  • Primary Citation of Related Structures:
    9B1U, 9B1V

  • PubMed Abstract:

    The 2011 discovery of the first rare earth-dependent enzyme in methylotrophic Methylobacterium extorquens AM1 prompted intensive research toward understanding the unique chemistry at play in these systems. This enzyme, an alcohol dehydrogenase (ADH), features a La 3+ ion closely associated with redox-active coenzyme pyrroloquinoline quinone (PQQ) and is structurally homologous to the Ca 2+ -dependent ADH from the same organism. AM1 also produces a periplasmic PQQ-binding protein, PqqT, which we have now structurally characterized to 1.46-Å resolution by X-ray diffraction. This crystal structure reveals a Lys residue hydrogen-bonded to PQQ at the site analogously occupied by a Lewis acidic cation in ADH. Accordingly, we prepared K 142 A- and K 142 D-PqqT variants to assess the relevance of this site toward metal binding. Isothermal titration calorimetry experiments and titrations monitored by UV-Vis absorption and emission spectroscopies support that K 142 D-PqqT binds tightly ( K d = 0.6 ± 0.2 μM) to La 3+ in the presence of bound PQQ and produces spectral signatures consistent with those of ADH enzymes. These spectral signatures are not observed for WT- or K 142 A-variants or upon addition of Ca 2+ to PQQ ⸦ K 142 D-PqqT. Addition of benzyl alcohol to La 3+ -bound PQQ ⸦ K 142 D-PqqT (but not Ca 2+ -bound PQQ ⸦ K 142 D-PqqT, or La 3+ -bound PQQ ⸦ WT-PqqT) produces spectroscopic changes associated with PQQ reduction, and chemical trapping experiments reveal the production of benzaldehyde, supporting ADH activity. By creating a metal binding site that mimics native ADH enzymes, we present a rare earth-dependent artificial metalloenzyme primed for future mechanistic, biocatalytic, and biosensing applications.


  • Organizational Affiliation

    Center for Biophysics and Quantitative Biology, University of Illinois, Urbana-Champaign, Urbana, IL 61801.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Putative ABC transporter periplasmic solute-binding protein310Methylorubrum extorquensMutation(s): 0
Gene Names: Mchl_2142
UniProt
Find proteins for B7KXB5 (Methylorubrum extorquens (strain CM4 / NCIMB 13688))
Explore B7KXB5
Go to UniProtKB:  B7KXB5
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupB7KXB5
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.55 Å
  • R-Value Free: 0.186
  • R-Value Work: 0.178
  • R-Value Observed: 0.178
  • Space Group: P 2 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 39.867α = 90
b = 53.389β = 90
c = 119.465γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
XDSdata reduction
XDSdata scaling
PHENIXphasing
Cootmodel building

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesGM138138

Revision History  (Full details and data files)

  • Version 1.0: 2024-08-21
    Type: Initial release
