8URK | pdb_00008urk

Crystal structure of DNA N6-Adenine Methyltransferase M.BceJIV from Burkholderia cenocepacia in complex with duplex DNA substrates


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.11 Å
  • R-Value Free:
    0.234 (Depositor), 0.228 (DCC)
  • R-Value Work:
    0.184 (Depositor)
  • R-Value Observed:
    0.186 (Depositor)

Starting Models: in silico, experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 8URK

Ligand Structure Quality Assessment


This is version 1.2 of the entry. See complete history

Literature

Burkholderia cenocepacia epigenetic regulator M.BceJIV simultaneously engages two DNA recognition sequences for methylation.

Quintana-Feliciano, R.Kottur, J.Ni, M.Ghosh, R.Salas-Estrada, L.Ahlsen, G.Rechkoblit, O.Shapiro, L.Filizola, M.Fang, G.Aggarwal, A.K.

(2024) Nat Commun 15: 7839-7839

  • DOI: https://doi.org/10.1038/s41467-024-52130-x
  • Primary Citation Related Structures:
    8URK, 9C3S, 9C3T, 9C3U

  • PubMed Abstract:

    Burkholderia cenocepacia is an opportunistic and infective bacterium containing an orphan DNA methyltransferase called M.BceJIV with roles in regulating gene expression and motility of the bacterium. M.BceJIV recognizes a GTWWAC motif (where W can be an adenine or a thymine) and methylates N6 of the adenine at the fifth base position. Here, we present crystal structures of M.BceJIV/DNA/sinefungin ternary complex and allied biochemical, computational, and thermodynamic analyses. Remarkably, the structures show not one, but two DNA substrates bound to the M.BceJIV dimer, with each monomer contributing to the recognition of two recognition sequences. We also show that methylation at the two recognition sequences occurs independently, and that the GTWWAC motifs are enriched in intergenic regions in the genomes of B. cenocepacia strains. We further computationally assess the interactions underlying the affinities of different ligands (SAM, SAH, and sinefungin) for M.BceJIV, as a step towards developing selective inhibitors for limiting B. cenocepacia infection.


  • Organizational Affiliation
    • Department of Pharmacological Sciences, Icahn School of Medicine at Mount Sinai, New York, New York, USA.

Macromolecule Content

  • Total Structure Weight: 162.65 kDa
  • Atom Count: 10,829
  • Modeled Residue Count: 1,103
  • Deposited Residue Count: 1,244
  • Unique protein chains: 1
  • Unique nucleic acid chains: 2

Macromolecules


Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
MethyltransferaseA,
D [auth C],
E [auth D],
F [auth B]
283Burkholderia cenocepaciaMutation(s): 0
Gene Names: JAO13_04290
EC: 2.1.1
UniProt
Find proteins for A0A8I1DKW0 (Burkholderia cepacia)
Explore A0A8I1DKW0
Go to UniProtKB:  A0A8I1DKW0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A8I1DKW0
Sequence Annotations
Expand
Reference Sequence
Find similar nucleic acids by:  Sequence
Entity ID: 2
MoleculeChains LengthOrganismImage
DNA1B [auth E],
G,
I,
K
14Burkholderia cenocepacia
Sequence Annotations
Expand
Reference Sequence
Find similar nucleic acids by:  Sequence
Entity ID: 3
MoleculeChains LengthOrganismImage
DNA2C [auth F],
H,
J,
L
14Burkholderia cenocepacia
Sequence Annotations
Expand
Reference Sequence

Oligosaccharides

Help
Entity ID: 4
MoleculeChains Length2D Diagram GlycosylationD Interactions
beta-D-fructofuranose-(2-1)-alpha-D-glucopyranoseM [auth N],
N [auth O]
2N/A
Glycosylation Resources
GlyTouCan: G05551OP
GlyCosmos: G05551OP

Biologically Interesting Molecules (External Reference)

1 Unique

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.11 Å
  • R-Value Free:  0.234 (Depositor), 0.228 (DCC)
  • R-Value Work:  0.184 (Depositor)
  • R-Value Observed: 0.186 (Depositor)
Space Group: I 41
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 137.728α = 90
b = 137.728β = 90
c = 167.315γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
Aimlessdata scaling
XDSdata reduction
PHASERphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Not funded--

Revision History  (Full details and data files)

  • Version 1.0: 2024-09-11
    Type: Initial release
  • Version 1.1: 2024-09-18
    Changes: Database references
  • Version 1.2: 2024-09-25
    Changes: Database references
