8B8F | pdb_00008b8f

Atomic structure of the beta-trefoil domain of the Laccaria bicolor lectin LBL in complex with lactose


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.00 Å
  • R-Value Free:
    0.152 (Depositor), 0.153 (DCC)
  • R-Value Work:
    0.140 (Depositor), 0.140 (DCC)
  • R-Value Observed:
    0.141 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 8B8F

This is version 1.1 of the entry. See complete history

Literature

Atomic crystal structure and sugar specificity of a beta-trefoil lectin domain from the ectomycorrhizal basidiomycete Laccaria bicolor.

Acebron, I.Campanero-Rhodes, M.A.Solis, D.Menendez, M.Garcia, C.Lillo, M.P.Mancheno, J.M.

(2023) Int J Biol Macromol 233: 123507-123507

  • DOI: https://doi.org/10.1016/j.ijbiomac.2023.123507
  • Primary Citation Related Structures:
    8B8F, 8B97

  • PubMed Abstract:

    Lectins from fruiting bodies are a diverse group of sugar-binding proteins from mushrooms that face the biologically relevant challenge of discriminating self- from non-self carbohydrate structures, therefore providing a basis for an innate defence system. Such a system entails both detection and destruction of invaders and/or feeders, and in contrast to more complex organisms with immense immune systems, these two functions normally rely on multitasking lectins, namely, lectins with different functional modules. Here, we present a novel fungal lectin, LBL, from the basidiomycete Laccaria bicolor. Using a diverse set of biophysical techniques, we unveil the fine details of the sugar-binding specificity of the N-terminal β-trefoil of LBL (LBL 152 ), whose structure has been determined at the highest resolution so far reported for such a fold. LBL 152 binds complex poly-N-Acetyllactosamine polysaccharides and also robust LBL 152 binding to Caenorhabditis elegans and Drosophila melanogaster cellular extracts was detected in microarray assays, with a seeming preference for the fruit fly adult and pupa stages over the larva stage. Prediction of the structure of the C-terminal part of LBL with AlphaFold reveals a tandem repeat of two structurally almost identical domains of around 110 amino acids each, despite sharing low sequence conservation.


  • Organizational Affiliation
    • Department of Crystallography and Structural Biology, Institute of Physical Chemistry Rocasolano, CSIC, Serrano 119, 28006 Madrid, Spain.

Macromolecule Content

  • Total Structure Weight: 18.92 kDa
  • Atom Count: 1,675
  • Modeled Residue Count: 151
  • Deposited Residue Count: 152
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
N-terminal beta-trefoil domain of the lectin LBL from Laccaria bicolor152Laccaria bicolor S238N-H53Mutation(s): 0
Gene Names: LACBIDRAFT_318163
UniProt
Find proteins for B0D650 (Laccaria bicolor (strain S238N-H82 / ATCC MYA-4686))
Explore B0D650
Go to UniProtKB:  B0D650
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupB0D650
Sequence Annotations
Expand
Reference Sequence

Oligosaccharides

Help
Entity ID: 2
MoleculeChains Length2D Diagram GlycosylationD Interactions
beta-D-galactopyranose-(1-4)-alpha-D-glucopyranoseB [auth C],
C [auth B],
D
2N/A
Glycosylation Resources
GlyTouCan: G88362QR
GlyCosmos: G88362QR
GlyGen: G88362QR
Entity ID: 3
MoleculeChains Length2D Diagram GlycosylationD Interactions
beta-D-galactopyranose-(1-4)-beta-D-glucopyranose
E, F, G
2N/A
Glycosylation Resources
GlyTouCan: G84224TW
GlyCosmos: G84224TW
GlyGen: G84224TW

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.00 Å
  • R-Value Free:  0.152 (Depositor), 0.153 (DCC)
  • R-Value Work:  0.140 (Depositor), 0.140 (DCC)
  • R-Value Observed: 0.141 (Depositor)
Space Group: P 21 21 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 52.53α = 90
b = 61.27β = 90
c = 44.79γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
MOSFLMdata reduction
SCALAdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Spanish Ministry of Economy and CompetitivenessSpainBFU2010-17929/BMC
Spanish Ministry of Science, Innovation, and UniversitiesSpainRTI2018-099985-B-I00

Revision History  (Full details and data files)

  • Version 1.0: 2023-02-22
    Type: Initial release
  • Version 1.1: 2024-02-07
    Changes: Data collection, Refinement description
