7QDI | pdb_00007qdi

Structure of octameric left-handed 310-helix bundle: D-310HD


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.34 Å
  • R-Value Free:
    0.239 (Depositor), 0.256 (DCC)
  • R-Value Work:
    0.189 (Depositor), 0.201 (DCC)
  • R-Value Observed:
    0.191 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 7QDI

This is version 1.3 of the entry. See complete history

Literature

De novo design of discrete, stable 3 10 -helix peptide assemblies.

Kumar, P.Paterson, N.G.Clayden, J.Woolfson, D.N.

(2022) Nature 607: 387-392

  • DOI: https://doi.org/10.1038/s41586-022-04868-x
  • Primary Citation Related Structures:
    7QDI, 7QDJ, 7QDK, 8BFD, 8BFE

  • PubMed Abstract:

    The α-helix is pre-eminent in structural biology 1 and widely exploited in protein folding 2 , design 3 and engineering 4 . Although other helical peptide conformations do exist near to the α-helical region of conformational space-namely, 3 10 -helices and π-helices 5 -these occur much less frequently in protein structures. Less favourable internal energies and reduced tendencies to pack into higher-order structures mean that 3 10 -helices rarely exceed six residues in length in natural proteins, and that they tend not to form normal supersecondary, tertiary or quaternary interactions. Here we show that despite their absence in nature, synthetic peptide assemblies can be built from 3 10 -helices. We report the rational design, solution-phase characterization and an X-ray crystal structure for water-soluble bundles of 3 10 -helices with consolidated hydrophobic cores. The design uses six-residue repeats informed by analysing 3 10 -helical conformations in known protein structures, and incorporates α-aminoisobutyric acid residues. Design iterations reveal a tipping point between α-helical and 3 10 -helical folding, and identify features required for stabilizing assemblies of 3 10 -helices. This work provides principles and rules to open opportunities for designing into this hitherto unexplored region of protein-structure space.


  • Organizational Affiliation
    • School of Chemistry, University of Bristol, Bristol, UK. prasun.kumar@bristol.ac.uk.

Macromolecule Content

  • Total Structure Weight: 30.06 kDa
  • Atom Count: 2,070
  • Modeled Residue Count: 238
  • Deposited Residue Count: 264
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
D-310HD
A, B, C, D, E
A, B, C, D, E, F, G, H
33synthetic constructMutation(s): 0

Small Molecules

Ligands 8 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
PG6

Query on PG6



Download:Ideal Coordinates CCD File
U [auth C]1-(2-METHOXY-ETHOXY)-2-{2-[2-(2-METHOXY-ETHOXY]-ETHOXY}-ETHANE
C12 H26 O6
DMDPGPKXQDIQQG-UHFFFAOYSA-N
PG4

Query on PG4



Download:Ideal Coordinates CCD File
DA [auth E]TETRAETHYLENE GLYCOL
C8 H18 O5
UWHCKJMYHZGTIT-UHFFFAOYSA-N
PGE

Query on PGE



Download:Ideal Coordinates CCD File
I [auth A],
J [auth A]
TRIETHYLENE GLYCOL
C6 H14 O4
ZIBGPFATKBEMQZ-UHFFFAOYSA-N
PG0

Query on PG0



Download:Ideal Coordinates CCD File
P [auth B]2-(2-METHOXYETHOXY)ETHANOL
C5 H12 O3
SBASXUCJHJRPEV-UHFFFAOYSA-N
PEG

Query on PEG



Download:Ideal Coordinates CCD File
EA [auth E]
GA [auth E]
HA [auth E]
LA [auth F]
M [auth A]
EA [auth E],
GA [auth E],
HA [auth E],
LA [auth F],
M [auth A],
MA [auth G],
N [auth A],
R [auth B]
DI(HYDROXYETHYL)ETHER
C4 H10 O3
MTHSVFCYNBDYFN-UHFFFAOYSA-N
SO4

Query on SO4



Download:Ideal Coordinates CCD File
BA [auth D],
L [auth A],
V [auth C]
SULFATE ION
O4 S
QAOWNCQODCNURD-UHFFFAOYSA-L
EDO

Query on EDO



Download:Ideal Coordinates CCD File
AA [auth D]
CA [auth E]
FA [auth E]
IA [auth E]
K [auth A]
AA [auth D],
CA [auth E],
FA [auth E],
IA [auth E],
K [auth A],
KA [auth E],
NA [auth G],
O [auth A],
Q [auth B],
S [auth B],
T [auth C],
X [auth C],
Y [auth D],
Z [auth D]
1,2-ETHANEDIOL
C2 H6 O2
LYCAIKOWRPUZTN-UHFFFAOYSA-N
BO3

Query on BO3



Download:Ideal Coordinates CCD File
JA [auth E],
W [auth C]
BORIC ACID
B H3 O3
KGBXLFKZBHKPEV-UHFFFAOYSA-N
Modified Residues  1 Unique
IDChains TypeFormula2D DiagramParent
AIB
Query on AIB
A, B, C, D, E
A, B, C, D, E, F, G, H
L-PEPTIDE LINKINGC4 H9 N O2ALA
BF7
Query on BF7
A, B, C, D, E
A, B, C, D, E, F, G, H
D-PEPTIDE LINKINGC9 H10 Br N O2

--

DGL
Query on DGL
A, B, C, D, E
A, B, C, D, E, F, G, H
D-PEPTIDE LINKINGC5 H9 N O4

--

DLE
Query on DLE
A, B, C, D, E
A, B, C, D, E, F, G, H
D-PEPTIDE LINKINGC6 H13 N O2

--

DLY
Query on DLY
A, B, C, D, E
A, B, C, D, E, F, G, H
D-PEPTIDE LINKINGC6 H14 N2 O2

--

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.34 Å
  • R-Value Free:  0.239 (Depositor), 0.256 (DCC)
  • R-Value Work:  0.189 (Depositor), 0.201 (DCC)
  • R-Value Observed: 0.191 (Depositor)
Space Group: P 21 2 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 33.238α = 90
b = 44.976β = 90
c = 194.192γ = 90
Software Package:
Software NamePurpose
xia2data scaling
REFMACrefinement
PDB_EXTRACTdata extraction
XDSdata reduction
CRANK2phasing

Structure Validation

View Full Validation Report



Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Biotechnology and Biological Sciences Research Council (BBSRC)United KingdomBB/L01386X/1
Biotechnology and Biological Sciences Research Council (BBSRC)United KingdomBB/R00661X/1

Revision History  (Full details and data files)

  • Version 1.0: 2022-04-27
    Type: Initial release
  • Version 1.1: 2022-06-29
    Changes: Database references
  • Version 1.2: 2022-07-06
    Changes: Database references
  • Version 1.3: 2022-07-27
    Changes: Database references
