 6U5F | pdb_00006u5f

CryoEM Structure of Pyocin R2 - precontracted - collar


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.80 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

Validation slider image for 6U5F

This is version 1.2 of the entry. See complete history.

Literature

Action of a minimal contractile bactericidal nanomachine.

Ge, P., Scholl, D., Prokhorov, N.S., Avaylon, J., Shneider, M.M., Browning, C., Buth, S.A., Plattner, M., Chakraborty, U., Ding, K., Leiman, P.G., Miller, J.F., Zhou, Z.H.

(2020) Nature 580: 658-662

  • DOI: https://doi.org/10.1038/s41586-020-2186-z
  • Primary Citation Related Structures:
    5CES, 6PYT, 6U5B, 6U5F, 6U5H, 6U5J, 6U5K

  • PubMed Abstract:

    R-type bacteriocins are minimal contractile nanomachines that hold promise as precision antibiotics 1-4 . Each bactericidal complex uses a collar to bridge a hollow tube with a contractile sheath loaded in a metastable state by a baseplate scaffold 1,2 . Fine-tuning of such nucleic acid-free protein machines for precision medicine calls for an atomic description of the entire complex and contraction mechanism, which is not available from baseplate structures of the (DNA-containing) T4 bacteriophage 5 . Here we report the atomic model of the complete R2 pyocin in its pre-contraction and post-contraction states, each containing 384 subunits of 11 unique atomic models of 10 gene products. Comparison of these structures suggests the following sequence of events during pyocin contraction: tail fibres trigger lateral dissociation of baseplate triplexes; the dissociation then initiates a cascade of events leading to sheath contraction; and this contraction converts chemical energy into mechanical force to drive the iron-tipped tube across the bacterial cell surface, killing the bacterium.


  • Organizational Affiliation:
    • Department of Microbiology, Immunology and Molecular Genetics, University of California, Los Angeles (UCLA), Los Angeles, CA, USA.

Macromolecule Content

  • Total Structure Weight: 1,534.71 kDa
  • Atom Count: 107,550
  • Modeled Residue Count: 14,232
  • Deposited Residue Count: 14,298
  • Unique protein chains: 3

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Collar PA0615171Pseudomonas aeruginosa PAO1Mutation(s): 0
UniProt
Find proteins for G3XD82 (Pseudomonas aeruginosa (strain ATCC 15692 / DSM 22644 / CIP 104116 / JCM 14847 / LMG 12228 / 1C / PRS 101 / PAO1))
Explore G3XD82
Go to UniProtKB:  G3XD82
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupG3XD82
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 2
MoleculeChains  Sequence LengthOrganismDetailsImage
Sheath PA0622386Pseudomonas aeruginosa PAO1Mutation(s): 0
UniProt
Find proteins for G3XD39 (Pseudomonas aeruginosa (strain ATCC 15692 / DSM 22644 / CIP 104116 / JCM 14847 / LMG 12228 / 1C / PRS 101 / PAO1))
Explore G3XD39
Go to UniProtKB:  G3XD39
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupG3XD39
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 3
MoleculeChains  Sequence LengthOrganismDetailsImage
Tube PA0623167Pseudomonas aeruginosa PAO1Mutation(s): 0
UniProt
Find proteins for Q9I5S9 (Pseudomonas aeruginosa (strain ATCC 15692 / DSM 22644 / CIP 104116 / JCM 14847 / LMG 12228 / 1C / PRS 101 / PAO1))
Explore Q9I5S9
Go to UniProtKB:  Q9I5S9
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9I5S9
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.80 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE
EM Software:
TaskSoftware PackageVersion
MODEL REFINEMENTPHENIX1.13
RECONSTRUCTIONRELION1.4

Structure Validation

View Full Validation Report



Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesR01GM071940
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)United StatesR21AI085318
Swiss National Science FoundationSwitzerland31003A_146284
National Science Foundation (NSF, United States)United StatesXSEDE MCB140140

Revision History  (Full details and data files)

  • Version 1.0: 2020-04-15
    Type: Initial release
  • Version 1.1: 2020-05-13
    Changes: Database references
  • Version 1.2: 2024-03-20
    Changes: Data collection, Database references
