5OKI | pdb_00005oki

Crystal structure of the Ctf18-1-8 module from Ctf18-RFC in complex with a 63 kDa fragment of DNA Polymerase epsilon


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 4.50 Å
  • R-Value Free:
    0.312 (Depositor), 0.319 (DCC)
  • R-Value Work:
    0.293 (Depositor), 0.298 (DCC)
  • R-Value Observed:
    0.293 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 5OKI

This is version 1.2 of the entry. See complete history

Literature

Structural Basis for the Recruitment of Ctf18-RFC to the Replisome.

Grabarczyk, D.B.Silkenat, S.Kisker, C.

(2018) Structure 26: 137-144.e3

  • DOI: https://doi.org/10.1016/j.str.2017.11.004
  • Primary Citation Related Structures:
    5OKC, 5OKI

  • PubMed Abstract:

    Ctf18-RFC is an alternative PCNA loader which plays important but poorly understood roles in multiple DNA replication-associated processes. To fulfill its specialist roles, the Ctf18-RFC clamp loader contains a unique module in which the Dcc1-Ctf8 complex is bound to the C terminus of Ctf18 (the Ctf18-1-8 module). Here, we report the structural and functional characterization of the heterotetrameric complex formed between Ctf18-1-8 and a 63 kDa fragment of DNA polymerase ɛ. Our data reveal that Ctf18-1-8 binds stably to the polymerase and far from its other functional sites, suggesting that Ctf18-RFC could be associated with Pol ɛ throughout normal replication as the leading strand clamp loader. We also show that Pol ɛ and double-stranded DNA compete to bind the same winged-helix domain on Dcc1, with Pol ɛ being the preferred binding partner, thus suggesting that there are two alternative pathways to recruit Ctf18-RFC to sites of replication.


  • Organizational Affiliation
    • Rudolf Virchow Center for Experimental Biomedicine, Institute for Structural Biology, Josef-Schneider-Strasse 2, 97080 Würzburg, Germany. Electronic address: daniel.grabarczyk@virchow.uni-wuerzburg.de.

Macromolecule Content

  • Total Structure Weight: 244.49 kDa
  • Atom Count: 15,910
  • Modeled Residue Count: 1,967
  • Deposited Residue Count: 2,126
  • Unique protein chains: 4

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
DNA polymerase epsilon catalytic subunit A
A, B
524Saccharomyces cerevisiae S288CMutation(s): 2
Gene Names: POL2DUN2YNL262WN0825
EC: 2.7.7.7 (PDB Primary Data), 3.1.11 (UniProt)
UniProt
Find proteins for P21951 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P21951
Go to UniProtKB:  P21951
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP21951
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 2
MoleculeChains  Sequence LengthOrganismDetailsImage
Sister chromatid cohesion protein DCC1C,
F [auth G]
380Saccharomyces cerevisiae S288CMutation(s): 0
Gene Names: DCC1YCL016CYCL16C
UniProt
Find proteins for P25559 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P25559
Go to UniProtKB:  P25559
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP25559
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 3
MoleculeChains  Sequence LengthOrganismDetailsImage
Chromosome transmission fidelity protein 8D,
G [auth H]
133Saccharomyces cerevisiae S288CMutation(s): 0
Gene Names: CTF8YHR191C
UniProt
Find proteins for P38877 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P38877
Go to UniProtKB:  P38877
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP38877
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 4
MoleculeChains  Sequence LengthOrganismDetailsImage
Chromosome transmission fidelity protein 18E,
H [auth I]
26Saccharomyces cerevisiae S288CMutation(s): 0
Gene Names: CTF18CHL12YMR078CYM9582.03C
UniProt
Find proteins for P49956 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P49956
Go to UniProtKB:  P49956
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP49956
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 4.50 Å
  • R-Value Free:  0.312 (Depositor), 0.319 (DCC)
  • R-Value Work:  0.293 (Depositor), 0.298 (DCC)
  • R-Value Observed: 0.293 (Depositor)
Space Group: C 2 2 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 121.678α = 90
b = 145.826β = 90
c = 378.752γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
Aimlessdata scaling
PDB_EXTRACTdata extraction
XDSdata reduction
PHASERphasing

Structure Validation

View Full Validation Report



Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Alexander von Humboldt FoundationGermany--

Revision History  (Full details and data files)

  • Version 1.0: 2017-12-20
    Type: Initial release
  • Version 1.1: 2018-01-10
    Changes: Database references
  • Version 1.2: 2024-11-13
    Changes: Data collection, Database references, Refinement description, Structure summary
