5ZW9 | pdb_00005zw9

Crystal structure of Pyridoxal kinase (PdxK) from Salmonella typhimurium


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.60 Å
  • R-Value Free:
    0.289 (Depositor), 0.284 (DCC)
  • R-Value Work:
    0.224 (Depositor), 0.224 (DCC)
  • R-Value Observed:
    0.227 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 5ZW9

This is version 1.2 of the entry. See complete history

Literature

Structural and functional studies on Salmonella typhimurium pyridoxal kinase: the first structural evidence for the formation of Schiff base with the substrate.

Deka, G.Kalyani, J.N.Jahangir, F.B.Sabharwal, P.Savithri, H.S.Murthy, M.R.N.

(2019) FEBS J 286: 3684-3700

  • DOI: https://doi.org/10.1111/febs.14933
  • Primary Citation Related Structures:
    5ZW9, 5ZWA, 5ZWB

  • PubMed Abstract:

    A large number of enzymes depend on the ubiquitous cofactor pyridoxal 5' phosphate (PLP) for their activity. Pyridoxal kinase (PLK) is the key enzyme involved in the synthesis of PLP from the three forms of vitamin B 6 via the salvage pathway. In the present work, we determined the unliganded structure of StPLK in a monoclinic form and its ternary complex with bound pyridoxal (PL), ADP and Mg 2+ in two different tetragonal crystal forms (Form I and Form II). We found that, in the ternary complex structure of StPLK, the active site Lys233 forms a Schiff base linkage with the substrate (PL). Although formation of a Schiff base with the active site Lys229 was demonstrated in the Escherichia coli enzyme based on biochemical studies, the ternary complex of StPLK represents the first crystal structure where the Schiff bond formation has been observed. We also identified an additional site for PLP binding away from the active site in one of the ternary complexes (crystal Form I), suggesting a probable route for the product release. This is the first ternary complex structure where the modeled γ-phosphate of ATP is close enough to PL for the phosphorylation of the substrate. StPLK prefers PL over pyridoxamine as its substrate and follows a sequential mechanism of catalysis. Surface plasmon resonance studies suggest that StPLK interacts with apo-PLP-dependent enzymes with μm affinity supporting the earlier proposed direct transfer mechanism of PLP from PLK to PLP-dependent enzymes.


  • Organizational Affiliation
    • Molecular Biophysics Unit, Indian Institute of Science, Bangalore, India.

Macromolecule Content

  • Total Structure Weight: 64.89 kDa
  • Atom Count: 4,141
  • Modeled Residue Count: 526
  • Deposited Residue Count: 592
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Pyridoxalkinase
A, B
296Salmonella entericaMutation(s): 0
Gene Names: pdxK
EC: 2.7.1.35
UniProt
Find proteins for A0A0F7J8S0 (Salmonella typhimurium)
Explore A0A0F7J8S0
Go to UniProtKB:  A0A0F7J8S0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A0F7J8S0
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 5 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
PE4

Query on PE4



Download:Ideal Coordinates CCD File
I [auth B]2-{2-[2-(2-{2-[2-(2-ETHOXY-ETHOXY)-ETHOXY]-ETHOXY}-ETHOXY)-ETHOXY]-ETHOXY}-ETHANOL
C16 H34 O8
PJWQOENWHPEPKI-UHFFFAOYSA-N
PEG

Query on PEG



Download:Ideal Coordinates CCD File
F [auth A]DI(HYDROXYETHYL)ETHER
C4 H10 O3
MTHSVFCYNBDYFN-UHFFFAOYSA-N
PO4

Query on PO4



Download:Ideal Coordinates CCD File
C [auth A]PHOSPHATE ION
O4 P
NBIIXXVUZAFLBC-UHFFFAOYSA-K
EDO

Query on EDO



Download:Ideal Coordinates CCD File
E [auth A],
G [auth B],
H [auth B]
1,2-ETHANEDIOL
C2 H6 O2
LYCAIKOWRPUZTN-UHFFFAOYSA-N
MG

Query on MG



Download:Ideal Coordinates CCD File
D [auth A]MAGNESIUM ION
Mg
JLVVSXFLKOJNIY-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.60 Å
  • R-Value Free:  0.289 (Depositor), 0.284 (DCC)
  • R-Value Work:  0.224 (Depositor), 0.224 (DCC)
  • R-Value Observed: 0.227 (Depositor)
Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 65.11α = 90
b = 72.89β = 90
c = 107.52γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
iMOSFLMdata reduction
Aimlessdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Department of BiotechnologyIndiaBT/ PR7021/BRB/10/1142/2012
Department of Science and TechnologyIndiaSR/S2/ JCB-12/2005/9.5.2006

Revision History  (Full details and data files)

  • Version 1.0: 2019-05-29
    Type: Initial release
  • Version 1.1: 2019-12-11
    Changes: Database references
  • Version 1.2: 2023-11-22
    Changes: Data collection, Database references, Refinement description
