5YTI | pdb_00005yti

Crystal structure of flagellar hook associated protein-3 (HAP-3: Q5ZW61_LEGPH) from Legionella pneumophila

PDB DOI: https://doi.org/10.2210/pdb5YTI/pdb

Classification: STRUCTURAL PROTEIN
Organism(s): Legionella pneumophila subsp. pneumophila str. Philadelphia 1
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2017-11-18 Released: 2018-01-17
Deposition Author(s): Lankipalli, S., Hegde, R.P., Dey, D., Almo, S.C., Ramagopal, U.A.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.75 Å
R-Value Free:
0.288 (Depositor), 0.279 (DCC)
R-Value Work:
0.235 (Depositor), 0.229 (DCC)
R-Value Observed:
0.238 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 5YTI

This is version 1.1 of the entry. See complete history.

Literature

Crystal structure of hook associated protein-3 (HAP-3: Q5ZW61_LEGPH) from Legionella pneumophila

Lankipalli, S., Ramagopal, U.A.

To be published.

Macromolecule Content

Total Structure Weight: 45.05 kDa
Atom Count: 2,492
Modeled Residue Count: 330
Deposited Residue Count: 411
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Flagellar hook associated protein type 3 FlgL	A	411	Legionella pneumophila subsp. pneumophila str. Philadelphia 1	Mutation(s): 0 Gene Names: flgL, lpg1226
UniProt
Find proteins for Q5ZW61 (Legionella pneumophila subsp. pneumophila (strain Philadelphia 1 / ATCC 33152 / DSM 7513)) Explore Q5ZW61 Go to UniProtKB: Q5ZW61
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q5ZW61
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
CD Query on CD Download:Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	CADMIUM ION Cd WLZRMCYVCSSEQC-UHFFFAOYSA-N		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE Query on MSE	A	L-PEPTIDE LINKING	C₅ H₁₁ N O₂ Se		MET

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.75 Å
R-Value Free: 0.288 (Depositor), 0.279 (DCC)
R-Value Work: 0.235 (Depositor), 0.229 (DCC)
R-Value Observed: 0.238 (Depositor)

Space Group: P 4₂ 2₁ 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 107.687	α = 90
b = 107.687	β = 90
c = 90.248	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
SCALEPACK	data scaling
SHELXDE	phasing
PDB_EXTRACT	data extraction
HKL-2000	data reduction

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2018-01-17

Deposition Author(s):

Ramagopal, U.A.

Revision History (Full details and data files)

Version 1.0: 2018-01-17
Type: Initial release
Version 1.1: 2024-11-13
Changes: Data collection, Database references, Structure summary
