5NNR | pdb_00005nnr

Structure of Naa15/Naa10 bound to HypK-THB


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.10 Å
  • R-Value Free:
    0.272 (Depositor), 0.277 (DCC)
  • R-Value Work:
    0.230 (Depositor), 0.240 (DCC)
  • R-Value Observed:
    0.232 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 5NNR

This is version 1.2 of the entry. See complete history

Literature

Structural basis of HypK regulating N-terminal acetylation by the NatA complex.

Weyer, F.A.Gumiero, A.Lapouge, K.Bange, G.Kopp, J.Sinning, I.

(2017) Nat Commun 8: 15726-15726

  • DOI: https://doi.org/10.1038/ncomms15726
  • Primary Citation Related Structures:
    5NNP, 5NNR

  • PubMed Abstract:

    In eukaryotes, N-terminal acetylation is one of the most common protein modifications involved in a wide range of biological processes. Most N-acetyltransferase complexes (NATs) act co-translationally, with the heterodimeric NatA complex modifying the majority of substrate proteins. Here we show that the Huntingtin yeast two-hybrid protein K (HypK) binds tightly to the NatA complex comprising the auxiliary subunit Naa15 and the catalytic subunit Naa10. The crystal structures of NatA bound to HypK or to a N-terminal deletion variant of HypK were determined without or with a bi-substrate analogue, respectively. The HypK C-terminal region is responsible for high-affinity interaction with the C-terminal part of Naa15. In combination with acetylation assays, the HypK N-terminal region is identified as a negative regulator of the NatA acetylation activity. Our study provides mechanistic insights into the regulation of this pivotal protein modification.


  • Organizational Affiliation
    • Heidelberg University Biochemistry Center (BZH), INF328, D-69120 Heidelberg, Germany.

Macromolecule Content

  • Total Structure Weight: 245.09 kDa
  • Atom Count: 14,719
  • Modeled Residue Count: 1,829
  • Deposited Residue Count: 2,158
  • Unique protein chains: 3

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
N-terminal acetyltransferase-like protein
A, D
751Thermochaetoides thermophilaMutation(s): 0
Gene Names: CTHT_0031530
UniProt
Find proteins for G0S4M4 (Chaetomium thermophilum (strain DSM 1495 / CBS 144.50 / IMI 039719))
Explore G0S4M4
Go to UniProtKB:  G0S4M4
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupG0S4M4
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 2
MoleculeChains  Sequence LengthOrganismDetailsImage
Naa10
B, E
195Thermochaetoides thermophilaMutation(s): 0
Gene Names: CTHT_0063490
UniProt
Find proteins for G0SEE8 (Chaetomium thermophilum (strain DSM 1495 / CBS 144.50 / IMI 039719))
Explore G0SEE8
Go to UniProtKB:  G0SEE8
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupG0SEE8
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 3
MoleculeChains  Sequence LengthOrganismDetailsImage
HypK
C, F
133Thermochaetoides thermophilaMutation(s): 0
Gene Names: CTHT_0058830
UniProt
Find proteins for G0SCY6 (Chaetomium thermophilum (strain DSM 1495 / CBS 144.50 / IMI 039719))
Explore G0SCY6
Go to UniProtKB:  G0SCY6
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupG0SCY6
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Modified Residues  2 Unique
IDChains TypeFormula2D DiagramParent
FME
Query on FME
B, E
L-PEPTIDE LINKINGC6 H11 N O3 SMET
MSE
Query on MSE
C, F
L-PEPTIDE LINKINGC5 H11 N O2 SeMET

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.10 Å
  • R-Value Free:  0.272 (Depositor), 0.277 (DCC)
  • R-Value Work:  0.230 (Depositor), 0.240 (DCC)
  • R-Value Observed: 0.232 (Depositor)
Space Group: P 32
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 85.348α = 90
b = 85.348β = 90
c = 319.626γ = 120
Software Package:
Software NamePurpose
PHENIXrefinement
XDSdata reduction
Aimlessdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
German Research FoundationGermanyGRK1188
German Research FoundationGermanyLeibniz Program
German Research FoundationGermanyFOR967

Revision History  (Full details and data files)

  • Version 1.0: 2017-06-14
    Type: Initial release
  • Version 1.1: 2024-01-17
    Changes: Author supporting evidence, Data collection, Database references, Refinement description
  • Version 1.2: 2024-10-16
    Changes: Structure summary
