5JPG | pdb_00005jpg

Rat Galectin 5 with lactose


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.90 Å
  • R-Value Free:
    0.228 (Depositor), 0.229 (DCC)
  • R-Value Work:
    0.178 (Depositor), 0.180 (DCC)
  • R-Value Observed:
    0.180 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 5JPG

This is version 2.2 of the entry. See complete history

Literature

Structural Characterization of Rat Galectin-5, an N-Tailed Monomeric Proto-Type-like Galectin.

Ruiz, F.M.Medrano, F.J.Ludwig, A.K.Kaltner, H.Shilova, N.V.Bovin, N.V.Gabius, H.J.Romero, A.

(2021) Biomolecules 11

  • DOI: https://doi.org/10.3390/biom11121854
  • Primary Citation Related Structures:
    5JP5, 5JPG, 7P8H

  • PubMed Abstract:

    Galectins are multi-purpose effectors acting via interactions with distinct counterreceptors based on protein-glycan/protein recognition. These processes are emerging to involve several regions on the protein so that the availability of a detailed structural characterization of a full-length galectin is essential. We report here the first crystallographic information on the N-terminal extension of the carbohydrate recognition domain of rat galectin-5, which is precisely described as an N-tailed proto-type-like galectin. In the ligand-free protein, the three amino-acid stretch from Ser2 to Ser5 is revealed to form an extra β-strand (F0), and the residues from Thr6 to Asn12 are part of a loop protruding from strands S1 and F0. In the ligand-bound structure, amino acids Ser2-Tyr10 switch position and are aligned to the edge of the β-sandwich. Interestingly, the signal profile in our glycan array screening shows the sugar-binding site to preferentially accommodate the histo-blood-group B (type 2) tetrasaccharide and N-acetyllactosamine-based di- and oligomers. The crystal structures revealed the characteristically preformed structural organization around the central Trp77 of the CRD with involvement of the sequence signature's amino acids in binding. Ligand binding was also characterized calorimetrically. The presented data shows that the N-terminal extension can adopt an ordered structure and shapes the hypothesis that a ligand-induced shift in the equilibrium between flexible and ordered conformers potentially acts as a molecular switch, enabling new contacts in this region.


  • Organizational Affiliation
    • Department of Structural and Chemical Biology, CIB Margarita Salas, CSIC, Ramiro de Maeztu 9, 28040 Madrid, Spain.

Macromolecule Content

  • Total Structure Weight: 33.13 kDa
  • Atom Count: 2,538
  • Modeled Residue Count: 279
  • Deposited Residue Count: 290
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Galectin-5
A, B
145Rattus norvegicusMutation(s): 0
Gene Names: Lgals5
UniProt
Find proteins for P47967 (Rattus norvegicus)
Explore P47967
Go to UniProtKB:  P47967
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP47967
Sequence Annotations
Expand
Reference Sequence

Oligosaccharides

Help
Entity ID: 2
MoleculeChains Length2D Diagram GlycosylationD Interactions
beta-D-galactopyranose-(1-4)-alpha-D-glucopyranose
C, D
2N/A
Glycosylation Resources
GlyTouCan: G88362QR
GlyCosmos: G88362QR
GlyGen: G88362QR

Small Molecules

Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
NA

Query on NA



Download:Ideal Coordinates CCD File
E [auth A]SODIUM ION
Na
FKNQFGJONOIPTF-UHFFFAOYSA-N

Biologically Interesting Molecules (External Reference)

1 Unique

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.90 Å
  • R-Value Free:  0.228 (Depositor), 0.229 (DCC)
  • R-Value Work:  0.178 (Depositor), 0.180 (DCC)
  • R-Value Observed: 0.180 (Depositor)
Space Group: P 2 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 39.024α = 90
b = 65.763β = 90
c = 112.718γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
XDSdata reduction
XSCALEdata scaling
PHENIXphasing

Structure Validation

View Full Validation Report



Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Spanish Ministry of Science and InnovationSpainBFU2011-24615

Revision History  (Full details and data files)

  • Version 1.0: 2017-05-24
    Type: Initial release
  • Version 2.0: 2020-07-29
    Type: Remediation
    Reason: Carbohydrate remediation
    Changes: Atomic model, Data collection, Derived calculations, Non-polymer description, Structure summary
  • Version 2.1: 2022-03-02
    Changes: Database references, Structure summary
  • Version 2.2: 2024-01-10
    Changes: Data collection, Refinement description
