5H6W | pdb_00005h6w

Structure of acetyl-Coenzyme A synthase Alpha subunit C-terminal domain F598H mutant

PDB DOI: https://doi.org/10.2210/pdb5H6W/pdb

Classification: TRANSFERASE
Organism(s): Neomoorella thermoacetica
Expression System: Escherichia coli
Mutation(s): Yes

Deposited: 2016-11-15 Released: 2017-03-08
Deposition Author(s): Yuan, H.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.20 Å
R-Value Free:
0.228 (Depositor), 0.231 (DCC)
R-Value Work:
0.173 (Depositor), 0.177 (DCC)
R-Value Observed:
0.176 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 5H6W

This is version 1.1 of the entry. See complete history.

Literature

Structure of acetyl-Coenzyme A synthase Alpha subunit C-terminal domain F598H mutant

Yuan, H.

To be published.

Macromolecule Content

Total Structure Weight: 58.38 kDa
Atom Count: 3,965
Modeled Residue Count: 504
Deposited Residue Count: 540
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Carbon monoxide dehydrogenase/acetyl-CoA synthase subunit alpha	A, B, C, D	135	Neomoorella thermoacetica	Mutation(s): 1 EC: 2.3.1.169
UniProt
Find proteins for P27988 (Neomoorella thermoacetica) Explore P27988 Go to UniProtKB: P27988
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P27988
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.20 Å
R-Value Free: 0.228 (Depositor), 0.231 (DCC)
R-Value Work: 0.173 (Depositor), 0.177 (DCC)
R-Value Observed: 0.176 (Depositor)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 33.512	α = 90
b = 86.601	β = 92.15
c = 86.762	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
HKL-3000	data reduction
HKL-3000	data scaling
MOLREP	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2017-03-08

Deposition Author(s):

Revision History (Full details and data files)

Version 1.0: 2017-03-08
Type: Initial release
Version 1.1: 2023-11-08
Changes: Data collection, Database references, Refinement description
