4NOH | pdb_00004noh

1.5 Angstrom Crystal Structure of Putative Lipoprotein from Bacillus anthracis.

PDB DOI: https://doi.org/10.2210/pdb4NOH/pdb

Classification: LIPID BINDING PROTEIN
Organism(s): Bacillus anthracis
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2013-11-19 Released: 2013-12-04
Deposition Author(s): Minasov, G., Shuvalova, L., Halavaty, A., Winsor, J., Dubrovska, I., Shatsman, S., Kwon, K., Anderson, W.F., Center for Structural Genomics of Infectious Diseases (CSGID)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.50 Å
R-Value Free:
0.197 (Depositor), 0.197 (DCC)
R-Value Work:
0.161 (Depositor), 0.161 (DCC)
R-Value Observed:
0.163 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 4NOH

This is version 1.2 of the entry. See complete history.

Literature

1.5 Angstrom Crystal Structure of Putative Lipoprotein from Bacillus anthracis.

Minasov, G., Shuvalova, L., Halavaty, A., Winsor, J., Dubrovska, I., Shatsman, S., Kwon, K., Anderson, W.F., Center for Structural Genomics of Infectious Diseases (CSGID)

To be published.

Macromolecule Content

Total Structure Weight: 38.67 kDa
Atom Count: 3,108
Modeled Residue Count: 334
Deposited Residue Count: 338
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Lipoprotein, putative	A, B	169	Bacillus anthracis	Mutation(s): 0 Gene Names: BA_5634, BAS5236, GBAA_5634
UniProt
Find proteins for A0A6L8PXC8 (Bacillus anthracis) Explore A0A6L8PXC8 Go to UniProtKB: A0A6L8PXC8
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	A0A6L8PXC8
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
CL Query on CL Download:Ideal Coordinates CCD File SDF format, chain C [auth B] MOL2 format, chain C [auth B] mmCIF format, chain C [auth B]	C [auth B]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M		Interactions Focus chain C [auth B] Interactions & Density Focus chain C [auth B]

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE Query on MSE	A, B	L-PEPTIDE LINKING	C₅ H₁₁ N O₂ Se		MET

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.50 Å
R-Value Free: 0.197 (Depositor), 0.197 (DCC)
R-Value Work: 0.161 (Depositor), 0.161 (DCC)
R-Value Observed: 0.163 (Depositor)

Diffraction Data:

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 40.927	α = 90
b = 74.267	β = 91.9
c = 47.382	γ = 90

Software Package:

Software Name	Purpose
Blu-Ice	data collection
SHELXS	phasing
REFMAC	refinement
HKL-3000	data reduction
HKL-3000	data scaling

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2013-12-04

Deposition Author(s):

Center for Structural Genomics of Infectious Diseases (CSGID)

Revision History (Full details and data files)

Version 1.0: 2013-12-04
Type: Initial release
Version 1.1: 2017-11-22
Changes: Refinement description
Version 1.2: 2024-11-06
Changes: Data collection, Database references, Derived calculations, Structure summary
