3ZRI | pdb_00003zri

N-domain of ClpV from Vibrio cholerae


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.80 Å
  • R-Value Free:
    0.218 (Depositor), 0.229 (DCC)
  • R-Value Work:
    0.191 (Depositor), 0.199 (DCC)
  • R-Value Observed:
    0.193 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 3ZRI

This is version 1.3 of the entry. See complete history

Literature

Molecular Basis for the Unique Role of the Aaa+ Chaperone Clpv in Type Vi Protein Secretion.

Pietrosiuk, A.Lenherr, E.D.Falk, S.Bonemann, G.Kopp, J.Zentgraf, H.Sinning, I.Mogk, A.

(2011) J Biological Chem 286: 30010

  • DOI: https://doi.org/10.1074/jbc.M111.253377
  • Primary Citation Related Structures:
    3ZRI, 3ZRJ

  • PubMed Abstract:

    Ring-forming AAA(+) ATPases act in a plethora of cellular processes by remodeling macromolecules. The specificity of individual AAA(+) proteins is achieved by direct or adaptor-mediated association with substrates via distinct recognition domains. We investigated the molecular basis of substrate interaction for Vibrio cholerae ClpV, which disassembles tubular VipA/VipB complexes, an essential step of type VI protein secretion and bacterial virulence. We identified the ClpV recognition site within VipB, showed that productive ClpV-VipB interaction requires the oligomeric state of both proteins, solved the crystal structure of a ClpV N-domain-VipB peptide complex, and verified the interaction surface by mutant analysis. Our results show that the substrate is bound to a hydrophobic groove, which is formed by the addition of a single α-helix to the core N-domain. This helix is absent from homologous N-domains, explaining the unique substrate specificity of ClpV. A limited interaction surface between both proteins accounts for the dramatic increase in binding affinity upon ATP-driven ClpV hexamerization and VipA/VipB tubule assembly by coupling multiple weak interactions. This principle ensures ClpV selectivity toward the VipA/VipB macromolecular complex.


  • Organizational Affiliation
    • Zentrum für Molekulare Biologie Heidelberg (ZMBH), DKFZ-ZMBH Alliance, Universität Heidelberg, Heidelberg, Germany.

Macromolecule Content

  • Total Structure Weight: 19.44 kDa
  • Atom Count: 1,454
  • Modeled Residue Count: 166
  • Deposited Residue Count: 171
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
CLPB PROTEIN171Vibrio cholerae V52Mutation(s): 0

Small Molecules

Modified Residues  1 Unique
IDChains TypeFormula2D DiagramParent
MSE
Query on MSE
A
L-PEPTIDE LINKINGC5 H11 N O2 SeMET

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.80 Å
  • R-Value Free:  0.218 (Depositor), 0.229 (DCC)
  • R-Value Work:  0.191 (Depositor), 0.199 (DCC)
  • R-Value Observed: 0.193 (Depositor)
Space Group: I 2 2 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 71.898α = 90
b = 72.99β = 90
c = 73.033γ = 90
Software Package:
Software NamePurpose
REFMACrefinement

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2011-06-29
    Type: Initial release
  • Version 1.1: 2013-01-09
    Changes: Database references, Version format compliance
  • Version 1.2: 2019-05-08
    Changes: Data collection, Derived calculations, Experimental preparation, Other
  • Version 1.3: 2024-10-23
    Changes: Data collection, Database references, Other, Structure summary
