3TBO | pdb_00003tbo

Crystal structure of a type 3 CDGSH iron-sulfur protein.


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.50 Å
  • R-Value Free:
    0.222 (Depositor), 0.216 (DCC)
  • R-Value Work:
    0.196 (Depositor), 0.193 (DCC)
  • R-Value Observed:
    0.197 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 3TBO

This is version 1.2 of the entry. See complete history

Literature

Structure and Molecular Evolution of CDGSH Iron-Sulfur Domains.

Lin, J.Zhang, L.Lai, S.Ye, K.

(2011) PLoS One 6: e24790-e24790

  • DOI: https://doi.org/10.1371/journal.pone.0024790
  • Primary Citation Related Structures:
    3TBM, 3TBN, 3TBO

  • PubMed Abstract:

    The recently discovered CDGSH iron-sulfur domains (CISDs) are classified into seven major types with a wide distribution throughout the three domains of life. The type 1 protein mitoNEET has been shown to fold into a dimer with the signature CDGSH motif binding to a [2Fe-2S] cluster. However, the structures of all other types of CISDs were unknown. Here we report the crystal structures of type 3, 4, and 6 CISDs determined at 1.5 Å, 1.8 Å and 1.15 Å resolution, respectively. The type 3 and 4 CISD each contain one CDGSH motif and adopt a dimeric structure. Although similar to each other, the two structures have permutated topologies, and both are distinct from the type 1 structure. The type 6 CISD contains tandem CDGSH motifs and adopts a monomeric structure with an internal pseudo dyad symmetry. All currently known CISD structures share dual iron-sulfur binding modules and a β-sandwich for either intermolecular or intramolecular dimerization. The iron-sulfur binding module, the β-strand N-terminal to the module and a proline motif are conserved among different type structures, but the dimerization module and the interface and orientation between the two iron-sulfur binding modules are divergent. Sequence analysis further shows resemblance between CISD types 4 and 7 and between 1 and 2. Our findings suggest that all CISDs share common ancestry and diverged into three primary folds with a characteristic phylogenetic distribution: a eukaryote-specific fold adopted by types 1 and 2 proteins, a prokaryote-specific fold adopted by types 3, 4 and 7 proteins, and a tandem-motif fold adopted by types 5 and 6 proteins. Our comprehensive structural, sequential and phylogenetic analysis provides significant insight into the assembly principles and evolutionary relationship of CISDs.


  • Organizational Affiliation
    • National Institute of Biological Sciences, Beijing, China.

Macromolecule Content

  • Total Structure Weight: 6.75 kDa
  • Atom Count: 462
  • Modeled Residue Count: 54
  • Deposited Residue Count: 60
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Zinc finger, CDGSH-type domain protein60Pyrobaculum calidifontis JCM 11548Mutation(s): 0
Gene Names: Pcal_1411
UniProt
Find proteins for A3MW14 (Pyrobaculum calidifontis (strain DSM 21063 / JCM 11548 / VA1))
Explore A3MW14
Go to UniProtKB:  A3MW14
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA3MW14
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
FES

Query on FES



Download:Ideal Coordinates CCD File
B [auth A]FE2/S2 (INORGANIC) CLUSTER
Fe2 S2
NIXDOXVAJZFRNF-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.50 Å
  • R-Value Free:  0.222 (Depositor), 0.216 (DCC)
  • R-Value Work:  0.196 (Depositor), 0.193 (DCC)
  • R-Value Observed: 0.197 (Depositor)
Space Group: P 31 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 49.903α = 90
b = 49.903β = 90
c = 46.076γ = 120
Software Package:
Software NamePurpose
HKL-2000data collection
SHARPphasing
PHASERphasing
REFMACrefinement
HKL-2000data reduction
SCALEPACKdata scaling

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2011-10-05
    Type: Initial release
  • Version 1.1: 2011-10-12
    Changes: Database references
  • Version 1.2: 2024-03-20
    Changes: Data collection, Database references, Derived calculations
