3S7Z | pdb_00003s7z

Crystal Structure of Putative Aspartate Racemase from Salmonella Typhimurium Complexed with Succinate

PDB DOI: https://doi.org/10.2210/pdb3S7Z/pdb

Classification: ISOMERASE
Organism(s): Salmonella enterica subsp. enterica serovar Typhimurium str. LT2
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2011-05-27 Released: 2011-10-05
Deposition Author(s): Maltseva, N., Zhang, R., Kwon, K., Anderson, W.F., Joachimiak, A., Center for Structural Genomics of Infectious Diseases (CSGID)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.00 Å
R-Value Free:
0.185 (Depositor), 0.185 (DCC)
R-Value Work:
0.148 (Depositor), 0.147 (DCC)
R-Value Observed:
0.150 (Depositor)

wwPDB Validation 3D Report Full Report

This is version 2.1 of the entry. See complete history.

Literature

Crystal Structure of Putative Aspartate Racemase from Salmonella Typhimurium Complexed with Succinate.

Maltseva, N., Zhang, R., Kwon, K., Anderson, W.F., Joachimiak, A., Center for Structural Genomics of Infectious Diseases (CSGID)

To be published.

Macromolecule Content

Total Structure Weight: 59.7 kDa
Atom Count: 4,141
Modeled Residue Count: 468
Deposited Residue Count: 536
Unique protein chains: 1

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Putative aspartate racemase	A, B	268	Salmonella enterica subsp. enterica serovar Typhimurium str. LT2	Mutation(s): 0 Gene Names: STM4510
UniProt
Find proteins for Q8ZJZ9 (Salmonella typhimurium (strain LT2 / SGSC1412 / ATCC 700720)) Explore Q8ZJZ9 Go to UniProtKB: Q8ZJZ9
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q8ZJZ9
Sequence Annotations Expand
Reference Sequence

Oligosaccharides

Help

Entity ID: 2
Molecule	Chains	Length	2D Diagram	Glycosylation	D Interactions
beta-D-fructofuranose-(2-1)-alpha-D-glucopyranose	C	2		N/A	Interactions Focus chain C Interactions & Density Focus chain C
Glycosylation Resources
GlyTouCan: G05551OP GlyCosmos: G05551OP

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
SIN Query on SIN Download:Ideal Coordinates CCD File SDF format, chain F [auth B] SDF format, chain D [auth A] MOL2 format, chain F [auth B] MOL2 format, chain D [auth A] mmCIF format, chain F [auth B] mmCIF format, chain D [auth A]	D [auth A], F [auth B]	SUCCINIC ACID C₄ H₆ O₄ KDYFGRWQOYBRFD-UHFFFAOYSA-N		Interactions Focus chain D [auth A] Focus chain F [auth B] Interactions & Density Focus chain D [auth A] Focus chain F [auth B]
MG Query on MG Download:Ideal Coordinates CCD File SDF format, chain E [auth B] MOL2 format, chain E [auth B] mmCIF format, chain E [auth B]	E [auth B]	MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N		Interactions Focus chain E [auth B] Interactions & Density Focus chain E [auth B]

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE Query on MSE	A, B	L-PEPTIDE LINKING	C₅ H₁₁ N O₂ Se		MET

Biologically Interesting Molecules (External Reference)

1 Unique

Entity ID: 2
ID	Chains	Name	Type/Class	2D Diagram	3D Interactions
PRD_900003 Query on PRD_900003	C	sucrose	Oligosaccharide / Nutrient		Interactions Focus chain C Interactions & Density Focus chain C

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.00 Å
R-Value Free: 0.185 (Depositor), 0.185 (DCC)
R-Value Work: 0.148 (Depositor), 0.147 (DCC)
R-Value Observed: 0.150 (Depositor)

Diffraction Data:

Space Group: P 6₅

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 84.826	α = 90
b = 84.826	β = 90
c = 114.127	γ = 120

Software Package:

Software Name	Purpose
SBC-Collect	data collection
HKL-3000	data collection
HKL-3000	phasing
SHELX	model building
RESOLVE	model building
BUCCANEER	model building
PHENIX	refinement
HKL-3000	data reduction
HKL-3000	data scaling
SHELX	phasing
RESOLVE	phasing
BUCCANEER	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2011-10-05

Deposition Author(s):

Center for Structural Genomics of Infectious Diseases (CSGID)

Revision History (Full details and data files)

Version 1.0: 2011-10-05
Type: Initial release
Version 1.1: 2017-11-08
Changes: Advisory, Refinement description
Version 2.0: 2020-07-29
Type: Remediation
Reason: Carbohydrate remediation
Changes: Atomic model, Data collection, Database references, Derived calculations, Non-polymer description, Structure summary
Version 2.1: 2024-10-16
Changes: Advisory, Data collection, Database references, Structure summary
