3PM5 | pdb_00003pm5

Crystal Structure of BoxB in mixed valent state with bound benzoyl-CoA


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.30 Å
  • R-Value Free:
    0.224 (Depositor)
  • R-Value Work:
    0.174 (Depositor)
  • R-Value Observed:
    0.177 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 3PM5

Ligand Structure Quality Assessment


This is version 1.4 of the entry. See complete history

Literature

Structure and Mechanism of the Diiron Benzoyl-Coenzyme A Epoxidase BoxB.

Rather, L.J.Weinert, T.Demmer, U.Bill, E.Ismail, W.Fuchs, G.Ermler, U.

(2011) J Biological Chem 286: 29241-29248

  • DOI: https://doi.org/10.1074/jbc.M111.236893
  • Primary Citation Related Structures:
    3PER, 3PF7, 3PM5, 3Q1G

  • PubMed Abstract:

    The coenzyme A (CoA)-dependent aerobic benzoate metabolic pathway uses an unprecedented chemical strategy to overcome the high aromatic resonance energy by forming the non-aromatic 2,3-epoxybenzoyl-CoA. The crucial dearomatizing reaction is catalyzed by three enzymes, BoxABC, where BoxA is an NADPH-dependent reductase, BoxB is a benzoyl-CoA 2,3-epoxidase, and BoxC is an epoxide ring hydrolase. We characterized the key enzyme BoxB from Azoarcus evansii by structural and Mössbauer spectroscopic methods as a new member of class I diiron enzymes. Several family members were structurally studied with respect to the diiron center architecture, but no structure of an intact diiron enzyme with its natural substrate has been reported. X-ray structures between 1.9 and 2.5 Å resolution were determined for BoxB in the diferric state and with bound substrate benzoyl-CoA in the reduced state. The substrate-bound reduced state is distinguished from the diferric state by increased iron-ligand distances and the absence of directly bridging groups between them. The position of benzoyl-CoA inside a 20 Å long channel and the position of the phenyl ring relative to the diiron center are accurately defined. The C2 and C3 atoms of the phenyl ring are closer to one of the irons. Therefore, one oxygen of activated O(2) must be ligated predominantly to this proximate iron to be in a geometrically suitable position to attack the phenyl ring. Consistent with the observed iron/phenyl geometry, BoxB stereoselectively should form the 2S,3R-epoxide. We postulate a reaction cycle that allows a charge delocalization because of the phenyl ring and the electron-withdrawing CoA thioester.


  • Organizational Affiliation
    • Mikrobiologie, Institut für Biologie II, Universität Freiburg, Schänzlestrasse 1, D-79104 Freiburg.

Macromolecule Content

  • Total Structure Weight: 228.06 kDa
  • Atom Count: 16,504
  • Modeled Residue Count: 1,886
  • Deposited Residue Count: 1,924
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Benzoyl-CoA oxygenase component B
A, B, C, D
481Aromatoleum evansiiMutation(s): 0
Gene Names: Azoarcus evansiiboxB
EC: 1.14.12.21 (PDB Primary Data), 1.14.13.208 (UniProt)
UniProt
Find proteins for Q9AIX7 (Aromatoleum evansii)
Explore Q9AIX7
Go to UniProtKB:  Q9AIX7
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9AIX7
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 7 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
BYC

Query on BYC



Download:Ideal Coordinates CCD File
HA [auth D],
M [auth A],
R [auth B],
Z [auth C]
benzoyl coenzyme A
C28 H40 N7 O17 P3 S
VEVJTUNLALKRNO-TYHXJLICSA-N
PGE

Query on PGE



Download:Ideal Coordinates CCD File
GA [auth D]TRIETHYLENE GLYCOL
C6 H14 O4
ZIBGPFATKBEMQZ-UHFFFAOYSA-N
SO4

Query on SO4



Download:Ideal Coordinates CCD File
AA [auth D]
E [auth A]
G [auth A]
I [auth A]
T [auth C]
AA [auth D],
E [auth A],
G [auth A],
I [auth A],
T [auth C],
V [auth C],
W [auth C]
SULFATE ION
O4 S
QAOWNCQODCNURD-UHFFFAOYSA-L
GOL

Query on GOL



Download:Ideal Coordinates CCD File
FA [auth D],
Y [auth C]
GLYCEROL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
PGO

Query on PGO



Download:Ideal Coordinates CCD File
EA [auth D],
L [auth A],
O [auth B],
Q [auth B]
S-1,2-PROPANEDIOL
C3 H8 O2
DNIAPMSPPWPWGF-VKHMYHEASA-N
FE

Query on FE



Download:Ideal Coordinates CCD File
BA [auth D]
DA [auth D]
F [auth A]
H [auth A]
N [auth B]
BA [auth D],
DA [auth D],
F [auth A],
H [auth A],
N [auth B],
P [auth B],
S [auth C],
U [auth C]
FE (III) ION
Fe
VTLYFUHAOXGGBS-UHFFFAOYSA-N
CL

Query on CL



Download:Ideal Coordinates CCD File
CA [auth D],
J [auth A],
K [auth A],
X [auth C]
CHLORIDE ION
Cl
VEXZGXHMUGYJMC-UHFFFAOYSA-M

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.30 Å
  • R-Value Free:  0.224 (Depositor)
  • R-Value Work:  0.174 (Depositor)
  • R-Value Observed: 0.177 (Depositor)
Space Group: C 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 208.18α = 90
b = 76.65β = 108.34
c = 148.2γ = 90
Software Package:
Software NamePurpose
PHASERphasing
REFMACrefinement
XDSdata reduction
XDSdata scaling

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2011-06-01
    Type: Initial release
  • Version 1.1: 2011-07-13
    Changes: Version format compliance
  • Version 1.2: 2011-09-14
    Changes: Database references
  • Version 1.3: 2017-11-08
    Changes: Refinement description
  • Version 1.4: 2024-02-21
    Changes: Data collection, Database references, Derived calculations
