3LDJ | pdb_00003ldj

Crystal structure of aprotinin in complex with sucrose octasulfate: unusual interactions and implication for heparin binding


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.70 Å
  • R-Value Free:
    0.234 (Depositor), 0.237 (DCC)
  • R-Value Work:
    0.190 (Depositor), 0.190 (DCC)
  • R-Value Observed:
    0.192 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 3LDJ

This is version 2.2 of the entry. See complete history

Literature

Crystal structures of aprotinin and its complex with sucrose octasulfate reveal multiple modes of interactions with implications for heparin binding.

Yang, I.S.Kim, T.G.Park, B.S.Cho, K.J.Lee, J.H.Park, Y.Kim, K.H.

(2010) Biochem Biophys Res Commun

  • DOI: https://doi.org/10.1016/j.bbrc.2010.05.113
  • Primary Citation Related Structures:
    3LDI, 3LDJ, 3LDM

  • PubMed Abstract:

    The crystal structures of aprotinin and its complex with sucrose octasulfate (SOS), a polysulfated heparin analog, were determined at 1.7-2.6A resolutions. Aprotinin is monomeric in solution, which associates into a decamer at high salt concentrations. Sulfate ions serve to neutralize the basic amino acid residues of aprotinin to stabilize the decameric aprotinin. Whereas SOS interacts with heparin binding proteins at 1:1 molar ratio, SOS was surprisingly found to induce strong agglutination of aprotinins. Five molecules of aprotinin interact with one molecule of the sulfated sugar, which is stabilized by electrostatic interactions between the positively charged residues of aprotinin and sulfate groups of SOS. The multiple binding modes of SOS with five individual aprotinin molecules may represent the diverse patterns of potential heparin binding to aprotinin, reflecting the interactions of densely packed protein molecules along the heparin polymer.


  • Organizational Affiliation
    • Department of Biotechnology & Bioinformatics, Korea University, Chungnam 339-700, Republic of Korea.

Macromolecule Content

  • Total Structure Weight: 20.62 kDa
  • Atom Count: 1,611
  • Modeled Residue Count: 168
  • Deposited Residue Count: 174
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Pancreatic trypsin inhibitor
A, B, C
58Bos taurusMutation(s): 0
UniProt
Find proteins for P00974 (Bos taurus)
Explore P00974
Go to UniProtKB:  P00974
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP00974
Sequence Annotations
Expand
Reference Sequence

Oligosaccharides

Help
Entity ID: 2
MoleculeChains Length2D Diagram GlycosylationD Interactions
1,3,4,6-tetra-O-sulfo-beta-D-fructofuranose-(2-1)-2,3,4,6-tetra-O-sulfonato-alpha-D-glucopyranose
D
2N/A
Glycosylation Resources
GlyTouCan: G97555GV
GlyCosmos: G97555GV

Small Molecules

Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
ACT

Query on ACT



Download:Ideal Coordinates CCD File
E [auth C]ACETATE ION
C2 H3 O2
QTBSBXVTEAMEQO-UHFFFAOYSA-M

Biologically Interesting Molecules (External Reference)

1 Unique

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.70 Å
  • R-Value Free:  0.234 (Depositor), 0.237 (DCC)
  • R-Value Work:  0.190 (Depositor), 0.190 (DCC)
  • R-Value Observed: 0.192 (Depositor)
Space Group: C 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 116.947α = 90
b = 31.003β = 116.911
c = 52.543γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
PDB_EXTRACTdata extraction
HKL-2000data collection
HKL-2000data reduction
HKL-2000data scaling
MOLREPphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2010-09-15
    Type: Initial release
  • Version 1.1: 2011-07-13
    Changes: Version format compliance
  • Version 2.0: 2020-07-29
    Type: Remediation
    Reason: Carbohydrate remediation
    Changes: Atomic model, Data collection, Derived calculations, Non-polymer description, Structure summary
  • Version 2.1: 2024-10-30
    Changes: Data collection, Database references, Structure summary
  • Version 2.2: 2025-05-07
    Changes: Advisory, Other
