3H5G | pdb_00003h5g

Switching the Chirality of the Metal Environment Alters the Coordination Mode in Designed Peptides.

• PDB DOI: https://doi.org/10.2210/pdb3H5G/pdb

• Classification: DE NOVO PROTEIN
• Mutation(s): No


• Deposited: 2009-04-22 Released: 2009-07-14
• Deposition Author(s): Peacock, A.F.A., Stuckey, J.A., Pecoraro, V.L.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.71 Å
• R-Value Free:
  0.224 (Depositor), 0.235 (DCC)
• R-Value Work:
  0.181 (Depositor), 0.187 (DCC)
• R-Value Observed:
  0.183 (Depositor)

Starting Model: experimental

Literature

Switching the Chirality of the Metal Environment Alters the Coordination Mode in Designed Peptides.

Peacock, A.F., Stuckey, J.A., Pecoraro, V.L.

(2009) Angew Chem Int Ed Engl 48: 7371-7374

• PubMed: 19579245
• DOI: https://doi.org/10.1002/anie.200902166
• Primary Citation Related Structures:
  3H5F, 3H5G


• PubMed Abstract:


  The effects of switching the chirality of a single layer of amino acids in a three stranded coiled coil has been investigated. X-ray crystallography reveals that this modification is well tolerated and does not alter the designed structure. In contrast, spectroscopic studies of cadmium binding to both the L- and D- enantiomers of the penicillamine, provide evidence that this switch dramatically alters the metal binding capability, the resulting coordination environment and the position of binding.

---

Organizational Affiliation:
• Department of Chemistry, University of Michigan, Ann Arbor, MI 48109, USA.

Biological Assembly 1

Global Symmetry: Cyclic - C3  (Explore in 3D)
Global Stoichiometry: Homo 3-mer - A3

Biological assembly 1 assigned by authors.

Macromolecule Content

• Total Structure Weight: 10.58 kDa
• Atom Count: 790
• Modeled Residue Count: 93
• Deposited Residue Count: 93
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
COIL SER L16D-Pen	A, B, C	31	N/A	Mutation(s): 0

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
ZN	D [auth A], E [auth A], F [auth A], G [auth A], H [auth A], I [auth B], J [auth C]	ZINC ION Zn PTFCDOFLOPIGGS-UHFFFAOYSA-N
ACT	K [auth C]	ACETATE ION C2 H3 O2 QTBSBXVTEAMEQO-UHFFFAOYSA-M

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.71 Å
• R-Value Free:  0.224 (Depositor), 0.235 (DCC)
• R-Value Work:  0.181 (Depositor), 0.187 (DCC)
• R-Value Observed: 0.183 (Depositor)

Space Group: C 1 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 76.723	α = 90
b = 29.237	β = 119.6
c = 44.385	γ = 90

Software Package:

Software Name	Purpose
DENZO	data reduction
SCALEPACK	data scaling
PHASER	phasing
REFMAC	refinement
PDB_EXTRACT	data extraction
HKL-2000	data reduction

Structure Validation

Entry History

Deposition Data

• Released Date: 2009-07-14
Deposition Author(s): Peacock, A.F.A., Stuckey, J.A., Pecoraro, V.L.

Revision History

• Version 1.0: 2009-07-14
  Type: Initial release

• Version 1.1: 2011-07-13
  Changes: Advisory, Version format compliance
• Version 1.2: 2017-11-01
  Changes: Advisory, Refinement description
• Version 1.3: 2023-09-06
  Changes: Advisory, Data collection, Database references, Derived calculations, Refinement description
• Version 1.4: 2023-11-22
  Changes: Data collection
