3ELK | pdb_00003elk

Crystal structure of putative transcriptional regulator TA0346 from Thermoplasma acidophilum

PDB DOI: https://doi.org/10.2210/pdb3ELK/pdb

Classification: transcription regulator
Organism(s): Thermoplasma acidophilum
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2008-09-22 Released: 2008-09-30
Deposition Author(s): Grantz Saskova, K., Chruszcz, M., Evdokimova, E., Egorova, O., Savchenko, A., Edwards, A., Joachimiak, A., Minor, W., Midwest Center for Structural Genomics (MCSG)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.70 Å
R-Value Free:
0.241 (Depositor), 0.251 (DCC)
R-Value Work:
0.202 (Depositor), 0.207 (DCC)
R-Value Observed:
0.204 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 3ELK

This is version 1.2 of the entry. See complete history.

Literature

Crystal structure of putative transcriptional regulator TA0346 from Thermoplasma acidophilum

Grantz Saskova, K., Chruszcz, M., Evdokimova, E., Egorova, O., Savchenko, A., Edwards, A., Joachimiak, A., Minor, W.

To be published.

Macromolecule Content

Total Structure Weight: 27.33 kDa
Atom Count: 1,761
Modeled Residue Count: 208
Deposited Residue Count: 234
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Putative transcriptional regulator TA0346	A, B	117	Thermoplasma acidophilum	Mutation(s): 0 Gene Names: Ta0346
UniProt
Find proteins for Q9HL84 (Thermoplasma acidophilum (strain ATCC 25905 / DSM 1728 / JCM 9062 / NBRC 15155 / AMRC-C165)) Explore Q9HL84 Go to UniProtKB: Q9HL84
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q9HL84
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
CL Query on CL Download:Ideal Coordinates CCD File SDF format, chain D [auth B] SDF format, chain C [auth A] MOL2 format, chain D [auth B] MOL2 format, chain C [auth A] mmCIF format, chain D [auth B] mmCIF format, chain C [auth A]	C [auth A], D [auth B]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M		Interactions Focus chain C [auth A] Focus chain D [auth B] Interactions & Density Focus chain C [auth A] Focus chain D [auth B]

Modified Residues 2 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE Query on MSE	A, B	L-PEPTIDE LINKING	C₅ H₁₁ N O₂ Se		MET
OCS Query on OCS	A, B	L-PEPTIDE LINKING	C₃ H₇ N O₅ S		CYS

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.70 Å
R-Value Free: 0.241 (Depositor), 0.251 (DCC)
R-Value Work: 0.202 (Depositor), 0.207 (DCC)
R-Value Observed: 0.204 (Depositor)

Space Group: C 2 2 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 42.515	α = 90
b = 45.707	β = 90
c = 207.679	γ = 90

Software Package:

Software Name	Purpose
HKL-2000	data collection
HKL-3000	phasing
MLPHARE	phasing
DM	model building
SHELXD	phasing
SHELXE	model building
RESOLVE	model building
ARP/wARP	model building
CCP4	model building
REFMAC	refinement
Coot	model building
HKL-3000	data reduction
HKL-3000	data scaling
DM	phasing
RESOLVE	phasing
CCP4	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2008-09-30

Deposition Author(s):

Grantz Saskova, K.

Midwest Center for Structural Genomics (MCSG)

Revision History (Full details and data files)

Version 1.0: 2008-09-30
Type: Initial release
Version 1.1: 2011-07-13
Changes: Advisory, Version format compliance
Version 1.2: 2022-04-13
Changes: Database references, Derived calculations, Structure summary
