2QUY | pdb_00002quy

Truncated mutant ASN175ALA of penicillin v acylase from bacillus sphaericus

PDB DOI: https://doi.org/10.2210/pdb2QUY/pdb

Classification: HYDROLASE
Organism(s): Lysinibacillus sphaericus
Expression System: Escherichia coli
Mutation(s): Yes

Deposited: 2007-08-07 Released: 2008-08-26
Deposition Author(s): Pathak, M.C., Brannigan, J., Dodson, G.G., Suresh, C.G.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.70 Å
R-Value Free:
0.203 (Depositor), 0.204 (DCC)
R-Value Work:
0.175 (Depositor), 0.178 (DCC)
R-Value Observed:
0.177 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 2QUY

This is version 1.3 of the entry. See complete history.

Literature

Auto-proteolytic processing of Penicillin V Acylase is simpler than of other related Ntn hydrolases

Pathak, M.C., Brannigan, J., Dodson, G.G., Suresh, C.G.

To be published.

Macromolecule Content

Total Structure Weight: 297.9 kDa
Atom Count: 21,995
Modeled Residue Count: 2,637
Deposited Residue Count: 2,680
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Penicillin acylase	A, B, C, D, E A, B, C, D, E, F, G, H	335	N/A	Mutation(s): 1 EC: 3.5.1.11
UniProt
Find proteins for P12256 (Lysinibacillus sphaericus) Explore P12256 Go to UniProtKB: P12256
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P12256
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
CL Query on CL Download:Ideal Coordinates CCD File SDF format, chain P [auth H] SDF format, chain O [auth G] SDF format, chain N [auth E] SDF format, chain M [auth E] SDF format, chain L [auth C] SDF format, chain K [auth C] SDF format, chain J [auth B] SDF format, chain I [auth A] MOL2 format, chain P [auth H] MOL2 format, chain O [auth G] MOL2 format, chain N [auth E] MOL2 format, chain M [auth E] MOL2 format, chain L [auth C] MOL2 format, chain K [auth C] MOL2 format, chain J [auth B] MOL2 format, chain I [auth A] mmCIF format, chain P [auth H] mmCIF format, chain O [auth G] mmCIF format, chain N [auth E] mmCIF format, chain M [auth E] mmCIF format, chain L [auth C] mmCIF format, chain K [auth C] mmCIF format, chain J [auth B] mmCIF format, chain I [auth A]	I [auth A] J [auth B] K [auth C] L [auth C] M [auth E] I [auth A], J [auth B], K [auth C], L [auth C], M [auth E], N [auth E], O [auth G], P [auth H]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M		Interactions Focus chain I [auth A] Focus chain J [auth B] Focus chain K [auth C] Focus chain L [auth C] Focus chain M [auth E] Focus chain N [auth E] Focus chain O [auth G] Focus chain P [auth H] Interactions & Density Focus chain I [auth A] Focus chain J [auth B] Focus chain K [auth C] Focus chain L [auth C] Focus chain M [auth E] Focus chain N [auth E] Focus chain O [auth G] Focus chain P [auth H]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.70 Å
R-Value Free: 0.203 (Depositor), 0.204 (DCC)
R-Value Work: 0.175 (Depositor), 0.178 (DCC)
R-Value Observed: 0.177 (Depositor)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 47.286	α = 90
b = 379.383	β = 93.51
c = 102.013	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
DENZO	data reduction
SCALEPACK	data scaling
AMoRE	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2008-08-26

Deposition Author(s):

Revision History (Full details and data files)

Version 1.0: 2008-08-26
Type: Initial release
Version 1.1: 2011-07-13
Changes: Version format compliance
Version 1.2: 2021-11-10
Changes: Database references, Derived calculations
Version 1.3: 2024-05-29
Changes: Data collection
