27TM | pdb_000027tm

GRM1-Acc State Conformation 2


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.20 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

Validation slider image for 27TM

This is version 1.2 of the entry. See complete history

Literature

G protein selectivity in group I metabotropic glutamate receptors.

Lu, Y.Wen, T.Lu, X.Zhang, G.Meng, T.Liu, T.Wang, X.Shen, Y.Yang, X.

(2026) Sci Adv 12: eaee0044-eaee0044

  • DOI: https://doi.org/10.1126/sciadv.aee0044
  • Primary Citation Related Structures:
    27TM, 9WQK, 9WQL, 9WQM, 9WQN, 9WQO

  • PubMed Abstract:

    Metabotropic glutamate (mGlu) receptors are class C G protein-coupled receptor involved in synaptic transmission and neurological disorders. Group I mGlu receptors (mGlu1 and mGlu5) predominantly couple to G q/11 , whereas group II and III receptors primarily engage G i/o . Although G i/o -coupling mechanisms have been defined for several group II/III receptors, how group I receptors preferentially engage G q/11 remains unclear. Here we report cryo-electron microscopy structures of active mGlu-G protein complexes (mGlu1-G q , mGlu1-G i , mGlu5-G q , and mGlu5-G i ) bound to l-glutamate and positive allosteric modulators (PAMs), together with two additional activated-state structures of mGlu1. Comparative structural and biochemical analyses identify a group I-specific ICL2 insertion that promotes preferential G q engagement. Each receptor dimer asymmetrically binds one G protein heterotrimer via an intracellular pocket engaging the Gα amino-terminal helix. PAM binding to one 7TM domain induces W 6.50 rotation and TM6 outward movement, bringing the two 7TMs into closer. These findings provide a structural basis for preferential G q/11 engagement and activation of group I mGlu receptors.


  • Organizational Affiliation
    • State Key Laboratory of Medicinal Chemical Biology and Frontiers Science Center for Cell Responses, College of Life Sciences, Nankai University, Tianjin 300350, China.

Macromolecule Content

  • Total Structure Weight: 197.91 kDa
  • Atom Count: 12,432
  • Modeled Residue Count: 1,555
  • Deposited Residue Count: 1,738
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Metabotropic glutamate receptor 1A [auth X],
B [auth Y]
869Homo sapiensMutation(s): 0
Gene Names: GRM1GPRC1AMGLUR1
UniProt & NIH Common Fund Data Resources
Find proteins for Q13255 (Homo sapiens)
Explore Q13255
Go to UniProtKB:  Q13255
GTEx:  ENSG00000152822
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ13255
Glycosylation
Glycosylation Sites: 3Go to GlyGen: Q13255-1
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 5 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
CLR

Query on CLR



Download:Ideal Coordinates CCD File
I [auth X],
Q [auth Y]
CHOLESTEROL
C27 H46 O
HVYWMOMLDIMFJA-DPAQBDIFSA-N
A1EX5

Query on A1EX5



Download:Ideal Coordinates CCD File
J [auth X]N-[4-(trifluoromethyl)-1,3-oxazol-2-yl]-9H-xanthene-9-carboxamide
C18 H11 F3 N2 O3
GSGDLBUOSWGZER-UHFFFAOYSA-N
NAG

Query on NAG



Download:Ideal Coordinates CCD File
D [auth X]
E [auth X]
F [auth X]
G [auth X]
L [auth Y]
D [auth X],
E [auth X],
F [auth X],
G [auth X],
L [auth Y],
M [auth Y],
N [auth Y],
O [auth Y]
2-acetamido-2-deoxy-beta-D-glucopyranose
C8 H15 N O6
OVRNDRQMDRJTHS-FMDGEEDCSA-N
GGL

Query on GGL



Download:Ideal Coordinates CCD File
C [auth X],
K [auth Y]
GAMMA-L-GLUTAMIC ACID
C5 H9 N O4
WHUUTDBJXJRKMK-VKHMYHEASA-N
CL

Query on CL



Download:Ideal Coordinates CCD File
H [auth X],
P [auth Y]
CHLORIDE ION
Cl
VEXZGXHMUGYJMC-UHFFFAOYSA-M

Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.20 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE
EM Software:
TaskSoftware PackageVersion
MODEL REFINEMENTPHENIX1.19_4092
RECONSTRUCTIONRELION5

Structure Validation

View Full Validation Report



Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Natural Science Foundation of China (NSFC)China--

Revision History  (Full details and data files)

  • Version 1.0: 2026-06-24
    Type: Initial release
  • Version 1.1: 2026-07-01
    Changes: Data collection
  • Version 1.2: 2026-07-22
    Changes: Data collection, Database references
