9TLC | pdb_00009tlc

Cryo-EM Structure of the oligomeric LPOR:Chlide:NADPH Complexes RF-25

PDB DOI: https://doi.org/10.2210/pdb9TLC/pdb
EM Map EMD-56049: EMDB EMDataResource

Classification: PHOTOSYNTHESIS
Organism(s): Arabidopsis thaliana
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2025-12-10 Released: 2026-08-19
Deposition Author(s): Gabruk, M., Desfosses, A., Estrozi, L.F., Pintscher, S., Rawski, M.
Funding Organization(s): Polish National Science Centre

Experimental Data Snapshot

Method: ELECTRON MICROSCOPY
Resolution: 3.20 Å
Aggregation State: HELICAL ARRAY
Reconstruction Method: HELICAL

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 9TLC

This is version 1.0 of the entry. See complete history.

Literature

Cryo-EM Structure of the LPOR:Chlide:NADPH Complexes - improved resolution of a dimer building block form RF-25

Gabruk, M., Desfosses, A., Estrozi, L.F., Pintscher, S., Rawski, M., Wazny, G., Garbacz, A., Zbyradowski, M., Kruk, J., Fiedor, L.

To be published.

Macromolecule Content

Total Structure Weight: 1,938.43 kDa
Atom Count: 122,544
Modeled Residue Count: 15,264
Deposited Residue Count: 16,944
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Protochlorophyllide reductase B, chloroplastic	A [auth YE] AA [auth ZE] B [auth YF] BA [auth ZF] C [auth YG] A [auth YE], AA [auth ZE], B [auth YF], BA [auth ZF], C [auth YG], CA [auth ZG], D [auth YH], DA [auth ZH], E [auth YI], EA [auth ZI], F [auth YJ], FA [auth ZJ], G [auth YK], GA [auth ZK], H [auth YL], HA [auth ZL], I [auth YM], IA [auth ZM], J [auth YN], JA [auth ZN], K [auth YO], KA [auth ZO], L [auth YP], LA [auth ZP], M [auth YQ], MA [auth ZQ], N [auth YR], NA [auth ZR], O [auth YS], OA [auth ZS], P [auth YT], PA [auth ZT], Q [auth YU], QA [auth ZU], R [auth YV], RA [auth ZV], S [auth YW], SA [auth ZW], T [auth YX], TA [auth ZX], U [auth YY], UA [auth ZY], V [auth YZ], VA [auth ZZ], W [auth ZA], X [auth ZB], Y [auth ZC], Z [auth ZD]	353	Arabidopsis thaliana	Mutation(s): 0 Gene Names: PORB, At4g27440, F27G19.40 EC: 1.3.1.33
UniProt
Find proteins for P21218 (Arabidopsis thaliana) Explore P21218 Go to UniProtKB: P21218
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P21218
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
LMG (Subject of Investigation/LOI) Query on LMG Download:Ideal Coordinates CCD File SDF format, chain AB [auth YF] SDF format, chain AE [auth ZF] SDF format, chain BC [auth YO] SDF format, chain BF [auth ZO] SDF format, chain CD [auth YX] SDF format, chain CG [auth ZX] SDF format, chain DB [auth YG] SDF format, chain DE [auth ZG] SDF format, chain EC [auth YP] SDF format, chain EF [auth ZP] SDF format, chain FD [auth YY] SDF format, chain FG [auth ZY] SDF format, chain GB [auth YH] SDF format, chain GE [auth ZH] SDF format, chain HC [auth YQ] SDF format, chain HF [auth ZQ] SDF format, chain ID [auth YZ] SDF format, chain IG [auth ZZ] SDF format, chain JB [auth YI] SDF format, chain JE [auth ZI] SDF format, chain KC [auth YR] SDF format, chain KF [auth ZR] SDF format, chain LD [auth ZA] SDF format, chain MB [auth YJ] SDF format, chain ME [auth ZJ] SDF format, chain NC [auth YS] SDF format, chain NF [auth ZS] SDF format, chain OD [auth ZB] SDF format, chain PB [auth YK] SDF format, chain PE [auth ZK] SDF format, chain QC [auth YT] SDF format, chain QF [auth ZT] SDF format, chain RD [auth ZC] SDF format, chain SB [auth YL] SDF format, chain SE [auth ZL] SDF format, chain TC [auth YU] SDF format, chain TF [auth ZU] SDF format, chain UD [auth ZD] SDF format, chain VB [auth YM] SDF format, chain VE [auth ZM] SDF format, chain WC [auth YV] SDF format, chain WF [auth ZV] SDF format, chain XA [auth YE] SDF format, chain XD [auth ZE] SDF format, chain YB [auth YN] SDF format, chain YE [auth ZN] SDF format, chain ZC [auth YW] SDF format, chain ZF [auth ZW] MOL2 format, chain AB [auth YF] MOL2 format, chain AE [auth ZF] MOL2 format, chain BC [auth YO] MOL2 format, chain BF [auth ZO] MOL2 format, chain CD [auth YX] MOL2 format, chain CG [auth ZX] MOL2 format, chain DB [auth YG] MOL2 format, chain DE [auth ZG] MOL2 format, chain EC [auth YP] MOL2 format, chain EF [auth ZP] MOL2 format, chain FD [auth YY] MOL2 format, chain FG [auth ZY] MOL2 format, chain GB [auth YH] MOL2 format, chain GE [auth ZH] MOL2 format, chain HC [auth YQ] MOL2 format, chain HF [auth ZQ] MOL2 format, chain ID [auth YZ] MOL2 format, chain IG [auth ZZ] MOL2 format, chain JB [auth YI] MOL2 format, chain JE [auth ZI] MOL2 format, chain KC [auth YR] MOL2 format, chain KF [auth ZR] MOL2 format, chain LD [auth ZA] MOL2 format, chain MB [auth YJ] MOL2 format, chain ME [auth ZJ] MOL2 format, chain NC [auth YS] MOL2 format, chain NF [auth ZS] MOL2 format, chain OD [auth ZB] MOL2 format, chain PB [auth YK] MOL2 format, chain PE [auth ZK] MOL2 format, chain QC [auth YT] MOL2 format, chain QF [auth ZT] MOL2 format, chain RD [auth ZC] MOL2 format, chain SB [auth YL] MOL2 format, chain SE [auth ZL] MOL2 format, chain TC [auth YU] MOL2 format, chain TF [auth ZU] MOL2 format, chain UD [auth ZD] MOL2 format, chain VB [auth YM] MOL2 format, chain VE [auth ZM] MOL2 format, chain WC [auth YV] MOL2 format, chain WF [auth ZV] MOL2 format, chain XA [auth YE] MOL2 format, chain XD [auth ZE] MOL2 format, chain YB [auth YN] MOL2 format, chain YE [auth ZN] MOL2 format, chain ZC [auth YW] MOL2 format, chain ZF [auth ZW] mmCIF format, chain AB [auth YF] mmCIF format, chain AE [auth ZF] mmCIF format, chain BC [auth YO] mmCIF format, chain BF [auth ZO] mmCIF format, chain CD [auth YX] mmCIF format, chain CG [auth ZX] mmCIF format, chain DB [auth YG] mmCIF format, chain DE [auth ZG] mmCIF format, chain EC [auth YP] mmCIF format, chain EF [auth ZP] mmCIF format, chain FD [auth YY] mmCIF format, chain FG [auth ZY] mmCIF format, chain GB [auth YH] mmCIF format, chain GE [auth ZH] mmCIF format, chain HC [auth YQ] mmCIF format, chain HF [auth ZQ] mmCIF format, chain ID [auth YZ] mmCIF format, chain IG [auth ZZ] mmCIF format, chain JB [auth YI] mmCIF format, chain JE [auth ZI] mmCIF format, chain KC [auth YR] mmCIF format, chain KF [auth ZR] mmCIF format, chain LD [auth ZA] mmCIF format, chain MB [auth YJ] mmCIF format, chain ME [auth ZJ] mmCIF format, chain NC [auth YS] mmCIF format, chain NF [auth ZS] mmCIF format, chain OD [auth ZB] mmCIF format, chain PB [auth YK] mmCIF format, chain PE [auth ZK] mmCIF format, chain QC [auth YT] mmCIF format, chain QF [auth ZT] mmCIF format, chain RD [auth ZC] mmCIF format, chain SB [auth YL] mmCIF format, chain SE [auth ZL] mmCIF format, chain TC [auth YU] mmCIF format, chain TF [auth ZU] mmCIF format, chain UD [auth ZD] mmCIF format, chain VB [auth YM] mmCIF format, chain VE [auth ZM] mmCIF format, chain WC [auth YV] mmCIF format, chain WF [auth ZV] mmCIF format, chain XA [auth YE] mmCIF format, chain XD [auth ZE] mmCIF format, chain YB [auth YN] mmCIF format, chain YE [auth ZN] mmCIF format, chain ZC [auth YW] mmCIF format, chain ZF [auth ZW]	AB [auth YF] AE [auth ZF] BC [auth YO] BF [auth ZO] CD [auth YX] AB [auth YF], AE [auth ZF], BC [auth YO], BF [auth ZO], CD [auth YX], CG [auth ZX], DB [auth YG], DE [auth ZG], EC [auth YP], EF [auth ZP], FD [auth YY], FG [auth ZY], GB [auth YH], GE [auth ZH], HC [auth YQ], HF [auth ZQ], ID [auth YZ], IG [auth ZZ], JB [auth YI], JE [auth ZI], KC [auth YR], KF [auth ZR], LD [auth ZA], MB [auth YJ], ME [auth ZJ], NC [auth YS], NF [auth ZS], OD [auth ZB], PB [auth YK], PE [auth ZK], QC [auth YT], QF [auth ZT], RD [auth ZC], SB [auth YL], SE [auth ZL], TC [auth YU], TF [auth ZU], UD [auth ZD], VB [auth YM], VE [auth ZM], WC [auth YV], WF [auth ZV], XA [auth YE], XD [auth ZE], YB [auth YN], YE [auth ZN], ZC [auth YW], ZF [auth ZW]	1,2-DISTEAROYL-MONOGALACTOSYL-DIGLYCERIDE C₄₅ H₈₆ O₁₀ DCLTVZLYPPIIID-CVELTQQQSA-N		Interactions Focus chain AB [auth YF] Focus chain AE [auth ZF] Focus chain BC [auth YO] Focus chain BF [auth ZO] Focus chain CD [auth YX] Focus chain CG [auth ZX] Focus chain DB [auth YG] Focus chain DE [auth ZG] Focus chain EC [auth YP] Focus chain EF [auth ZP] Focus chain FD [auth YY] Focus chain FG [auth ZY] Focus chain GB [auth YH] Focus chain GE [auth ZH] Focus chain HC [auth YQ] Focus chain HF [auth ZQ] Focus chain ID [auth YZ] Focus chain IG [auth ZZ] Focus chain JB [auth YI] Focus chain JE [auth ZI] Focus chain KC [auth YR] Focus chain KF [auth ZR] Focus chain LD [auth ZA] Focus chain MB [auth YJ] Focus chain ME [auth ZJ] Focus chain NC [auth YS] Focus chain NF [auth ZS] Focus chain OD [auth ZB] Focus chain PB [auth YK] Focus chain PE [auth ZK] Focus chain QC [auth YT] Focus chain QF [auth ZT] Focus chain RD [auth ZC] Focus chain SB [auth YL] Focus chain SE [auth ZL] Focus chain TC [auth YU] Focus chain TF [auth ZU] Focus chain UD [auth ZD] Focus chain VB [auth YM] Focus chain VE [auth ZM] Focus chain WC [auth YV] Focus chain WF [auth ZV] Focus chain XA [auth YE] Focus chain XD [auth ZE] Focus chain YB [auth YN] Focus chain YE [auth ZN] Focus chain ZC [auth YW] Focus chain ZF [auth ZW] Interactions & Density Focus chain AB [auth YF] Focus chain AE [auth ZF] Focus chain BC [auth YO] Focus chain BF [auth ZO] Focus chain CD [auth YX] Focus chain CG [auth ZX] Focus chain DB [auth YG] Focus chain DE [auth ZG] Focus chain EC [auth YP] Focus chain EF [auth ZP] Focus chain FD [auth YY] Focus chain FG [auth ZY] Focus chain GB [auth YH] Focus chain GE [auth ZH] Focus chain HC [auth YQ] Focus chain HF [auth ZQ] Focus chain ID [auth YZ] Focus chain IG [auth ZZ] Focus chain JB [auth YI] Focus chain JE [auth ZI] Focus chain KC [auth YR] Focus chain KF [auth ZR] Focus chain LD [auth ZA] Focus chain MB [auth YJ] Focus chain ME [auth ZJ] Focus chain NC [auth YS] Focus chain NF [auth ZS] Focus chain OD [auth ZB] Focus chain PB [auth YK] Focus chain PE [auth ZK] Focus chain QC [auth YT] Focus chain QF [auth ZT] Focus chain RD [auth ZC] Focus chain SB [auth YL] Focus chain SE [auth ZL] Focus chain TC [auth YU] Focus chain TF [auth ZU] Focus chain UD [auth ZD] Focus chain VB [auth YM] Focus chain VE [auth ZM] Focus chain WC [auth YV] Focus chain WF [auth ZV] Focus chain XA [auth YE] Focus chain XD [auth ZE] Focus chain YB [auth YN] Focus chain YE [auth ZN] Focus chain ZC [auth YW] Focus chain ZF [auth ZW]
NDP (Subject of Investigation/LOI) Query on NDP Download:Ideal Coordinates CCD File SDF format, chain AC [auth YO] SDF format, chain AF [auth ZO] SDF format, chain BD [auth YX] SDF format, chain BG [auth ZX] SDF format, chain CB [auth YG] SDF format, chain CE [auth ZG] SDF format, chain DC [auth YP] SDF format, chain DF [auth ZP] SDF format, chain ED [auth YY] SDF format, chain EG [auth ZY] SDF format, chain FB [auth YH] SDF format, chain FE [auth ZH] SDF format, chain GC [auth YQ] SDF format, chain GF [auth ZQ] SDF format, chain HD [auth YZ] SDF format, chain HG [auth ZZ] SDF format, chain IB [auth YI] SDF format, chain IE [auth ZI] SDF format, chain JC [auth YR] SDF format, chain JF [auth ZR] SDF format, chain KD [auth ZA] SDF format, chain LB [auth YJ] SDF format, chain LE [auth ZJ] SDF format, chain MC [auth YS] SDF format, chain MF [auth ZS] SDF format, chain ND [auth ZB] SDF format, chain OB [auth YK] SDF format, chain OE [auth ZK] SDF format, chain PC [auth YT] SDF format, chain PF [auth ZT] SDF format, chain QD [auth ZC] SDF format, chain RB [auth YL] SDF format, chain RE [auth ZL] SDF format, chain SC [auth YU] SDF format, chain SF [auth ZU] SDF format, chain TD [auth ZD] SDF format, chain UB [auth YM] SDF format, chain UE [auth ZM] SDF format, chain VC [auth YV] SDF format, chain VF [auth ZV] SDF format, chain WA [auth YE] SDF format, chain WD [auth ZE] SDF format, chain XB [auth YN] SDF format, chain XE [auth ZN] SDF format, chain YC [auth YW] SDF format, chain YF [auth ZW] SDF format, chain ZA [auth YF] SDF format, chain ZD [auth ZF] MOL2 format, chain AC [auth YO] MOL2 format, chain AF [auth ZO] MOL2 format, chain BD [auth YX] MOL2 format, chain BG [auth ZX] MOL2 format, chain CB [auth YG] MOL2 format, chain CE [auth ZG] MOL2 format, chain DC [auth YP] MOL2 format, chain DF [auth ZP] MOL2 format, chain ED [auth YY] MOL2 format, chain EG [auth ZY] MOL2 format, chain FB [auth YH] MOL2 format, chain FE [auth ZH] MOL2 format, chain GC [auth YQ] MOL2 format, chain GF [auth ZQ] MOL2 format, chain HD [auth YZ] MOL2 format, chain HG [auth ZZ] MOL2 format, chain IB [auth YI] MOL2 format, chain IE [auth ZI] MOL2 format, chain JC [auth YR] MOL2 format, chain JF [auth ZR] MOL2 format, chain KD [auth ZA] MOL2 format, chain LB [auth YJ] MOL2 format, chain LE [auth ZJ] MOL2 format, chain MC [auth YS] MOL2 format, chain MF [auth ZS] MOL2 format, chain ND [auth ZB] MOL2 format, chain OB [auth YK] MOL2 format, chain OE [auth ZK] MOL2 format, chain PC [auth YT] MOL2 format, chain PF [auth ZT] MOL2 format, chain QD [auth ZC] MOL2 format, chain RB [auth YL] MOL2 format, chain RE [auth ZL] MOL2 format, chain SC [auth YU] MOL2 format, chain SF [auth ZU] MOL2 format, chain TD [auth ZD] MOL2 format, chain UB [auth YM] MOL2 format, chain UE [auth ZM] MOL2 format, chain VC [auth YV] MOL2 format, chain VF [auth ZV] MOL2 format, chain WA [auth YE] MOL2 format, chain WD [auth ZE] MOL2 format, chain XB [auth YN] MOL2 format, chain XE [auth ZN] MOL2 format, chain YC [auth YW] MOL2 format, chain YF [auth ZW] MOL2 format, chain ZA [auth YF] MOL2 format, chain ZD [auth ZF] mmCIF format, chain AC [auth YO] mmCIF format, chain AF [auth ZO] mmCIF format, chain BD [auth YX] mmCIF format, chain BG [auth ZX] mmCIF format, chain CB [auth YG] mmCIF format, chain CE [auth ZG] mmCIF format, chain DC [auth YP] mmCIF format, chain DF [auth ZP] mmCIF format, chain ED [auth YY] mmCIF format, chain EG [auth ZY] mmCIF format, chain FB [auth YH] mmCIF format, chain FE [auth ZH] mmCIF format, chain GC [auth YQ] mmCIF format, chain GF [auth ZQ] mmCIF format, chain HD [auth YZ] mmCIF format, chain HG [auth ZZ] mmCIF format, chain IB [auth YI] mmCIF format, chain IE [auth ZI] mmCIF format, chain JC [auth YR] mmCIF format, chain JF [auth ZR] mmCIF format, chain KD [auth ZA] mmCIF format, chain LB [auth YJ] mmCIF format, chain LE [auth ZJ] mmCIF format, chain MC [auth YS] mmCIF format, chain MF [auth ZS] mmCIF format, chain ND [auth ZB] mmCIF format, chain OB [auth YK] mmCIF format, chain OE [auth ZK] mmCIF format, chain PC [auth YT] mmCIF format, chain PF [auth ZT] mmCIF format, chain QD [auth ZC] mmCIF format, chain RB [auth YL] mmCIF format, chain RE [auth ZL] mmCIF format, chain SC [auth YU] mmCIF format, chain SF [auth ZU] mmCIF format, chain TD [auth ZD] mmCIF format, chain UB [auth YM] mmCIF format, chain UE [auth ZM] mmCIF format, chain VC [auth YV] mmCIF format, chain VF [auth ZV] mmCIF format, chain WA [auth YE] mmCIF format, chain WD [auth ZE] mmCIF format, chain XB [auth YN] mmCIF format, chain XE [auth ZN] mmCIF format, chain YC [auth YW] mmCIF format, chain YF [auth ZW] mmCIF format, chain ZA [auth YF] mmCIF format, chain ZD [auth ZF]	AC [auth YO] AF [auth ZO] BD [auth YX] BG [auth ZX] CB [auth YG] AC [auth YO], AF [auth ZO], BD [auth YX], BG [auth ZX], CB [auth YG], CE [auth ZG], DC [auth YP], DF [auth ZP], ED [auth YY], EG [auth ZY], FB [auth YH], FE [auth ZH], GC [auth YQ], GF [auth ZQ], HD [auth YZ], HG [auth ZZ], IB [auth YI], IE [auth ZI], JC [auth YR], JF [auth ZR], KD [auth ZA], LB [auth YJ], LE [auth ZJ], MC [auth YS], MF [auth ZS], ND [auth ZB], OB [auth YK], OE [auth ZK], PC [auth YT], PF [auth ZT], QD [auth ZC], RB [auth YL], RE [auth ZL], SC [auth YU], SF [auth ZU], TD [auth ZD], UB [auth YM], UE [auth ZM], VC [auth YV], VF [auth ZV], WA [auth YE], WD [auth ZE], XB [auth YN], XE [auth ZN], YC [auth YW], YF [auth ZW], ZA [auth YF], ZD [auth ZF]	NADPH DIHYDRO-NICOTINAMIDE-ADENINE-DINUCLEOTIDE PHOSPHATE C₂₁ H₃₀ N₇ O₁₇ P₃ ACFIXJIJDZMPPO-NNYOXOHSSA-N		Interactions Focus chain AC [auth YO] Focus chain AF [auth ZO] Focus chain BD [auth YX] Focus chain BG [auth ZX] Focus chain CB [auth YG] Focus chain CE [auth ZG] Focus chain DC [auth YP] Focus chain DF [auth ZP] Focus chain ED [auth YY] Focus chain EG [auth ZY] Focus chain FB [auth YH] Focus chain FE [auth ZH] Focus chain GC [auth YQ] Focus chain GF [auth ZQ] Focus chain HD [auth YZ] Focus chain HG [auth ZZ] Focus chain IB [auth YI] Focus chain IE [auth ZI] Focus chain JC [auth YR] Focus chain JF [auth ZR] Focus chain KD [auth ZA] Focus chain LB [auth YJ] Focus chain LE [auth ZJ] Focus chain MC [auth YS] Focus chain MF [auth ZS] Focus chain ND [auth ZB] Focus chain OB [auth YK] Focus chain OE [auth ZK] Focus chain PC [auth YT] Focus chain PF [auth ZT] Focus chain QD [auth ZC] Focus chain RB [auth YL] Focus chain RE [auth ZL] Focus chain SC [auth YU] Focus chain SF [auth ZU] Focus chain TD [auth ZD] Focus chain UB [auth YM] Focus chain UE [auth ZM] Focus chain VC [auth YV] Focus chain VF [auth ZV] Focus chain WA [auth YE] Focus chain WD [auth ZE] Focus chain XB [auth YN] Focus chain XE [auth ZN] Focus chain YC [auth YW] Focus chain YF [auth ZW] Focus chain ZA [auth YF] Focus chain ZD [auth ZF] Interactions & Density Focus chain AC [auth YO] Focus chain AF [auth ZO] Focus chain BD [auth YX] Focus chain BG [auth ZX] Focus chain CB [auth YG] Focus chain CE [auth ZG] Focus chain DC [auth YP] Focus chain DF [auth ZP] Focus chain ED [auth YY] Focus chain EG [auth ZY] Focus chain FB [auth YH] Focus chain FE [auth ZH] Focus chain GC [auth YQ] Focus chain GF [auth ZQ] Focus chain HD [auth YZ] Focus chain HG [auth ZZ] Focus chain IB [auth YI] Focus chain IE [auth ZI] Focus chain JC [auth YR] Focus chain JF [auth ZR] Focus chain KD [auth ZA] Focus chain LB [auth YJ] Focus chain LE [auth ZJ] Focus chain MC [auth YS] Focus chain MF [auth ZS] Focus chain ND [auth ZB] Focus chain OB [auth YK] Focus chain OE [auth ZK] Focus chain PC [auth YT] Focus chain PF [auth ZT] Focus chain QD [auth ZC] Focus chain RB [auth YL] Focus chain RE [auth ZL] Focus chain SC [auth YU] Focus chain SF [auth ZU] Focus chain TD [auth ZD] Focus chain UB [auth YM] Focus chain UE [auth ZM] Focus chain VC [auth YV] Focus chain VF [auth ZV] Focus chain WA [auth YE] Focus chain WD [auth ZE] Focus chain XB [auth YN] Focus chain XE [auth ZN] Focus chain YC [auth YW] Focus chain YF [auth ZW] Focus chain ZA [auth YF] Focus chain ZD [auth ZF]
A1JWG (Subject of Investigation/LOI) Query on A1JWG Download:Ideal Coordinates CCD File SDF format, chain AD [auth YW] SDF format, chain AG [auth ZW] SDF format, chain BB [auth YF] SDF format, chain BE [auth ZF] SDF format, chain CC [auth YO] SDF format, chain CF [auth ZO] SDF format, chain DD [auth YX] SDF format, chain DG [auth ZX] SDF format, chain EB [auth YG] SDF format, chain EE [auth ZG] SDF format, chain FC [auth YP] SDF format, chain FF [auth ZP] SDF format, chain GD [auth YY] SDF format, chain GG [auth ZY] SDF format, chain HB [auth YH] SDF format, chain HE [auth ZH] SDF format, chain IC [auth YQ] SDF format, chain IF [auth ZQ] SDF format, chain JD [auth YZ] SDF format, chain JG [auth ZZ] SDF format, chain KB [auth YI] SDF format, chain KE [auth ZI] SDF format, chain LC [auth YR] SDF format, chain LF [auth ZR] SDF format, chain MD [auth ZA] SDF format, chain NB [auth YJ] SDF format, chain NE [auth ZJ] SDF format, chain OC [auth YS] SDF format, chain OF [auth ZS] SDF format, chain PD [auth ZB] SDF format, chain QB [auth YK] SDF format, chain QE [auth ZK] SDF format, chain RC [auth YT] SDF format, chain RF [auth ZT] SDF format, chain SD [auth ZC] SDF format, chain TB [auth YL] SDF format, chain TE [auth ZL] SDF format, chain UC [auth YU] SDF format, chain UF [auth ZU] SDF format, chain VD [auth ZD] SDF format, chain WB [auth YM] SDF format, chain WE [auth ZM] SDF format, chain XC [auth YV] SDF format, chain XF [auth ZV] SDF format, chain YA [auth YE] SDF format, chain YD [auth ZE] SDF format, chain ZB [auth YN] SDF format, chain ZE [auth ZN] MOL2 format, chain AD [auth YW] MOL2 format, chain AG [auth ZW] MOL2 format, chain BB [auth YF] MOL2 format, chain BE [auth ZF] MOL2 format, chain CC [auth YO] MOL2 format, chain CF [auth ZO] MOL2 format, chain DD [auth YX] MOL2 format, chain DG [auth ZX] MOL2 format, chain EB [auth YG] MOL2 format, chain EE [auth ZG] MOL2 format, chain FC [auth YP] MOL2 format, chain FF [auth ZP] MOL2 format, chain GD [auth YY] MOL2 format, chain GG [auth ZY] MOL2 format, chain HB [auth YH] MOL2 format, chain HE [auth ZH] MOL2 format, chain IC [auth YQ] MOL2 format, chain IF [auth ZQ] MOL2 format, chain JD [auth YZ] MOL2 format, chain JG [auth ZZ] MOL2 format, chain KB [auth YI] MOL2 format, chain KE [auth ZI] MOL2 format, chain LC [auth YR] MOL2 format, chain LF [auth ZR] MOL2 format, chain MD [auth ZA] MOL2 format, chain NB [auth YJ] MOL2 format, chain NE [auth ZJ] MOL2 format, chain OC [auth YS] MOL2 format, chain OF [auth ZS] MOL2 format, chain PD [auth ZB] MOL2 format, chain QB [auth YK] MOL2 format, chain QE [auth ZK] MOL2 format, chain RC [auth YT] MOL2 format, chain RF [auth ZT] MOL2 format, chain SD [auth ZC] MOL2 format, chain TB [auth YL] MOL2 format, chain TE [auth ZL] MOL2 format, chain UC [auth YU] MOL2 format, chain UF [auth ZU] MOL2 format, chain VD [auth ZD] MOL2 format, chain WB [auth YM] MOL2 format, chain WE [auth ZM] MOL2 format, chain XC [auth YV] MOL2 format, chain XF [auth ZV] MOL2 format, chain YA [auth YE] MOL2 format, chain YD [auth ZE] MOL2 format, chain ZB [auth YN] MOL2 format, chain ZE [auth ZN] mmCIF format, chain AD [auth YW] mmCIF format, chain AG [auth ZW] mmCIF format, chain BB [auth YF] mmCIF format, chain BE [auth ZF] mmCIF format, chain CC [auth YO] mmCIF format, chain CF [auth ZO] mmCIF format, chain DD [auth YX] mmCIF format, chain DG [auth ZX] mmCIF format, chain EB [auth YG] mmCIF format, chain EE [auth ZG] mmCIF format, chain FC [auth YP] mmCIF format, chain FF [auth ZP] mmCIF format, chain GD [auth YY] mmCIF format, chain GG [auth ZY] mmCIF format, chain HB [auth YH] mmCIF format, chain HE [auth ZH] mmCIF format, chain IC [auth YQ] mmCIF format, chain IF [auth ZQ] mmCIF format, chain JD [auth YZ] mmCIF format, chain JG [auth ZZ] mmCIF format, chain KB [auth YI] mmCIF format, chain KE [auth ZI] mmCIF format, chain LC [auth YR] mmCIF format, chain LF [auth ZR] mmCIF format, chain MD [auth ZA] mmCIF format, chain NB [auth YJ] mmCIF format, chain NE [auth ZJ] mmCIF format, chain OC [auth YS] mmCIF format, chain OF [auth ZS] mmCIF format, chain PD [auth ZB] mmCIF format, chain QB [auth YK] mmCIF format, chain QE [auth ZK] mmCIF format, chain RC [auth YT] mmCIF format, chain RF [auth ZT] mmCIF format, chain SD [auth ZC] mmCIF format, chain TB [auth YL] mmCIF format, chain TE [auth ZL] mmCIF format, chain UC [auth YU] mmCIF format, chain UF [auth ZU] mmCIF format, chain VD [auth ZD] mmCIF format, chain WB [auth YM] mmCIF format, chain WE [auth ZM] mmCIF format, chain XC [auth YV] mmCIF format, chain XF [auth ZV] mmCIF format, chain YA [auth YE] mmCIF format, chain YD [auth ZE] mmCIF format, chain ZB [auth YN] mmCIF format, chain ZE [auth ZN]	AD [auth YW] AG [auth ZW] BB [auth YF] BE [auth ZF] CC [auth YO] AD [auth YW], AG [auth ZW], BB [auth YF], BE [auth ZF], CC [auth YO], CF [auth ZO], DD [auth YX], DG [auth ZX], EB [auth YG], EE [auth ZG], FC [auth YP], FF [auth ZP], GD [auth YY], GG [auth ZY], HB [auth YH], HE [auth ZH], IC [auth YQ], IF [auth ZQ], JD [auth YZ], JG [auth ZZ], KB [auth YI], KE [auth ZI], LC [auth YR], LF [auth ZR], MD [auth ZA], NB [auth YJ], NE [auth ZJ], OC [auth YS], OF [auth ZS], PD [auth ZB], QB [auth YK], QE [auth ZK], RC [auth YT], RF [auth ZT], SD [auth ZC], TB [auth YL], TE [auth ZL], UC [auth YU], UF [auth ZU], VD [auth ZD], WB [auth YM], WE [auth ZM], XC [auth YV], XF [auth ZV], YA [auth YE], YD [auth ZE], ZB [auth YN], ZE [auth ZN]	Chlorophyllide a C₃₅ H₃₄ Mg N₄ O₅ LRLVQWDKYFMPKX-NYABAGMLSA-L		Interactions Focus chain AD [auth YW] Focus chain AG [auth ZW] Focus chain BB [auth YF] Focus chain BE [auth ZF] Focus chain CC [auth YO] Focus chain CF [auth ZO] Focus chain DD [auth YX] Focus chain DG [auth ZX] Focus chain EB [auth YG] Focus chain EE [auth ZG] Focus chain FC [auth YP] Focus chain FF [auth ZP] Focus chain GD [auth YY] Focus chain GG [auth ZY] Focus chain HB [auth YH] Focus chain HE [auth ZH] Focus chain IC [auth YQ] Focus chain IF [auth ZQ] Focus chain JD [auth YZ] Focus chain JG [auth ZZ] Focus chain KB [auth YI] Focus chain KE [auth ZI] Focus chain LC [auth YR] Focus chain LF [auth ZR] Focus chain MD [auth ZA] Focus chain NB [auth YJ] Focus chain NE [auth ZJ] Focus chain OC [auth YS] Focus chain OF [auth ZS] Focus chain PD [auth ZB] Focus chain QB [auth YK] Focus chain QE [auth ZK] Focus chain RC [auth YT] Focus chain RF [auth ZT] Focus chain SD [auth ZC] Focus chain TB [auth YL] Focus chain TE [auth ZL] Focus chain UC [auth YU] Focus chain UF [auth ZU] Focus chain VD [auth ZD] Focus chain WB [auth YM] Focus chain WE [auth ZM] Focus chain XC [auth YV] Focus chain XF [auth ZV] Focus chain YA [auth YE] Focus chain YD [auth ZE] Focus chain ZB [auth YN] Focus chain ZE [auth ZN] Interactions & Density Focus chain AD [auth YW] Focus chain AG [auth ZW] Focus chain BB [auth YF] Focus chain BE [auth ZF] Focus chain CC [auth YO] Focus chain CF [auth ZO] Focus chain DD [auth YX] Focus chain DG [auth ZX] Focus chain EB [auth YG] Focus chain EE [auth ZG] Focus chain FC [auth YP] Focus chain FF [auth ZP] Focus chain GD [auth YY] Focus chain GG [auth ZY] Focus chain HB [auth YH] Focus chain HE [auth ZH] Focus chain IC [auth YQ] Focus chain IF [auth ZQ] Focus chain JD [auth YZ] Focus chain JG [auth ZZ] Focus chain KB [auth YI] Focus chain KE [auth ZI] Focus chain LC [auth YR] Focus chain LF [auth ZR] Focus chain MD [auth ZA] Focus chain NB [auth YJ] Focus chain NE [auth ZJ] Focus chain OC [auth YS] Focus chain OF [auth ZS] Focus chain PD [auth ZB] Focus chain QB [auth YK] Focus chain QE [auth ZK] Focus chain RC [auth YT] Focus chain RF [auth ZT] Focus chain SD [auth ZC] Focus chain TB [auth YL] Focus chain TE [auth ZL] Focus chain UC [auth YU] Focus chain UF [auth ZU] Focus chain VD [auth ZD] Focus chain WB [auth YM] Focus chain WE [auth ZM] Focus chain XC [auth YV] Focus chain XF [auth ZV] Focus chain YA [auth YE] Focus chain YD [auth ZE] Focus chain ZB [auth YN] Focus chain ZE [auth ZN]

Experimental Data & Validation

Experimental Data

Method: ELECTRON MICROSCOPY
Resolution: 3.20 Å
Aggregation State: HELICAL ARRAY
Reconstruction Method: HELICAL

EM Software:

Task	Software Package	Version
MODEL REFINEMENT	PHENIX	2.0_5885
RECONSTRUCTION	PHENIX

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2026-08-19

Deposition Author(s):

Funding Organization	Location	Grant Number
Polish National Science Centre	Poland	2019/35/D/NZ1/00295

Revision History (Full details and data files)

Version 1.0: 2026-08-19
Type: Initial release
