9QHP | pdb_00009qhp

Cryo-EM structure of mouse TRPM3 alpha 2 in complex with antagonist Isosakuranetin

PDB DOI: https://doi.org/10.2210/pdb9QHP/pdb
EM Map EMD-53176: EMDB EMDataResource

Classification: MEMBRANE PROTEIN
Organism(s): Mus musculus
Expression System: Homo sapiens
Mutation(s): No

Deposited: 2025-03-16 Released: 2026-02-11
Deposition Author(s): Shkumatov, A.V., Schenck, S., Brunner, J.D.
Funding Organization(s): Not funded

Experimental Data Snapshot

Method: ELECTRON MICROSCOPY
Resolution: 2.35 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

This is version 1.0 of the entry. See complete history.

Literature

Cryo-EM structure of mouse TRPM3 alpha 2 in complex with antagonist Isosakuranetin

Shkumatov, A.V., Schenck, S., Brunner, J.D.

To be published.

Macromolecule Content

Total Structure Weight: 652.32 kDa
Atom Count: 30,348
Modeled Residue Count: 3,700
Deposited Residue Count: 5,636
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
MKIAA1616 protein	A, B, C, D	1,409	Mus musculus	Mutation(s): 0 Gene Names: Trpm3, mKIAA1616
UniProt & NIH Common Fund Data Resources
Find proteins for Q69ZE8 (Mus musculus) Explore Q69ZE8 Go to UniProtKB: Q69ZE8
IMPC: MGI:2443101
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	Q69ZE8
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
YUV Query on YUV Download Ideal Coordinates CCD File SDF format, chain F [auth A] SDF format, chain G [auth A] SDF format, chain H [auth B] SDF format, chain J [auth B] SDF format, chain K [auth C] SDF format, chain M [auth C] SDF format, chain N [auth D] SDF format, chain P [auth D] MOL2 format, chain F [auth A] MOL2 format, chain G [auth A] MOL2 format, chain H [auth B] MOL2 format, chain J [auth B] MOL2 format, chain K [auth C] MOL2 format, chain M [auth C] MOL2 format, chain N [auth D] MOL2 format, chain P [auth D] mmCIF format, chain F [auth A] mmCIF format, chain G [auth A] mmCIF format, chain H [auth B] mmCIF format, chain J [auth B] mmCIF format, chain K [auth C] mmCIF format, chain M [auth C] mmCIF format, chain N [auth D] mmCIF format, chain P [auth D]	F [auth A] G [auth A] H [auth B] J [auth B] K [auth C] F [auth A], G [auth A], H [auth B], J [auth B], K [auth C], M [auth C], N [auth D], P [auth D]	(25R)-14beta,17beta-spirost-5-en-3beta-ol C₂₇ H₄₂ O₃ WQLVFSAGQJTQCK-VKROHFNGSA-N		Interactions Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth B] Focus chain J [auth B] Focus chain K [auth C] Focus chain M [auth C] Focus chain N [auth D] Focus chain P [auth D] Interactions & Density Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth B] Focus chain J [auth B] Focus chain K [auth C] Focus chain M [auth C] Focus chain N [auth D] Focus chain P [auth D]
A1JBK (Subject of Investigation/LOI) Query on A1JBK Download Ideal Coordinates CCD File SDF format, chain E [auth A] SDF format, chain I [auth B] SDF format, chain L [auth C] SDF format, chain O [auth D] MOL2 format, chain E [auth A] MOL2 format, chain I [auth B] MOL2 format, chain L [auth C] MOL2 format, chain O [auth D] mmCIF format, chain E [auth A] mmCIF format, chain I [auth B] mmCIF format, chain L [auth C] mmCIF format, chain O [auth D]	E [auth A], I [auth B], L [auth C], O [auth D]	(2~{R})-2-(4-methoxyphenyl)-5,7-bis(oxidanyl)-2,3-dihydrochromen-4-one C₁₆ H₁₄ O₅ HMUJXQRRKBLVOO-CQSZACIVSA-N		Interactions Focus chain E [auth A] Focus chain I [auth B] Focus chain L [auth C] Focus chain O [auth D] Interactions & Density Focus chain E [auth A] Focus chain I [auth B] Focus chain L [auth C] Focus chain O [auth D]
