9M5A | pdb_00009m5a

cryo-EM structure of PSII D1-V185T from Thermosynechococcus vestitus BP-1

PDB DOI: https://doi.org/10.2210/pdb9M5A/pdb
EM Map EMD-63639: EMDB EMDataResource

Classification: PHOTOSYNTHESIS
Organism(s): Thermosynechococcus vestitus BP-1
Mutation(s): No

Deposited: 2025-03-05 Released: 2026-07-01
Deposition Author(s): Jiang, H.W., Nakajima, Y., Akita, F., Li, H.J., Kato, K., Sugiura, M., Shen, J.R.
Funding Organization(s): Not funded

Experimental Data Snapshot

Method: ELECTRON MICROSCOPY
Resolution: 1.88 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

This is version 1.0 of the entry. See complete history.

Literature

Cryo-EM structure of photosystem II D1-V185T mutant from Thermosynechococcus vestitus

Shen, J.R., Jian, H.W., Nakajima, Y., Akita, F., Li, H.J., Kato, K., Sugiura, M.

(2026) Biochim Biophys Acta Bioenerg

Macromolecule Content

Total Structure Weight: 744.19 kDa
Atom Count: 50,208
Modeled Residue Count: 5,180
Deposited Residue Count: 5,650
Unique protein chains: 19

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Photosystem II protein D1 3	A, Q [auth a]	360	Thermosynechococcus vestitus BP-1	Mutation(s): 0 EC: 1.10.3.9
UniProt
Find proteins for Q8DIV4 (Thermosynechococcus vestitus (strain NIES-2133 / IAM M-273 / BP-1)) Explore Q8DIV4 Go to UniProtKB: Q8DIV4
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q8DIV4
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

| 3D Structure

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
Photosystem II CP47 reaction center protein	B, R [auth b]	510	Thermosynechococcus vestitus BP-1	Mutation(s): 0
UniProt
Find proteins for Q8DIQ1 (Thermosynechococcus vestitus (strain NIES-2133 / IAM M-273 / BP-1)) Explore Q8DIQ1 Go to UniProtKB: Q8DIQ1
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q8DIQ1
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

| 3D Structure

Entity ID: 3
Molecule	Chains	Sequence Length	Organism	Details	Image
Photosystem II CP43 reaction center protein	C, S [auth c]	461	Thermosynechococcus vestitus BP-1	Mutation(s): 0
UniProt
Find proteins for Q8DIF8 (Thermosynechococcus vestitus (strain NIES-2133 / IAM M-273 / BP-1)) Explore Q8DIF8 Go to UniProtKB: Q8DIF8
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q8DIF8
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

| 3D Structure

Entity ID: 4
Molecule	Chains	Sequence Length	Organism	Details	Image
Photosystem II D2 protein	D, T [auth d]	352	Thermosynechococcus vestitus BP-1	Mutation(s): 0 EC: 1.10.3.9
UniProt
Find proteins for Q8CM25 (Thermosynechococcus vestitus (strain NIES-2133 / IAM M-273 / BP-1)) Explore Q8CM25 Go to UniProtKB: Q8CM25
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q8CM25
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

| 3D Structure

Entity ID: 5
Molecule	Chains	Sequence Length	Organism	Details	Image
Cytochrome b559 subunit beta	E [auth F], U [auth f]	45	Thermosynechococcus vestitus BP-1	Mutation(s): 0
UniProt
Find proteins for Q8DIN9 (Thermosynechococcus vestitus (strain NIES-2133 / IAM M-273 / BP-1)) Explore Q8DIN9 Go to UniProtKB: Q8DIN9
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q8DIN9
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

| 3D Structure

Entity ID: 6
Molecule	Chains	Sequence Length	Organism	Details	Image
Photosystem II reaction center protein H	F [auth H], V [auth h]	66	Thermosynechococcus vestitus BP-1	Mutation(s): 0
UniProt
Find proteins for Q8DJ43 (Thermosynechococcus vestitus (strain NIES-2133 / IAM M-273 / BP-1)) Explore Q8DJ43 Go to UniProtKB: Q8DJ43
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q8DJ43
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

| 3D Structure

Entity ID: 7
Molecule	Chains	Sequence Length	Organism	Details	Image
Photosystem II reaction center protein I	G [auth I], W [auth i]	38	Thermosynechococcus vestitus BP-1	Mutation(s): 0
UniProt
Find proteins for Q8DJZ6 (Thermosynechococcus vestitus (strain NIES-2133 / IAM M-273 / BP-1)) Explore Q8DJZ6 Go to UniProtKB: Q8DJZ6
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q8DJZ6
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

| 3D Structure

Entity ID: 8
Molecule	Chains	Sequence Length	Organism	Details	Image
Photosystem II reaction center protein J	H [auth J], X [auth j]	40	Thermosynechococcus vestitus BP-1	Mutation(s): 0
UniProt
Find proteins for P59087 (Thermosynechococcus vestitus (strain NIES-2133 / IAM M-273 / BP-1)) Explore P59087 Go to UniProtKB: P59087
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P59087
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

| 3D Structure

Entity ID: 9
Molecule	Chains	Sequence Length	Organism	Details	Image
Photosystem II reaction center protein K	I [auth K], Y [auth k]	46	Thermosynechococcus vestitus BP-1	Mutation(s): 0
UniProt
Find proteins for Q9F1K9 (Thermosynechococcus vestitus (strain NIES-2133 / IAM M-273 / BP-1)) Explore Q9F1K9 Go to UniProtKB: Q9F1K9
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q9F1K9
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

| 3D Structure

Entity ID: 10
Molecule	Chains	Sequence Length	Organism	Details	Image
Photosystem II reaction center protein L	J [auth L], Z [auth l]	37	Thermosynechococcus vestitus BP-1	Mutation(s): 0
UniProt
Find proteins for Q8DIN8 (Thermosynechococcus vestitus (strain NIES-2133 / IAM M-273 / BP-1)) Explore Q8DIN8 Go to UniProtKB: Q8DIN8
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q8DIN8
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

| 3D Structure

Entity ID: 11
Molecule	Chains	Sequence Length	Organism	Details	Image
Photosystem II reaction center protein M	AA [auth m], K [auth M]	36	Thermosynechococcus vestitus BP-1	Mutation(s): 0
UniProt
Find proteins for Q8DHA7 (Thermosynechococcus vestitus (strain NIES-2133 / IAM M-273 / BP-1)) Explore Q8DHA7 Go to UniProtKB: Q8DHA7
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q8DHA7
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

| 3D Structure

Entity ID: 12
Molecule	Chains	Sequence Length	Organism	Details	Image
Photosystem II reaction center protein T	BA [auth t], L [auth T]	32	Thermosynechococcus vestitus BP-1	Mutation(s): 0
UniProt
Find proteins for Q8DIQ0 (Thermosynechococcus vestitus (strain NIES-2133 / IAM M-273 / BP-1)) Explore Q8DIQ0 Go to UniProtKB: Q8DIQ0
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q8DIQ0
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

| 3D Structure

Entity ID: 13
Molecule	Chains	Sequence Length	Organism	Details	Image
Photosystem II extrinsic protein U	CA [auth u], M [auth U]	134	Thermosynechococcus vestitus BP-1	Mutation(s): 0
UniProt
Find proteins for Q9F1L5 (Thermosynechococcus vestitus (strain NIES-2133 / IAM M-273 / BP-1)) Explore Q9F1L5 Go to UniProtKB: Q9F1L5
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q9F1L5
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

| 3D Structure

Entity ID: 14
Molecule	Chains	Sequence Length	Organism	Details	Image
Photosystem II extrinsic protein V	DA [auth v], N [auth V]	163	Thermosynechococcus vestitus BP-1	Mutation(s): 0
UniProt
Find proteins for P0A386 (Thermosynechococcus vestitus (strain NIES-2133 / IAM M-273 / BP-1)) Explore P0A386 Go to UniProtKB: P0A386
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P0A386
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

| 3D Structure

Entity ID: 15
Molecule	Chains	Sequence Length	Organism	Details	Image
Photosystem II reaction center protein X	EA [auth x], O [auth X]	41	Thermosynechococcus vestitus BP-1	Mutation(s): 0
UniProt
Find proteins for Q9F1R6 (Thermosynechococcus vestitus (strain NIES-2133 / IAM M-273 / BP-1)) Explore Q9F1R6 Go to UniProtKB: Q9F1R6
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q9F1R6
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

| 3D Structure

Entity ID: 16
Molecule	Chains	Sequence Length	Organism	Details	Image
Photosystem II reaction center protein Psb30	FA [auth y], P [auth Y]	46	Thermosynechococcus vestitus BP-1	Mutation(s): 0
UniProt
Find proteins for Q8DJI1 (Thermosynechococcus vestitus (strain NIES-2133 / IAM M-273 / BP-1)) Explore Q8DJI1 Go to UniProtKB: Q8DJI1
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q8DJI1
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

| 3D Structure

Entity ID: 17
Molecule	Chains	Sequence Length	Organism	Details	Image
Cytochrome b559 subunit alpha	GA [auth E], JA [auth e]	84	Thermosynechococcus vestitus BP-1	Mutation(s): 0
UniProt
Find proteins for Q8DIP0 (Thermosynechococcus vestitus (strain NIES-2133 / IAM M-273 / BP-1)) Explore Q8DIP0 Go to UniProtKB: Q8DIP0
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q8DIP0
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

| 3D Structure

Entity ID: 18
Molecule	Chains	Sequence Length	Organism	Details	Image
Photosystem II extrinsic protein O	HA [auth O], KA [auth o]	272	Thermosynechococcus vestitus BP-1	Mutation(s): 0
UniProt
Find proteins for P0A431 (Thermosynechococcus vestitus (strain NIES-2133 / IAM M-273 / BP-1)) Explore P0A431 Go to UniProtKB: P0A431
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P0A431
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

| 3D Structure

Entity ID: 19
Molecule	Chains	Sequence Length	Organism	Details	Image
Photosystem II reaction center protein Z	IA [auth Z], LA [auth z]	62	Thermosynechococcus vestitus BP-1	Mutation(s): 0
UniProt
Find proteins for Q8DHJ2 (Thermosynechococcus vestitus (strain NIES-2133 / IAM M-273 / BP-1)) Explore Q8DHJ2 Go to UniProtKB: Q8DHJ2
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q8DHJ2
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 19 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
DGD Query on DGD Download:Ideal Coordinates CCD File SDF format, chain AG [auth c] SDF format, chain ID [auth H] SDF format, chain MC [auth C] SDF format, chain NC [auth C] SDF format, chain OC [auth C] SDF format, chain UG [auth h] SDF format, chain YF [auth c] SDF format, chain ZF [auth c] MOL2 format, chain AG [auth c] MOL2 format, chain ID [auth H] MOL2 format, chain MC [auth C] MOL2 format, chain NC [auth C] MOL2 format, chain OC [auth C] MOL2 format, chain UG [auth h] MOL2 format, chain YF [auth c] MOL2 format, chain ZF [auth c] mmCIF format, chain AG [auth c] mmCIF format, chain ID [auth H] mmCIF format, chain MC [auth C] mmCIF format, chain NC [auth C] mmCIF format, chain OC [auth C] mmCIF format, chain UG [auth h] mmCIF format, chain YF [auth c] mmCIF format, chain ZF [auth c]	AG [auth c] ID [auth H] MC [auth C] NC [auth C] OC [auth C] AG [auth c], ID [auth H], MC [auth C], NC [auth C], OC [auth C], UG [auth h], YF [auth c], ZF [auth c]	DIGALACTOSYL DIACYL GLYCEROL (DGDG) C₅₁ H₉₆ O₁₅ LDQFLSUQYHBXSX-HXXRYREZSA-N		Interactions Focus chain AG [auth c] Focus chain ID [auth H] Focus chain MC [auth C] Focus chain NC [auth C] Focus chain OC [auth C] Focus chain UG [auth h] Focus chain YF [auth c] Focus chain ZF [auth c] Interactions & Density Focus chain AG [auth c] Focus chain ID [auth H] Focus chain MC [auth C] Focus chain NC [auth C] Focus chain OC [auth C] Focus chain UG [auth h] Focus chain YF [auth c] Focus chain ZF [auth c]
CLA Query on CLA Download:Ideal Coordinates CCD File SDF format, chain AB [auth B] SDF format, chain AC [auth C] SDF format, chain AF [auth b] SDF format, chain BB [auth B] SDF format, chain BC [auth C] SDF format, chain BF [auth b] SDF format, chain CB [auth B] SDF format, chain CC [auth C] SDF format, chain DB [auth B] SDF format, chain DC [auth C] SDF format, chain DE [auth a] SDF format, chain EB [auth B] SDF format, chain EC [auth C] SDF format, chain EE [auth a] SDF format, chain GB [auth B] SDF format, chain GC [auth C] SDF format, chain GE [auth a] SDF format, chain HC [auth C] SDF format, chain HG [auth d] SDF format, chain IB [auth B] SDF format, chain IC [auth C] SDF format, chain IG [auth d] SDF format, chain JB [auth B] SDF format, chain JC [auth C] SDF format, chain JF [auth c] SDF format, chain KB [auth B] SDF format, chain KF [auth c] SDF format, chain LB [auth B] SDF format, chain LF [auth c] SDF format, chain MB [auth B] SDF format, chain ME [auth b] SDF format, chain MF [auth c] SDF format, chain NB [auth B] SDF format, chain NE [auth b] SDF format, chain NF [auth c] SDF format, chain OB [auth B] SDF format, chain OE [auth b] SDF format, chain OF [auth c] SDF format, chain PE [auth b] SDF format, chain PF [auth c] SDF format, chain QA [auth A] SDF format, chain QE [auth b] SDF format, chain QF [auth c] SDF format, chain RA [auth A] SDF format, chain RE [auth b] SDF format, chain RF [auth c] SDF format, chain SC [auth D] SDF format, chain SE [auth b] SDF format, chain SF [auth c] SDF format, chain TA [auth A] SDF format, chain TE [auth b] SDF format, chain TF [auth c] SDF format, chain UE [auth b] SDF format, chain UF [auth c] SDF format, chain VC [auth D] SDF format, chain VE [auth b] SDF format, chain VF [auth c] SDF format, chain WC [auth D] SDF format, chain WE [auth b] SDF format, chain XE [auth b] SDF format, chain YB [auth C] SDF format, chain YE [auth b] SDF format, chain ZA [auth B] SDF format, chain ZB [auth C] SDF format, chain ZE [auth b] SDF format, chain XB [auth C] SDF format, chain HB [auth B] SDF format, chain FC [auth C] SDF format, chain FB [auth B] SDF format, chain EG [auth d] MOL2 format, chain AB [auth B] MOL2 format, chain AC [auth C] MOL2 format, chain AF [auth b] MOL2 format, chain BB [auth B] MOL2 format, chain BC [auth C] MOL2 format, chain BF [auth b] MOL2 format, chain CB [auth B] MOL2 format, chain CC [auth C] MOL2 format, chain DB [auth B] MOL2 format, chain DC [auth C] MOL2 format, chain DE [auth a] MOL2 format, chain EB [auth B] MOL2 format, chain EC [auth C] MOL2 format, chain EE [auth a] MOL2 format, chain GB [auth B] MOL2 format, chain GC [auth C] MOL2 format, chain GE [auth a] MOL2 format, chain HC [auth C] MOL2 format, chain HG [auth d] MOL2 format, chain IB [auth B] MOL2 format, chain IC [auth C] MOL2 format, chain IG [auth d] MOL2 format, chain JB [auth B] MOL2 format, chain JC [auth C] MOL2 format, chain JF [auth c] MOL2 format, chain KB [auth B] MOL2 format, chain KF [auth c] MOL2 format, chain LB [auth B] MOL2 format, chain LF [auth c] MOL2 format, chain MB [auth B] MOL2 format, chain ME [auth b] MOL2 format, chain MF [auth c] MOL2 format, chain NB [auth B] MOL2 format, chain NE [auth b] MOL2 format, chain NF [auth c] MOL2 format, chain OB [auth B] MOL2 format, chain OE [auth b] MOL2 format, chain OF [auth c] MOL2 format, chain PE [auth b] MOL2 format, chain PF [auth c] MOL2 format, chain QA [auth A] MOL2 format, chain QE [auth b] MOL2 format, chain QF [auth c] MOL2 format, chain RA [auth A] MOL2 format, chain RE [auth b] MOL2 format, chain RF [auth c] MOL2 format, chain SC [auth D] MOL2 format, chain SE [auth b] MOL2 format, chain SF [auth c] MOL2 format, chain TA [auth A] MOL2 format, chain TE [auth b] MOL2 format, chain TF [auth c] MOL2 format, chain UE [auth b] MOL2 format, chain UF [auth c] MOL2 format, chain VC [auth D] MOL2 format, chain VE [auth b] MOL2 format, chain VF [auth c] MOL2 format, chain WC [auth D] MOL2 format, chain WE [auth b] MOL2 format, chain XE [auth b] MOL2 format, chain YB [auth C] MOL2 format, chain YE [auth b] MOL2 format, chain ZA [auth B] MOL2 format, chain ZB [auth C] MOL2 format, chain ZE [auth b] MOL2 format, chain XB [auth C] MOL2 format, chain HB [auth B] MOL2 format, chain FC [auth C] MOL2 format, chain FB [auth B] MOL2 format, chain EG [auth d] mmCIF format, chain AB [auth B] mmCIF format, chain AC [auth C] mmCIF format, chain AF [auth b] mmCIF format, chain BB [auth B] mmCIF format, chain BC [auth C] mmCIF format, chain BF [auth b] mmCIF format, chain CB [auth B] mmCIF format, chain CC [auth C] mmCIF format, chain DB [auth B] mmCIF format, chain DC [auth C] mmCIF format, chain DE [auth a] mmCIF format, chain EB [auth B] mmCIF format, chain EC [auth C] mmCIF format, chain EE [auth a] mmCIF format, chain GB [auth B] mmCIF format, chain GC [auth C] mmCIF format, chain GE [auth a] mmCIF format, chain HC [auth C] mmCIF format, chain HG [auth d] mmCIF format, chain IB [auth B] mmCIF format, chain IC [auth C] mmCIF format, chain IG [auth d] mmCIF format, chain JB [auth B] mmCIF format, chain JC [auth C] mmCIF format, chain JF [auth c] mmCIF format, chain KB [auth B] mmCIF format, chain KF [auth c] mmCIF format, chain LB [auth B] mmCIF format, chain LF [auth c] mmCIF format, chain MB [auth B] mmCIF format, chain ME [auth b] mmCIF format, chain MF [auth c] mmCIF format, chain NB [auth B] mmCIF format, chain NE [auth b] mmCIF format, chain NF [auth c] mmCIF format, chain OB [auth B] mmCIF format, chain OE [auth b] mmCIF format, chain OF [auth c] mmCIF format, chain PE [auth b] mmCIF format, chain PF [auth c] mmCIF format, chain QA [auth A] mmCIF format, chain QE [auth b] mmCIF format, chain QF [auth c] mmCIF format, chain RA [auth A] mmCIF format, chain RE [auth b] mmCIF format, chain RF [auth c] mmCIF format, chain SC [auth D] mmCIF format, chain SE [auth b] mmCIF format, chain SF [auth c] mmCIF format, chain TA [auth A] mmCIF format, chain TE [auth b] mmCIF format, chain TF [auth c] mmCIF format, chain UE [auth b] mmCIF format, chain UF [auth c] mmCIF format, chain VC [auth D] mmCIF format, chain VE [auth b] mmCIF format, chain VF [auth c] mmCIF format, chain WC [auth D] mmCIF format, chain WE [auth b] mmCIF format, chain XE [auth b] mmCIF format, chain YB [auth C] mmCIF format, chain YE [auth b] mmCIF format, chain ZA [auth B] mmCIF format, chain ZB [auth C] mmCIF format, chain ZE [auth b] mmCIF format, chain XB [auth C] mmCIF format, chain HB [auth B] mmCIF format, chain FC [auth C] mmCIF format, chain FB [auth B] mmCIF format, chain EG [auth d]	AB [auth B] AC [auth C] AF [auth b] BB [auth B] BC [auth C] AB [auth B], AC [auth C], AF [auth b], BB [auth B], BC [auth C], BF [auth b], CB [auth B], CC [auth C], DB [auth B], DC [auth C], DE [auth a], EB [auth B], EC [auth C], EE [auth a], EG [auth d], FB [auth B], FC [auth C], GB [auth B], GC [auth C], GE [auth a], HB [auth B], HC [auth C], HG [auth d], IB [auth B], IC [auth C], IG [auth d], JB [auth B], JC [auth C], JF [auth c], KB [auth B], KF [auth c], LB [auth B], LF [auth c], MB [auth B], ME [auth b], MF [auth c], NB [auth B], NE [auth b], NF [auth c], OB [auth B], OE [auth b], OF [auth c], PE [auth b], PF [auth c], QA [auth A], QE [auth b], QF [auth c], RA [auth A], RE [auth b], RF [auth c], SC [auth D], SE [auth b], SF [auth c], TA [auth A], TE [auth b], TF [auth c], UE [auth b], UF [auth c], VC [auth D], VE [auth b], VF [auth c], WC [auth D], WE [auth b], XB [auth C], XE [auth b], YB [auth C], YE [auth b], ZA [auth B], ZB [auth C], ZE [auth b]	CHLOROPHYLL A C₅₅ H₇₂ Mg N₄ O₅ ATNHDLDRLWWWCB-AENOIHSZSA-M		Interactions Focus chain AB [auth B] Focus chain AC [auth C] Focus chain AF [auth b] Focus chain BB [auth B] Focus chain BC [auth C] Focus chain BF [auth b] Focus chain CB [auth B] Focus chain CC [auth C] Focus chain DB [auth B] Focus chain DC [auth C] Focus chain DE [auth a] Focus chain EB [auth B] Focus chain EC [auth C] Focus chain EE [auth a] Focus chain EG [auth d] Focus chain FB [auth B] Focus chain FC [auth C] Focus chain GB [auth B] Focus chain GC [auth C] Focus chain GE [auth a] Focus chain HB [auth B] Focus chain HC [auth C] Focus chain HG [auth d] Focus chain IB [auth B] Focus chain IC [auth C] Focus chain IG [auth d] Focus chain JB [auth B] Focus chain JC [auth C] Focus chain JF [auth c] Focus chain KB [auth B] Focus chain KF [auth c] Focus chain LB [auth B] Focus chain LF [auth c] Focus chain MB [auth B] Focus chain ME [auth b] Focus chain MF [auth c] Focus chain NB [auth B] Focus chain NE [auth b] Focus chain NF [auth c] Focus chain OB [auth B] Focus chain OE [auth b] Focus chain OF [auth c] Focus chain PE [auth b] Focus chain PF [auth c] Focus chain QA [auth A] Focus chain QE [auth b] Focus chain QF [auth c] Focus chain RA [auth A] Focus chain RE [auth b] Focus chain RF [auth c] Focus chain SC [auth D] Focus chain SE [auth b] Focus chain SF [auth c] Focus chain TA [auth A] Focus chain TE [auth b] Focus chain TF [auth c] Focus chain UE [auth b] Focus chain UF [auth c] Focus chain VC [auth D] Focus chain VE [auth b] Focus chain VF [auth c] Focus chain WC [auth D] Focus chain WE [auth b] Focus chain XB [auth C] Focus chain XE [auth b] Focus chain YB [auth C] Focus chain YE [auth b] Focus chain ZA [auth B] Focus chain ZB [auth C] Focus chain ZE [auth b] Interactions & Density Focus chain AB [auth B] Focus chain AC [auth C] Focus chain AF [auth b] Focus chain BB [auth B] Focus chain BC [auth C] Focus chain BF [auth b] Focus chain CB [auth B] Focus chain CC [auth C] Focus chain DB [auth B] Focus chain DC [auth C] Focus chain DE [auth a] Focus chain EB [auth B] Focus chain EC [auth C] Focus chain EE [auth a] Focus chain EG [auth d] Focus chain FB [auth B] Focus chain FC [auth C] Focus chain GB [auth B] Focus chain GC [auth C] Focus chain GE [auth a] Focus chain HB [auth B] Focus chain HC [auth C] Focus chain HG [auth d] Focus chain IB [auth B] Focus chain IC [auth C] Focus chain IG [auth d] Focus chain JB [auth B] Focus chain JC [auth C] Focus chain JF [auth c] Focus chain KB [auth B] Focus chain KF [auth c] Focus chain LB [auth B] Focus chain LF [auth c] Focus chain MB [auth B] Focus chain ME [auth b] Focus chain MF [auth c] Focus chain NB [auth B] Focus chain NE [auth b] Focus chain NF [auth c] Focus chain OB [auth B] Focus chain OE [auth b] Focus chain OF [auth c] Focus chain PE [auth b] Focus chain PF [auth c] Focus chain QA [auth A] Focus chain QE [auth b] Focus chain QF [auth c] Focus chain RA [auth A] Focus chain RE [auth b] Focus chain RF [auth c] Focus chain SC [auth D] Focus chain SE [auth b] Focus chain SF [auth c] Focus chain TA [auth A] Focus chain TE [auth b] Focus chain TF [auth c] Focus chain UE [auth b] Focus chain UF [auth c] Focus chain VC [auth D] Focus chain VE [auth b] Focus chain VF [auth c] Focus chain WC [auth D] Focus chain WE [auth b] Focus chain XB [auth C] Focus chain XE [auth b] Focus chain YB [auth C] Focus chain YE [auth b] Focus chain ZA [auth B] Focus chain ZB [auth C] Focus chain ZE [auth b]
PHO Query on PHO Download:Ideal Coordinates CCD File SDF format, chain DG [auth d] SDF format, chain FE [auth a] SDF format, chain RC [auth D] SDF format, chain SA [auth A] MOL2 format, chain DG [auth d] MOL2 format, chain FE [auth a] MOL2 format, chain RC [auth D] MOL2 format, chain SA [auth A] mmCIF format, chain DG [auth d] mmCIF format, chain FE [auth a] mmCIF format, chain RC [auth D] mmCIF format, chain SA [auth A]	DG [auth d], FE [auth a], RC [auth D], SA [auth A]	PHEOPHYTIN A C₅₅ H₇₄ N₄ O₅ CQIKWXUXPNUNDV-RCBXBCQGSA-N		Interactions Focus chain DG [auth d] Focus chain FE [auth a] Focus chain RC [auth D] Focus chain SA [auth A] Interactions & Density Focus chain DG [auth d] Focus chain FE [auth a] Focus chain RC [auth D] Focus chain SA [auth A]
SQD Query on SQD Download:Ideal Coordinates CCD File SDF format, chain DH [auth t] SDF format, chain FD [auth D] SDF format, chain IF [auth c] SDF format, chain KE [auth a] SDF format, chain RG [auth d] SDF format, chain TD [auth T] SDF format, chain WB [auth C] SDF format, chain XA [auth A] MOL2 format, chain DH [auth t] MOL2 format, chain FD [auth D] MOL2 format, chain IF [auth c] MOL2 format, chain KE [auth a] MOL2 format, chain RG [auth d] MOL2 format, chain TD [auth T] MOL2 format, chain WB [auth C] MOL2 format, chain XA [auth A] mmCIF format, chain DH [auth t] mmCIF format, chain FD [auth D] mmCIF format, chain IF [auth c] mmCIF format, chain KE [auth a] mmCIF format, chain RG [auth d] mmCIF format, chain TD [auth T] mmCIF format, chain WB [auth C] mmCIF format, chain XA [auth A]	DH [auth t] FD [auth D] IF [auth c] KE [auth a] RG [auth d] DH [auth t], FD [auth D], IF [auth c], KE [auth a], RG [auth d], TD [auth T], WB [auth C], XA [auth A]	1,2-DI-O-ACYL-3-O-[6-DEOXY-6-SULFO-ALPHA-D-GLUCOPYRANOSYL]-SN-GLYCEROL C₄₁ H₇₈ O₁₂ S RVUUQPKXGDTQPG-JUDHQOGESA-N		Interactions Focus chain DH [auth t] Focus chain FD [auth D] Focus chain IF [auth c] Focus chain KE [auth a] Focus chain RG [auth d] Focus chain TD [auth T] Focus chain WB [auth C] Focus chain XA [auth A] Interactions & Density Focus chain DH [auth t] Focus chain FD [auth D] Focus chain IF [auth c] Focus chain KE [auth a] Focus chain RG [auth d] Focus chain TD [auth T] Focus chain WB [auth C] Focus chain XA [auth A]
LMG Query on LMG Download:Ideal Coordinates CCD File SDF format, chain BG [auth c] SDF format, chain CD [auth D] SDF format, chain CG [auth c] SDF format, chain FF [auth b] SDF format, chain IE [auth a] SDF format, chain OG [auth d] SDF format, chain PC [auth C] SDF format, chain SB [auth B] SDF format, chain VA [auth A] SDF format, chain QC [auth C] MOL2 format, chain BG [auth c] MOL2 format, chain CD [auth D] MOL2 format, chain CG [auth c] MOL2 format, chain FF [auth b] MOL2 format, chain IE [auth a] MOL2 format, chain OG [auth d] MOL2 format, chain PC [auth C] MOL2 format, chain SB [auth B] MOL2 format, chain VA [auth A] MOL2 format, chain QC [auth C] mmCIF format, chain BG [auth c] mmCIF format, chain CD [auth D] mmCIF format, chain CG [auth c] mmCIF format, chain FF [auth b] mmCIF format, chain IE [auth a] mmCIF format, chain OG [auth d] mmCIF format, chain PC [auth C] mmCIF format, chain SB [auth B] mmCIF format, chain VA [auth A] mmCIF format, chain QC [auth C]	BG [auth c] CD [auth D] CG [auth c] FF [auth b] IE [auth a] BG [auth c], CD [auth D], CG [auth c], FF [auth b], IE [auth a], OG [auth d], PC [auth C], QC [auth C], SB [auth B], VA [auth A]	1,2-DISTEAROYL-MONOGALACTOSYL-DIGLYCERIDE C₄₅ H₈₆ O₁₀ DCLTVZLYPPIIID-CVELTQQQSA-N		Interactions Focus chain BG [auth c] Focus chain CD [auth D] Focus chain CG [auth c] Focus chain FF [auth b] Focus chain IE [auth a] Focus chain OG [auth d] Focus chain PC [auth C] Focus chain QC [auth C] Focus chain SB [auth B] Focus chain VA [auth A] Interactions & Density Focus chain BG [auth c] Focus chain CD [auth D] Focus chain CG [auth c] Focus chain FF [auth b] Focus chain IE [auth a] Focus chain OG [auth d] Focus chain PC [auth C] Focus chain QC [auth C] Focus chain SB [auth B] Focus chain VA [auth A]
PL9 Query on PL9 Download:Ideal Coordinates CCD File SDF format, chain KG [auth d] SDF format, chain WA [auth A] SDF format, chain YC [auth D] SDF format, chain JE [auth a] MOL2 format, chain KG [auth d] MOL2 format, chain WA [auth A] MOL2 format, chain YC [auth D] MOL2 format, chain JE [auth a] mmCIF format, chain KG [auth d] mmCIF format, chain WA [auth A] mmCIF format, chain YC [auth D] mmCIF format, chain JE [auth a]	JE [auth a], KG [auth d], WA [auth A], YC [auth D]	2,3-DIMETHYL-5-(3,7,11,15,19,23,27,31,35-NONAMETHYL-2,6,10,14,18,22,26,30,34-HEXATRIACONTANONAENYL-2,5-CYCLOHEXADIENE-1,4-DIONE-2,3-DIMETHYL-5-SOLANESYL-1,4-BENZOQUINONE C₅₃ H₈₀ O₂ FKUYMLZIRPABFK-UHFFFAOYSA-N		Interactions Focus chain JE [auth a] Focus chain KG [auth d] Focus chain WA [auth A] Focus chain YC [auth D] Interactions & Density Focus chain JE [auth a] Focus chain KG [auth d] Focus chain WA [auth A] Focus chain YC [auth D]
LHG Query on LHG Download:Ideal Coordinates CCD File SDF format, chain AD [auth D] SDF format, chain BD [auth D] SDF format, chain BH [auth l] SDF format, chain KH [auth E] SDF format, chain LG [auth d] SDF format, chain MG [auth d] SDF format, chain NG [auth d] SDF format, chain NH [auth e] SDF format, chain PD [auth L] SDF format, chain ZC [auth D] MOL2 format, chain AD [auth D] MOL2 format, chain BD [auth D] MOL2 format, chain BH [auth l] MOL2 format, chain KH [auth E] MOL2 format, chain LG [auth d] MOL2 format, chain MG [auth d] MOL2 format, chain NG [auth d] MOL2 format, chain NH [auth e] MOL2 format, chain PD [auth L] MOL2 format, chain ZC [auth D] mmCIF format, chain AD [auth D] mmCIF format, chain BD [auth D] mmCIF format, chain BH [auth l] mmCIF format, chain KH [auth E] mmCIF format, chain LG [auth d] mmCIF format, chain MG [auth d] mmCIF format, chain NG [auth d] mmCIF format, chain NH [auth e] mmCIF format, chain PD [auth L] mmCIF format, chain ZC [auth D]	AD [auth D] BD [auth D] BH [auth l] KH [auth E] LG [auth d] AD [auth D], BD [auth D], BH [auth l], KH [auth E], LG [auth d], MG [auth d], NG [auth d], NH [auth e], PD [auth L], ZC [auth D]	1,2-DIPALMITOYL-PHOSPHATIDYL-GLYCEROLE C₃₈ H₇₅ O₁₀ P BIABMEZBCHDPBV-MPQUPPDSSA-N		Interactions Focus chain AD [auth D] Focus chain BD [auth D] Focus chain BH [auth l] Focus chain KH [auth E] Focus chain LG [auth d] Focus chain MG [auth d] Focus chain NG [auth d] Focus chain NH [auth e] Focus chain PD [auth L] Focus chain ZC [auth D] Interactions & Density Focus chain AD [auth D] Focus chain BD [auth D] Focus chain BH [auth l] Focus chain KH [auth E] Focus chain LG [auth d] Focus chain MG [auth d] Focus chain NG [auth d] Focus chain NH [auth e] Focus chain PD [auth L] Focus chain ZC [auth D]
HEC Query on HEC Download:Ideal Coordinates CCD File SDF format, chain HH [auth v] SDF format, chain WD [auth V] MOL2 format, chain HH [auth v] MOL2 format, chain WD [auth V] mmCIF format, chain HH [auth v] mmCIF format, chain WD [auth V]	HH [auth v], WD [auth V]	HEME C C₃₄ H₃₄ Fe N₄ O₄ HXQIYSLZKNYNMH-LJNAALQVSA-N		Interactions Focus chain HH [auth v] Focus chain WD [auth V] Interactions & Density Focus chain HH [auth v] Focus chain WD [auth V]
HEM Query on HEM Download:Ideal Coordinates CCD File SDF format, chain GD [auth F] SDF format, chain SG [auth f] MOL2 format, chain GD [auth F] MOL2 format, chain SG [auth f] mmCIF format, chain GD [auth F] mmCIF format, chain SG [auth f]	GD [auth F], SG [auth f]	PROTOPORPHYRIN IX CONTAINING FE C₃₄ H₃₂ Fe N₄ O₄ KABFMIBPWCXCRK-RGGAHWMASA-L		Interactions Focus chain GD [auth F] Focus chain SG [auth f] Interactions & Density Focus chain GD [auth F] Focus chain SG [auth f]
RRX Query on RRX Download:Ideal Coordinates CCD File SDF format, chain HD [auth H] SDF format, chain TG [auth h] MOL2 format, chain HD [auth H] MOL2 format, chain TG [auth h] mmCIF format, chain HD [auth H] mmCIF format, chain TG [auth h]	HD [auth H], TG [auth h]	(3R)-beta,beta-caroten-3-ol C₄₀ H₅₆ O DMASLKHVQRHNES-FKKUPVFPSA-N		Interactions Focus chain HD [auth H] Focus chain TG [auth h] Interactions & Density Focus chain HD [auth H] Focus chain TG [auth h]
BCR Query on BCR Download:Ideal Coordinates CCD File SDF format, chain AH [auth k] SDF format, chain CF [auth b] SDF format, chain DF [auth b] SDF format, chain EF [auth b] SDF format, chain FH [auth t] SDF format, chain HE [auth a] SDF format, chain JG [auth d] SDF format, chain JH [auth y] SDF format, chain KC [auth C] SDF format, chain LC [auth C] SDF format, chain OD [auth K] SDF format, chain PB [auth B] SDF format, chain QB [auth B] SDF format, chain RB [auth B] SDF format, chain RD [auth T] SDF format, chain UA [auth A] SDF format, chain WF [auth c] SDF format, chain XC [auth D] SDF format, chain XF [auth c] SDF format, chain YD [auth Y] MOL2 format, chain AH [auth k] MOL2 format, chain CF [auth b] MOL2 format, chain DF [auth b] MOL2 format, chain EF [auth b] MOL2 format, chain FH [auth t] MOL2 format, chain HE [auth a] MOL2 format, chain JG [auth d] MOL2 format, chain JH [auth y] MOL2 format, chain KC [auth C] MOL2 format, chain LC [auth C] MOL2 format, chain OD [auth K] MOL2 format, chain PB [auth B] MOL2 format, chain QB [auth B] MOL2 format, chain RB [auth B] MOL2 format, chain RD [auth T] MOL2 format, chain UA [auth A] MOL2 format, chain WF [auth c] MOL2 format, chain XC [auth D] MOL2 format, chain XF [auth c] MOL2 format, chain YD [auth Y] mmCIF format, chain AH [auth k] mmCIF format, chain CF [auth b] mmCIF format, chain DF [auth b] mmCIF format, chain EF [auth b] mmCIF format, chain FH [auth t] mmCIF format, chain HE [auth a] mmCIF format, chain JG [auth d] mmCIF format, chain JH [auth y] mmCIF format, chain KC [auth C] mmCIF format, chain LC [auth C] mmCIF format, chain OD [auth K] mmCIF format, chain PB [auth B] mmCIF format, chain QB [auth B] mmCIF format, chain RB [auth B] mmCIF format, chain RD [auth T] mmCIF format, chain UA [auth A] mmCIF format, chain WF [auth c] mmCIF format, chain XC [auth D] mmCIF format, chain XF [auth c] mmCIF format, chain YD [auth Y]	AH [auth k] CF [auth b] DF [auth b] EF [auth b] FH [auth t] AH [auth k], CF [auth b], DF [auth b], EF [auth b], FH [auth t], HE [auth a], JG [auth d], JH [auth y], KC [auth C], LC [auth C], OD [auth K], PB [auth B], QB [auth B], RB [auth B], RD [auth T], UA [auth A], WF [auth c], XC [auth D], XF [auth c], YD [auth Y]	BETA-CAROTENE C₄₀ H₅₆ OENHQHLEOONYIE-JLTXGRSLSA-N		Interactions Focus chain AH [auth k] Focus chain CF [auth b] Focus chain DF [auth b] Focus chain EF [auth b] Focus chain FH [auth t] Focus chain HE [auth a] Focus chain JG [auth d] Focus chain JH [auth y] Focus chain KC [auth C] Focus chain LC [auth C] Focus chain OD [auth K] Focus chain PB [auth B] Focus chain QB [auth B] Focus chain RB [auth B] Focus chain RD [auth T] Focus chain UA [auth A] Focus chain WF [auth c] Focus chain XC [auth D] Focus chain XF [auth c] Focus chain YD [auth Y] Interactions & Density Focus chain AH [auth k] Focus chain CF [auth b] Focus chain DF [auth b] Focus chain EF [auth b] Focus chain FH [auth t] Focus chain HE [auth a] Focus chain JG [auth d] Focus chain JH [auth y] Focus chain KC [auth C] Focus chain LC [auth C] Focus chain OD [auth K] Focus chain PB [auth B] Focus chain QB [auth B] Focus chain RB [auth B] Focus chain RD [auth T] Focus chain UA [auth A] Focus chain WF [auth c] Focus chain XC [auth D] Focus chain XF [auth c] Focus chain YD [auth Y]
LMT Query on LMT Download:Ideal Coordinates CCD File SDF format, chain CH [auth m] SDF format, chain EH [auth t] SDF format, chain GF [auth b] SDF format, chain MD [auth J] SDF format, chain QD [auth M] SDF format, chain TB [auth B] SDF format, chain UD [auth T] SDF format, chain VD [auth T] SDF format, chain YG [auth j] SDF format, chain VB [auth B] MOL2 format, chain CH [auth m] MOL2 format, chain EH [auth t] MOL2 format, chain GF [auth b] MOL2 format, chain MD [auth J] MOL2 format, chain QD [auth M] MOL2 format, chain TB [auth B] MOL2 format, chain UD [auth T] MOL2 format, chain VD [auth T] MOL2 format, chain YG [auth j] MOL2 format, chain VB [auth B] mmCIF format, chain CH [auth m] mmCIF format, chain EH [auth t] mmCIF format, chain GF [auth b] mmCIF format, chain MD [auth J] mmCIF format, chain QD [auth M] mmCIF format, chain TB [auth B] mmCIF format, chain UD [auth T] mmCIF format, chain VD [auth T] mmCIF format, chain YG [auth j] mmCIF format, chain VB [auth B]	CH [auth m] EH [auth t] GF [auth b] MD [auth J] QD [auth M] CH [auth m], EH [auth t], GF [auth b], MD [auth J], QD [auth M], TB [auth B], UD [auth T], VB [auth B], VD [auth T], YG [auth j]	DODECYL-BETA-D-MALTOSIDE C₂₄ H₄₆ O₁₁ NLEBIOOXCVAHBD-QKMCSOCLSA-N		Interactions Focus chain CH [auth m] Focus chain EH [auth t] Focus chain GF [auth b] Focus chain MD [auth J] Focus chain QD [auth M] Focus chain TB [auth B] Focus chain UD [auth T] Focus chain VB [auth B] Focus chain VD [auth T] Focus chain YG [auth j] Interactions & Density Focus chain CH [auth m] Focus chain EH [auth t] Focus chain GF [auth b] Focus chain MD [auth J] Focus chain QD [auth M] Focus chain TB [auth B] Focus chain UD [auth T] Focus chain VB [auth B] Focus chain VD [auth T] Focus chain YG [auth j]
OEX Query on OEX Download:Ideal Coordinates CCD File SDF format, chain MA [auth A] SDF format, chain ZD [auth a] MOL2 format, chain MA [auth A] MOL2 format, chain ZD [auth a] mmCIF format, chain MA [auth A] mmCIF format, chain ZD [auth a]	MA [auth A], ZD [auth a]	CA-MN4-O5 CLUSTER Ca Mn₄ O₅ SEXWDHMBWJEXOJ-UHFFFAOYSA-N		Interactions Focus chain MA [auth A] Focus chain ZD [auth a] Interactions & Density Focus chain MA [auth A] Focus chain ZD [auth a]
BCT Query on BCT Download:Ideal Coordinates CCD File SDF format, chain GG [auth d] SDF format, chain UC [auth D] MOL2 format, chain GG [auth d] MOL2 format, chain UC [auth D] mmCIF format, chain GG [auth d] mmCIF format, chain UC [auth D]	GG [auth d], UC [auth D]	BICARBONATE ION C H O₃ BVKZGUZCCUSVTD-UHFFFAOYSA-M		Interactions Focus chain GG [auth d] Focus chain UC [auth D] Interactions & Density Focus chain GG [auth d] Focus chain UC [auth D]
FE2 Query on FE2 Download:Ideal Coordinates CCD File SDF format, chain AE [auth a] SDF format, chain NA [auth A] MOL2 format, chain AE [auth a] MOL2 format, chain NA [auth A] mmCIF format, chain AE [auth a] mmCIF format, chain NA [auth A]	AE [auth a], NA [auth A]	FE (II) ION Fe CWYNVVGOOAEACU-UHFFFAOYSA-N		Interactions Focus chain AE [auth a] Focus chain NA [auth A] Interactions & Density Focus chain AE [auth a] Focus chain NA [auth A]
CA Query on CA Download:Ideal Coordinates CCD File SDF format, chain MH [auth O] SDF format, chain PH [auth o] MOL2 format, chain MH [auth O] MOL2 format, chain PH [auth o] mmCIF format, chain MH [auth O] mmCIF format, chain PH [auth o]	MH [auth O], PH [auth o]	CALCIUM ION Ca BHPQYMZQTOCNFJ-UHFFFAOYSA-N		Interactions Focus chain MH [auth O] Focus chain PH [auth o] Interactions & Density Focus chain MH [auth O] Focus chain PH [auth o]
CL Query on CL Download:Ideal Coordinates CCD File SDF format, chain BE [auth a] SDF format, chain CE [auth a] SDF format, chain OA [auth A] SDF format, chain PA [auth A] MOL2 format, chain BE [auth a] MOL2 format, chain CE [auth a] MOL2 format, chain OA [auth A] MOL2 format, chain PA [auth A] mmCIF format, chain BE [auth a] mmCIF format, chain CE [auth a] mmCIF format, chain OA [auth A] mmCIF format, chain PA [auth A]	BE [auth a], CE [auth a], OA [auth A], PA [auth A]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M		Interactions Focus chain BE [auth a] Focus chain CE [auth a] Focus chain OA [auth A] Focus chain PA [auth A] Interactions & Density Focus chain BE [auth a] Focus chain CE [auth a] Focus chain OA [auth A] Focus chain PA [auth A]
MG Query on MG Download:Ideal Coordinates CCD File SDF format, chain LD [auth J] SDF format, chain XG [auth j] MOL2 format, chain LD [auth J] MOL2 format, chain XG [auth j] mmCIF format, chain LD [auth J] mmCIF format, chain XG [auth j]	LD [auth J], XG [auth j]	MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N		Interactions Focus chain LD [auth J] Focus chain XG [auth j] Interactions & Density Focus chain LD [auth J] Focus chain XG [auth j]
UNL Query on UNL Download:Ideal Coordinates CCD File	DD [auth D] ED [auth D] FG [auth d] GH [auth t] HF [auth b] DD [auth D], ED [auth D], FG [auth d], GH [auth t], HF [auth b], IH [auth x], JD [auth I], KD [auth I], LE [auth a], LH [auth E], ND [auth K], OH [auth e], PG [auth d], QG [auth d], SD [auth T], TC [auth D], UB [auth B], VG [auth i], WG [auth i], XD [auth X], YA [auth A], ZG [auth k]	Unknown ligand JLVVSXFLKOJNIY-UHFFFAOYSA-N		Interactions Focus chain DD [auth D] Focus chain ED [auth D] Focus chain FG [auth d] Focus chain GH [auth t] Focus chain HF [auth b] Focus chain IH [auth x] Focus chain JD [auth I] Focus chain KD [auth I] Focus chain LE [auth a] Focus chain LH [auth E] Focus chain ND [auth K] Focus chain OH [auth e] Focus chain PG [auth d] Focus chain QG [auth d] Focus chain SD [auth T] Focus chain TC [auth D] Focus chain UB [auth B] Focus chain VG [auth i] Focus chain WG [auth i] Focus chain XD [auth X] Focus chain YA [auth A] Focus chain ZG [auth k] Interactions & Density Focus chain DD [auth D] Focus chain ED [auth D] Focus chain FG [auth d] Focus chain GH [auth t] Focus chain HF [auth b] Focus chain IH [auth x] Focus chain JD [auth I] Focus chain KD [auth I] Focus chain LE [auth a] Focus chain LH [auth E] Focus chain ND [auth K] Focus chain OH [auth e] Focus chain PG [auth d] Focus chain QG [auth d] Focus chain SD [auth T] Focus chain TC [auth D] Focus chain UB [auth B] Focus chain VG [auth i] Focus chain WG [auth i] Focus chain XD [auth X] Focus chain YA [auth A] Focus chain ZG [auth k]
