9HIM | pdb_00009him

ManDH5 E303Q in complex with mannotriose after co-crystalliztion with mannohexaose at 1.36 angstroms resolution a beta-D-Mannanase of GH5 family from Dictyoglomus thermophilium

• PDB DOI: https://doi.org/10.2210/pdb9HIM/pdb

• Classification: HYDROLASE
• Organism(s): Dictyoglomus thermophilum
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): Yes


• Deposited: 2024-11-26 Released: 2025-12-10
• Deposition Author(s): Sivron, Y., Romano, A., Shoham, Y., Shoham, G.
• Funding Organization(s): Not funded

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.36 Å
• R-Value Free:
  0.168 (Depositor), 0.169 (DCC)
• R-Value Work:
  0.147 (Depositor), 0.148 (DCC)
• R-Value Observed:
  0.148 (Depositor)

Starting Model: experimental

Literature

ManDH5 E303Q in complex with mannotriose after co-crystalliztion with mannohexaose- a beta-D-Mannanase of GH5 family from Dictyoglomus thermophilium

Sivron, Y., Romano, A., Shoham, Y., Shoham, G.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 67.91 kDa
• Atom Count: 5,277
• Modeled Residue Count: 563
• Deposited Residue Count: 568
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
DUF5060 domain-containing protein	A	568	Dictyoglomus thermophilum	Mutation(s): 1  Gene Names: ENW00_02810
UniProt
Find proteins for A0A7C3MIF0 (Dictyoglomus thermophilum) Explore A0A7C3MIF0  Go to UniProtKB:  A0A7C3MIF0

Oligosaccharides

Help

Entity ID: 2
Molecule	Chains	Length	2D Diagram	Glycosylation	3D Interactions
beta-D-mannopyranose-(1-4)-beta-D-mannopyranose-(1-4)-beta-D-mannopyranose	B [auth C]	3		N/A
Glycosylation Resources
GlyTouCan:  G26320VF GlyCosmos:  G26320VF GlyGen:  G26320VF

Biologically Interesting Molecules (External Reference) 1 Unique

Entity ID: 2
ID	Chains	Name	Type/Class	2D Diagram	3D Interactions
PRD_900009	B [auth C]	alpha-maltotriose	Oligosaccharide / Nutrient

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.36 Å
• R-Value Free:  0.168 (Depositor), 0.169 (DCC)
• R-Value Work:  0.147 (Depositor), 0.148 (DCC)
• R-Value Observed: 0.148 (Depositor)

Space Group: I 2 2 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 95.481	α = 90
b = 99.353	β = 90
c = 153.617	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
XDS	data reduction
xia2	data scaling
PHASER	phasing
Coot	model building

Structure Validation

Entry History & Funding Information

Deposition Data

• Released Date: 2025-12-10
Deposition Author(s): Sivron, Y., Romano, A., Shoham, Y., Shoham, G.

---

Funding Organization	Location	Grant Number
Not funded		--

Revision History

• Version 1.0: 2025-12-10
  Type: Initial release
