9GIJ

Crystal structure of SARS-CoV-2 Mpro with compound 5


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.48 Å
  • R-Value Free: 0.177
  • R-Value Work: 0.135
  • R-Value Observed: 0.139

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.1 of the entry. See complete history


Literature

Rational Design of Macrocyclic Noncovalent Inhibitors of SARS-CoV-2 M pro from a DNA-Encoded Chemical Library Screening Hit That Demonstrate Potent Inhibition against Pan-Coronavirus Homologues and Nirmatrelvir-Resistant Variants.

Wang, X.Gotchev, D.Fan, K.Y.Vega, M.M.Mani, N.McGovern-Gooch, K.Cuconati, A.Tercero, B.Wang, X.Carpino, P.Maskos, K.Centrella, P.A.Schmitt, A.Preuss, F.Prasad, A.Chen, C.Y.Clark, M.A.Guilinger, J.P.Johnstone, S.von Konig, K.Keefe, A.D.Liu, J.Turcotte, S.Zhang, Y.Konz Makino, D.L.Lam, A.M.Cole, A.G.Sofia, M.J.

(2024) J Med Chem 67: 19623-19667

  • DOI: https://doi.org/10.1021/acs.jmedchem.4c02009
  • Primary Citation of Related Structures:
    9GIJ, 9GIL

  • PubMed Abstract:

    The recent global COVID-19 pandemic has highlighted treatments for coronavirus infection as an unmet medical need. The main protease (M pro ) has been an important target for the development of SARS-CoV-2 direct-acting antivirals. Nirmatrelvir as a covalent M pro inhibitor was the first such approved therapy. Although M pro inhibitors of various chemical classes have been reported, they are generally less active against nirmatrelvir-resistant variants and have limited pan-coronavirus potential, presenting a significant human health risk upon future outbreaks. We here present a novel approach and utilized DNA-encoded chemical library screening to identify the noncovalent M pro inhibitor 5 , which demonstrated a distinct binding mode to nirmatrelvir. A macrocyclization strategy designed to lock the active conformation resulted in lactone 12 with significantly improved antiviral activity. Further optimization led to the potent lactam 26 , which demonstrated exceptional potency against nirmatrelvir-resistant variants as well as against a panel of viral main proteases from other coronaviruses.


  • Organizational Affiliation

    Arbutus Biopharma Inc., 701 Veterans Circle, Warminster, Pennsylvania 18974, United States.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
3C-like proteinase nsp5306Severe acute respiratory syndrome coronavirus 2Mutation(s): 0
EC: 3.4.22.69
UniProt
Find proteins for P0DTC1 (Severe acute respiratory syndrome coronavirus 2)
Explore P0DTC1
Go to UniProtKB:  P0DTC1
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0DTC1
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
A1IL0 (Subject of Investigation/LOI)
Query on A1IL0

Download Ideal Coordinates CCD File
B [auth A](2~{R})-3-(4-chlorophenyl)-2-[2-[(2~{R})-1-isoquinolin-4-ylcarbonylpyrrolidin-2-yl]ethanoyl-methyl-amino]-~{N}-methyl-propanamide
C27 H29 Cl N4 O3
UIMIIFFPUAFUFK-ZJSXRUAMSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.48 Å
  • R-Value Free: 0.177
  • R-Value Work: 0.135
  • R-Value Observed: 0.139
  • Space Group: C 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 98.15α = 90
b = 81.226β = 114.78
c = 51.732γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
PDB_EXTRACTdata extraction
XDSdata reduction
Aimlessdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Not funded--

Revision History  (Full details and data files)

  • Version 1.0: 2024-11-06
    Type: Initial release
  • Version 1.1: 2024-11-27
    Changes: Database references
