9EBG | pdb_00009ebg

Crystal structure of the hERalpha LBD complexed with androstenediol and SRC 2-2 peptide

• PDB DOI: https://doi.org/10.2210/pdb9EBG/pdb

• Classification: NUCLEAR PROTEIN
• Organism(s): Homo sapiens
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): No


• Deposited: 2024-11-12 Released: 2025-11-19
• Deposition Author(s): Pederick, J.L., Bruning, J.B.
• Funding Organization(s): Australian Research Council (ARC)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.02 Å
• R-Value Free:
  0.248 (Depositor), 0.248 (DCC)
• R-Value Work:
  0.205 (Depositor), 0.205 (DCC)
• R-Value Observed:
  0.207 (Depositor)

Starting Model: experimental

Literature

Crystal structure of the hERalpha LBD complexed with androstenediol and SRC 2-2 peptide

Pederick, J.L., Bruning, J.B.

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Hetero 4-mer - A2B2 Pseudo Symmetry: Asymmetric - C1
Pseudo Stoichiometry: Hetero 4-mer - A2B1C1

Biological assembly 1 assigned by authors.

Biological Assembly Evidence: mass spectrometry

Macromolecule Content

• Total Structure Weight: 59.38 kDa
• Atom Count: 3,984
• Modeled Residue Count: 488
• Deposited Residue Count: 512
• Unique protein chains: 2

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Nuclear receptor coactivator 2	A [auth B], B [auth D]	13	Homo sapiens	Mutation(s): 0
UniProt & NIH Common Fund Data Resources
Find proteins for Q15596 (Homo sapiens) Explore Q15596  Go to UniProtKB:  Q15596
PHAROS:  Q15596 GTEx:  ENSG00000140396

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
Estrogen receptor	C [auth A], D [auth C]	243	Homo sapiens	Mutation(s): 0  Gene Names: ESR1, ESR, NR3A1
UniProt & NIH Common Fund Data Resources
Find proteins for P03372 (Homo sapiens) Explore P03372  Go to UniProtKB:  P03372
PHAROS:  P03372 GTEx:  ENSG00000091831

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
B81 (Subject of Investigation/LOI)	E [auth A], F [auth C]	(3alpha,8alpha,17beta)-androst-5-ene-3,17-diol C19 H30 O2 QADHLRWLCPCEKT-LOVVWNRFSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.02 Å
• R-Value Free:  0.248 (Depositor), 0.248 (DCC)
• R-Value Work:  0.205 (Depositor), 0.205 (DCC)
• R-Value Observed: 0.207 (Depositor)

Space Group: P 3₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 83.401	α = 90
b = 83.401	β = 90
c = 58.553	γ = 120

Software Package:

Software Name	Purpose
PHENIX	refinement
Aimless	data scaling
XDS	data reduction
PHASER	phasing

Structure Validation

Entry History & Funding Information

Deposition Data

• Released Date: 2025-11-19
Deposition Author(s): Pederick, J.L., Bruning, J.B.

---

Funding Organization	Location	Grant Number
Australian Research Council (ARC)	Australia	DP230100609

Revision History

• Version 1.0: 2025-11-19
  Type: Initial release
