9BJF

Tungstate binding protein (Tungbindin) from Eubacterium limosum in apo form

• PDB DOI: https://doi.org/10.2210/pdb9BJF/pdb

• Classification: METAL BINDING PROTEIN
• Organism(s): Eubacterium limosum
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): No


• Deposited: 2024-04-25 Released: 2024-09-04
• Deposition Author(s): Zhou, D., Rose, J.P., Chen, L., Wang, B.C.
• Funding Organization(s): National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.89 Å
• R-Value Free: 0.323
• R-Value Work: 0.284
• R-Value Observed: 0.288

Starting Model: in silico

Literature

Tungstate binding protein (Tungbindin) from Eubacterium limosum in apo form

Zhou, D., Rose, J.P., Chen, L., Wang, B.C.

To be published.

Biological Assembly 1

Global Symmetry: Dihedral - D3  (Explore in 3D)
Global Stoichiometry: Homo 6-mer - A6

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly Evidence: gel filtration

Macromolecule Content

• Total Structure Weight: 50.11 kDa
• Atom Count: 3,013
• Modelled Residue Count: 414
• Deposited Residue Count: 468
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Molybdenum-pterin binding domain-containing protein	A, B, C, D, E, F	78	Eubacterium limosum	Mutation(s): 0  Gene Names: C7955_103236, SAMN04515624_10415
UniProt
Find proteins for A0A0U3FVB3 (Eubacterium limosum) Explore A0A0U3FVB3  Go to UniProtKB:  A0A0U3FVB3

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
SO4 (Subject of Investigation/LOI)	G [auth A], H [auth B], I [auth B], J [auth C], K [auth C], L [auth D], M [auth E], N [auth F]	SULFATE ION O4 S QAOWNCQODCNURD-UHFFFAOYSA-L

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.89 Å
• R-Value Free: 0.323
• R-Value Work: 0.284
• R-Value Observed: 0.288
• Space Group: P 4₃ 2₁ 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 75.441	α = 90
b = 75.441	β = 90
c = 248.697	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
HKL-3000	data scaling
HKL-3000	data reduction
PHASER	phasing

Structure Validation

Entry History & Funding Information

Deposition Data

• Released Date: 2024-09-04
Deposition Author(s): Zhou, D., Rose, J.P., Chen, L., Wang, B.C.

---

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)	United States	GM 136885

Revision History

• Version 1.0: 2024-09-04
  Type: Initial release
