9ZRA | pdb_00009zra

Crystal structure of macrodomain from Chikungunya virus

PDB DOI: https://doi.org/10.2210/pdb9ZRA/pdb

Classification: VIRAL PROTEIN
Organism(s): Chikungunya virus
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2025-12-19 Released: 2026-08-12
Deposition Author(s): Chang, C., Endre, M., Stols, L., Kim, Y., Joachimiak, A.
Funding Organization(s): Department of Energy (DOE, United States)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.30 Å
R-Value Free:
0.186 (Depositor), 0.187 (DCC)
R-Value Work:
0.156 (Depositor), 0.156 (DCC)
R-Value Observed:
0.157 (Depositor)

Starting Model: in silico
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 9ZRA

This is version 1.0 of the entry. See complete history.

Literature

Crystal structure of macrodomain from Chikungunya virus

Chang, C., Endre, M., Stols, L., Kim, Y., Joachimiak, A.

To be published.

Macromolecule Content

Total Structure Weight: 18.03 kDa
Atom Count: 1,549
Modeled Residue Count: 162
Deposited Residue Count: 163
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Polyprotein P1234	A	163	Chikungunya virus	Mutation(s): 0
UniProt
Find proteins for D0U7D9 (Chikungunya virus) Explore D0U7D9 Go to UniProtKB: D0U7D9
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	D0U7D9
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
GOL Query on GOL Download:Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	GLYCEROL C₃ H₈ O₃ PEDCQBHIVMGVHV-UHFFFAOYSA-N		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]
EDO Query on EDO Download:Ideal Coordinates CCD File SDF format, chain C [auth A] SDF format, chain D [auth A] MOL2 format, chain C [auth A] MOL2 format, chain D [auth A] mmCIF format, chain C [auth A] mmCIF format, chain D [auth A]	C [auth A], D [auth A]	1,2-ETHANEDIOL C₂ H₆ O₂ LYCAIKOWRPUZTN-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Focus chain D [auth A] Interactions & Density Focus chain C [auth A] Focus chain D [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.30 Å
R-Value Free: 0.186 (Depositor), 0.187 (DCC)
R-Value Work: 0.156 (Depositor), 0.156 (DCC)
R-Value Observed: 0.157 (Depositor)

Space Group: P 4₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 41.031	α = 90
b = 41.031	β = 90
c = 103.877	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
HKL-3000	data scaling
PDB_EXTRACT	data extraction
DENZO	data reduction
HKL-3000	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2026-08-12

Deposition Author(s):

Funding Organization	Location	Grant Number
Department of Energy (DOE, United States)	United States	--

Revision History (Full details and data files)

Version 1.0: 2026-08-12
Type: Initial release
