9YO4 | pdb_00009yo4

Crystal structure of integrin a4b1 headpiece in complex with MR128 (Mn)

PDB DOI: https://doi.org/10.2210/pdb9YO4/pdb

Classification: CELL ADHESION
Organism(s): Homo sapiens
Expression System: Homo sapiens
Mutation(s): No

Deposited: 2025-10-13 Released: 2026-10-21
Deposition Author(s): Monroy, M.F., Lin, F.Y., Qiao, Q.
Funding Organization(s): Not funded

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.22 Å
R-Value Free:
0.263 (Depositor), 0.267 (DCC)
R-Value Work:
0.240 (Depositor), 0.245 (DCC)
R-Value Observed:
0.241 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.0 of the entry. See complete history.

Literature

Crystal structure of a4b1 headpiece in complex with MR128 (Mn)

Monroy, M.F., Lin, F.Y.

To be published.

Macromolecule Content

Total Structure Weight: 123.44 kDa
Atom Count: 8,312
Modeled Residue Count: 1,037
Deposited Residue Count: 1,087
Unique protein chains: 2

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Integrin a4	A	597	Homo sapiens	Mutation(s): 0
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
Glycosylation
Glycosylation Sites: 5	Glycosylation Focus chain A
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

| 3D Structure

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
Integrin beta-1	B	490	Homo sapiens	Mutation(s): 0 Gene Names: ITGB1, FNRB, MDF2, MSK12
UniProt & NIH Common Fund Data Resources
Find proteins for P05556 (Homo sapiens) Explore P05556 Go to UniProtKB: P05556
PHAROS: P05556 GTEx: ENSG00000150093
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P05556
Glycosylation
Glycosylation Sites: 1	Glycosylation Focus chain B	Go to GlyGen: P05556-1
Sequence Annotations Expand
Reference Sequence

Oligosaccharides

Help

Entity ID: 3
Molecule	Chains	Length	2D Diagram	Glycosylation	D Interactions
beta-D-mannopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose	C	3		N-Glycosylation	Interactions Focus chain C Interactions & Density Focus chain C

Entity ID: 4
Molecule	Chains	Length	2D Diagram	Glycosylation	D Interactions
alpha-D-mannopyranose-(1-6)-beta-D-mannopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose	D [auth E]	4		N-Glycosylation	Interactions Focus chain D [auth E] Interactions & Density Focus chain D [auth E]

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
A1CYR Query on A1CYR Download:Ideal Coordinates CCD File SDF format, chain P [auth B] MOL2 format, chain P [auth B] mmCIF format, chain P [auth B]	P [auth B]	(2S)-(2,6-difluorobenzamido)(4-hydroxy-1-{[(2S)-1-({4-[(2-methylphenyl)carbamamido]phenyl}acetyl)pyrrolidin-2-yl]methyl}piperidin-4-yl)acetic acid C₃₅ H₃₉ F₂ N₅ O₆ MTKQIGZCFWWMGF-VVFBEHOQSA-N		Interactions Focus chain P [auth B] Interactions & Density Focus chain P [auth B]
NAG Query on NAG Download:Ideal Coordinates CCD File SDF format, chain H [auth A] SDF format, chain I [auth A] SDF format, chain J [auth A] SDF format, chain N [auth B] SDF format, chain O [auth B] MOL2 format, chain H [auth A] MOL2 format, chain I [auth A] MOL2 format, chain J [auth A] MOL2 format, chain N [auth B] MOL2 format, chain O [auth B] mmCIF format, chain H [auth A] mmCIF format, chain I [auth A] mmCIF format, chain J [auth A] mmCIF format, chain N [auth B] mmCIF format, chain O [auth B]	H [auth A], I [auth A], J [auth A], N [auth B], O [auth B]	2-acetamido-2-deoxy-beta-D-glucopyranose C₈ H₁₅ N O₆ OVRNDRQMDRJTHS-FMDGEEDCSA-N		Interactions Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A] Focus chain N [auth B] Focus chain O [auth B] Interactions & Density Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A] Focus chain N [auth B] Focus chain O [auth B]
MN Query on MN Download:Ideal Coordinates CCD File SDF format, chain M [auth B] SDF format, chain L [auth B] SDF format, chain K [auth B] SDF format, chain G [auth A] SDF format, chain F [auth A] SDF format, chain E [auth A] MOL2 format, chain M [auth B] MOL2 format, chain L [auth B] MOL2 format, chain K [auth B] MOL2 format, chain G [auth A] MOL2 format, chain F [auth A] MOL2 format, chain E [auth A] mmCIF format, chain M [auth B] mmCIF format, chain L [auth B] mmCIF format, chain K [auth B] mmCIF format, chain G [auth A] mmCIF format, chain F [auth A] mmCIF format, chain E [auth A]	E [auth A] F [auth A] G [auth A] K [auth B] L [auth B] E [auth A], F [auth A], G [auth A], K [auth B], L [auth B], M [auth B]	MANGANESE (II) ION Mn WAEMQWOKJMHJLA-UHFFFAOYSA-N		Interactions Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain K [auth B] Focus chain L [auth B] Focus chain M [auth B] Interactions & Density Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain K [auth B] Focus chain L [auth B] Focus chain M [auth B]
