9YIZ | pdb_00009yiz

Crystal structure of yeast coatomer alpha-WD40 domain H31A mutant

PDB DOI: https://doi.org/10.2210/pdb9YIZ/pdb

Classification: PROTEIN TRANSPORT
Organism(s): Schizosaccharomyces pombe
Expression System: Escherichia coli
Mutation(s): Yes

Deposited: 2025-10-02 Released: 2026-10-07
Deposition Author(s): Shakya, A.K., Hasan, S.S.
Funding Organization(s): National Institutes of Health/Office of the Director

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.72 Å
R-Value Free:
0.205 (Depositor), 0.205 (DCC)
R-Value Work:
0.164 (Depositor), 0.164 (DCC)
R-Value Observed:
0.165 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 9YIZ

This is version 1.0 of the entry. See complete history.

Literature

Crystal structure of yeast coatomer alpha-WD40 domain H31A mutant

Shakya, A.K., Hasan, S.S.

To be published.

Macromolecule Content

Total Structure Weight: 113.08 kDa
Atom Count: 8,297
Modeled Residue Count: 918
Deposited Residue Count: 984
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Putative coatomer subunit alpha	A, B, C	328	Schizosaccharomyces pombe	Mutation(s): 6 Gene Names: SPBPJ4664.04
UniProt
Find proteins for Q96WV5 (Schizosaccharomyces pombe (strain 972 / ATCC 24843)) Explore Q96WV5 Go to UniProtKB: Q96WV5
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q96WV5
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.72 Å
R-Value Free: 0.205 (Depositor), 0.205 (DCC)
R-Value Work: 0.164 (Depositor), 0.164 (DCC)
R-Value Observed: 0.165 (Depositor)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 36.656	α = 90
b = 172.117	β = 98.71
c = 70.998	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
HKL-3000	data reduction
XDS	data scaling
PHASER	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2026-10-07

Deposition Author(s):

Funding Organization	Location	Grant Number
National Institutes of Health/Office of the Director	United States	R01GM150187

Revision History (Full details and data files)

Version 1.0: 2026-10-07
Type: Initial release
