9Y7K | pdb_00009y7k

Importin a2 in complex with Guertu virus non-structural S (NSs) NLS peptide

PDB DOI: https://doi.org/10.2210/pdb9Y7K/pdb

Classification: TRANSPORT PROTEIN
Organism(s): Mus musculus, Bandavirus guertuense
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2025-09-10 Released: 2025-09-24
Deposition Author(s): Hawker, J.E., Forwood, J.K.
Funding Organization(s): Not funded

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.25 Å
R-Value Free:
0.205 (Depositor), 0.205 (DCC)
R-Value Work:
0.191 (Depositor), 0.191 (DCC)
R-Value Observed:
0.192 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 9Y7K

This is version 1.0 of the entry. See complete history.

Literature

Importin a2 in complex with Guertu virus non-structural S (NSs) NLS peptide

Hawker, J.E., Forwood, J.K.

To be published.

Macromolecule Content

Total Structure Weight: 58.09 kDa
Atom Count: 3,412
Modeled Residue Count: 433
Deposited Residue Count: 534
Unique protein chains: 2

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Importin subunit alpha-1	A	510	Mus musculus	Mutation(s): 0 Gene Names: Kpna2, Rch1
UniProt & NIH Common Fund Data Resources
Find proteins for P52293 (Mus musculus) Explore P52293 Go to UniProtKB: P52293
IMPC: MGI:103561
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P52293
Sequence Annotations Expand
Reference Sequence

Find similar proteins by: Sequence | 3D Structure

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
Non-structural S NLS peptide	B	24	Bandavirus guertuense	Mutation(s): 0

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.25 Å
R-Value Free: 0.205 (Depositor), 0.205 (DCC)
R-Value Work: 0.191 (Depositor), 0.191 (DCC)
R-Value Observed: 0.192 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 78.41	α = 90
b = 89.648	β = 90
c = 98.749	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
MOSFLM	data reduction
Aimless	data scaling
PHASER	phasing
Coot	model building

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2025-09-24

Deposition Author(s):

Funding Organization	Location	Grant Number
Not funded		--

Revision History (Full details and data files)

Version 1.0: 2025-09-24
Type: Initial release
