9XQB | pdb_00009xqb

Cryo-EM structure of the human A2A adenosine receptor in complex with a Fab antibody fragment


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.45 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

Validation slider image for 9XQB

This is version 1.1 of the entry. See complete history

Literature

Rapid and Label-Free Structural Proteomics Using One-Step Swift Trypsin LiP-MS.

Miyashita, Y.Konno, R.Ogasawara, S.Okuda, Y.Takamuku, Y.Moriya, T.Saito, T.Murata, T.Ohara, O.Kawashima, Y.

(2026) ACS Omega 11: 2152-2162

  • DOI: https://doi.org/10.1021/acsomega.5c11109
  • Primary Citation Related Structures:
    9XQB

  • PubMed Abstract:

    Limited proteolysis mass spectrometry (LiP-MS) is a powerful approach for probing protein conformational changes on a proteome-wide scale. However, conventional workflows rely on a two-step digestion with proteinase K and trypsin, which increases complexity and reduces reproducibility and sensitivity. This study aimed to develop a simplified one-step protocol, termed Swift Trypsin LiP-MS (STLiP-MS), which uses a trypsin-immobilized spin column and high-speed centrifugation to achieve rapid and reproducible surface-limited proteolysis. Using HEK293 cell extracts, STLiP-MS identified 286 proteins exhibiting conformational changes upon phosphatase inhibition, including 37 enriched in phosphatase-related Gene Ontology categories. The method improvements, including suppression of predigestion and immediate enzyme inactivation, further increased sensitivity, enabling the detection of 799 proteins with structural alterations, of which 77 were enriched in phosphatase-related categories. Comparison with the single-pot solid-phase-enhanced sample preparation (SP3) method confirmed that these changes originated from structure-selective proteolysis and were not detectable under fully denaturing conditions. To demonstrate its broader applicability, we applied STLiP-MS to the adenosine A 2A receptor (A 2A -BRIL) and observed antibody-induced protection of extracellular loop 2 (residues 147-176). Cryogenic electron microscopy validated Fab fragment binding to the same region, confirming the correspondence between STLiP-MS signals and actual antibody-antigen interfaces. Collectively, these results show that STLiP-MS is a rapid and robust platform that enables sensitive, label-free detection of local structural changes under near-physiological conditions and accurate prediction of protein-protein interaction sites. This method holds great promise for applications in structural proteomics and drug target identification.


  • Organizational Affiliation
    • Department of Applied Genomics, Kazusa DNA Research Institute, 2-6-7 Kazusa-kamatari, Kisarazu, Chiba 292-0818, Japan.

Macromolecule Content

  • Total Structure Weight: 77.15 kDa
  • Atom Count: 2,932
  • Modeled Residue Count: 453
  • Deposited Residue Count: 694
  • Unique protein chains: 3

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Fab Light chainA [auth B]127Mus musculusMutation(s): 0
Find similar proteins by:|  3D Structure
Entity ID: 2
MoleculeChains  Sequence LengthOrganismDetailsImage
A2A receptor-BRILB [auth C]431Homo sapiensMutation(s): 0
UniProt & NIH Common Fund Data Resources
Find proteins for P29274 (Homo sapiens)
Explore P29274
Go to UniProtKB:  P29274
PHAROS:  P29274
GTEx:  ENSG00000128271
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP29274
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 3
MoleculeChains  Sequence LengthOrganismDetailsImage
Fab Heavy chainC [auth A]136Mus musculusMutation(s): 0

Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.45 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE
EM Software:
TaskSoftware PackageVersion
MODEL REFINEMENTPHENIX1.21.2_5419
RECONSTRUCTIONcryoSPARC

Structure Validation

View Full Validation Report



Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Japan Society for the Promotion of Science (JSPS)Japan23K27158, 25K18417
Japan Agency for Medical Research and Development (AMED)JapanJP25ama121013
Kazusa DNA Research Institute FoundationJapan--

Revision History  (Full details and data files)

  • Version 1.0: 2026-01-07
    Type: Initial release
  • Version 1.1: 2026-02-04
    Changes: Data collection, Database references
