9WEH | pdb_00009weh

Plasmodium vivax aspartyl-tRNA synthetase in complex with Asp-AMS, SO4, MOPSO and Butanetriol

PDB DOI: https://doi.org/10.2210/pdb9WEH/pdb

Classification: LIGASE
Organism(s): Plasmodium vivax
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2025-08-19 Released: 2026-09-02
Deposition Author(s): Manickam, Y., Sharma, V.K., Bagale, S., Pradeepkumar, P.I., Sharma, A.
Funding Organization(s): Department of Biotechnology (DBT, India), Indian Council of Medical Research

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.09 Å
R-Value Free:
0.211 (Depositor), 0.212 (DCC)
R-Value Work:
0.175 (Depositor), 0.182 (DCC)
R-Value Observed:
0.177 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 9WEH

Ligand Structure Quality Assessment

This is version 1.0 of the entry. See complete history.

Literature

The active site of aspartyl-tRNA synthetase: Structural studies of the adenylation reaction and flexibility of residues.

Sharma, V.K., Manickam, Y., Sharma, A.

To be published.

Macromolecule Content

Total Structure Weight: 126.74 kDa
Atom Count: 9,055
Modeled Residue Count: 1,006
Deposited Residue Count: 1,072
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
aspartate--tRNA ligase	A, B	536	Plasmodium vivax	Mutation(s): 0 Gene Names: PVC01_020016700, PVW1_020019400 EC: 6.1.1.12
UniProt
Find proteins for A0A1G4H6Y1 (Plasmodium vivax) Explore A0A1G4H6Y1 Go to UniProtKB: A0A1G4H6Y1
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	A0A1G4H6Y1
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 7 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
DSZ (Subject of Investigation/LOI) Query on DSZ Download:Ideal Coordinates CCD File SDF format, chain C [auth A] SDF format, chain J [auth B] MOL2 format, chain C [auth A] MOL2 format, chain J [auth B] mmCIF format, chain C [auth A] mmCIF format, chain J [auth B]	C [auth A], J [auth B]	5'-O-(L-alpha-aspartylsulfamoyl)adenosine C₁₄ H₁₉ N₇ O₉ S KMRBRMHHDAUXAY-UFIIOMENSA-N		Interactions Focus chain C [auth A] Focus chain J [auth B] Interactions & Density Focus chain C [auth A] Focus chain J [auth B]
6BX (Subject of Investigation/LOI) Query on 6BX Download:Ideal Coordinates CCD File SDF format, chain F [auth A] MOL2 format, chain F [auth A] mmCIF format, chain F [auth A]	F [auth A]	(2S)-2-hydroxy-3-(morpholin-4-yl)propane-1-sulfonic acid C₇ H₁₅ N O₅ S NUFBIAUZAMHTSP-ZETCQYMHSA-N		Interactions Focus chain F [auth A] Interactions & Density Focus chain F [auth A]
PGE (Subject of Investigation/LOI) Query on PGE Download:Ideal Coordinates CCD File SDF format, chain R [auth B] MOL2 format, chain R [auth B] mmCIF format, chain R [auth B]	R [auth B]	TRIETHYLENE GLYCOL C₆ H₁₄ O₄ ZIBGPFATKBEMQZ-UHFFFAOYSA-N		Interactions Focus chain R [auth B] Interactions & Density Focus chain R [auth B]
0V1 (Subject of Investigation/LOI) Query on 0V1 Download:Ideal Coordinates CCD File SDF format, chain N [auth B] SDF format, chain M [auth B] SDF format, chain G [auth A] SDF format, chain E [auth A] MOL2 format, chain N [auth B] MOL2 format, chain M [auth B] MOL2 format, chain G [auth A] MOL2 format, chain E [auth A] mmCIF format, chain N [auth B] mmCIF format, chain M [auth B] mmCIF format, chain G [auth A] mmCIF format, chain E [auth A]	E [auth A], G [auth A], M [auth B], N [auth B]	(2~{S})-butane-1,2,4-triol C₄ H₁₀ O₃ ARXKVVRQIIOZGF-BYPYZUCNSA-N		Interactions Focus chain E [auth A] Focus chain G [auth A] Focus chain M [auth B] Focus chain N [auth B] Interactions & Density Focus chain E [auth A] Focus chain G [auth A] Focus chain M [auth B] Focus chain N [auth B]
PEG (Subject of Investigation/LOI) Query on PEG Download:Ideal Coordinates CCD File SDF format, chain P [auth B] MOL2 format, chain P [auth B] mmCIF format, chain P [auth B]	P [auth B]	DI(HYDROXYETHYL)ETHER C₄ H₁₀ O₃ MTHSVFCYNBDYFN-UHFFFAOYSA-N		Interactions Focus chain P [auth B] Interactions & Density Focus chain P [auth B]
SO4 (Subject of Investigation/LOI) Query on SO4 Download:Ideal Coordinates CCD File SDF format, chain L [auth B] SDF format, chain K [auth B] SDF format, chain D [auth A] MOL2 format, chain L [auth B] MOL2 format, chain K [auth B] MOL2 format, chain D [auth A] mmCIF format, chain L [auth B] mmCIF format, chain K [auth B] mmCIF format, chain D [auth A]	D [auth A], K [auth B], L [auth B]	SULFATE ION O₄ S QAOWNCQODCNURD-UHFFFAOYSA-L		Interactions Focus chain D [auth A] Focus chain K [auth B] Focus chain L [auth B] Interactions & Density Focus chain D [auth A] Focus chain K [auth B] Focus chain L [auth B]
GOL (Subject of Investigation/LOI) Query on GOL Download:Ideal Coordinates CCD File SDF format, chain Q [auth B] SDF format, chain O [auth B] SDF format, chain I [auth A] SDF format, chain H [auth A] MOL2 format, chain Q [auth B] MOL2 format, chain O [auth B] MOL2 format, chain I [auth A] MOL2 format, chain H [auth A] mmCIF format, chain Q [auth B] mmCIF format, chain O [auth B] mmCIF format, chain I [auth A] mmCIF format, chain H [auth A]	H [auth A], I [auth A], O [auth B], Q [auth B]	GLYCEROL C₃ H₈ O₃ PEDCQBHIVMGVHV-UHFFFAOYSA-N		Interactions Focus chain H [auth A] Focus chain I [auth A] Focus chain O [auth B] Focus chain Q [auth B] Interactions & Density Focus chain H [auth A] Focus chain I [auth A] Focus chain O [auth B] Focus chain Q [auth B]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.09 Å
R-Value Free: 0.211 (Depositor), 0.212 (DCC)
R-Value Work: 0.175 (Depositor), 0.182 (DCC)
R-Value Observed: 0.177 (Depositor)

Space Group: P 6₁ 2 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 139.779	α = 90
b = 139.779	β = 90
c = 274.11	γ = 120

Software Package:

Software Name	Purpose
PHENIX	refinement
autoPROC	data scaling
autoPROC	data reduction
PHASER	phasing
PDB_EXTRACT	data extraction

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2026-09-02

Deposition Author(s):

Pradeepkumar, P.I.

Funding Organization	Location	Grant Number
Department of Biotechnology (DBT, India)	India	PR32713
Indian Council of Medical Research	India	CAR grant 2024-000140

Revision History (Full details and data files)

Version 1.0: 2026-09-02
Type: Initial release
