9W78 | pdb_00009w78

Rhinolophus cornutus Bat ACE2 Dimer in Complex with Two Rc-o319 Sarbecovirus Spike RBDs.

PDB DOI: https://doi.org/10.2210/pdb9W78/pdb
EM Map EMD-65720: EMDB EMDataResource

Classification: VIRAL PROTEIN/HYDROLASE
Organism(s): Sarbecovirus, Rhinolophus cornutus
Expression System: Homo sapiens
Mutation(s): No

Deposited: 2025-08-05 Released: 2025-10-29
Deposition Author(s): Wang, J., Li, Z.X., Li, Z.M., Hang, Y., Xiong, X.
Funding Organization(s): National Natural Science Foundation of China (NSFC)

Experimental Data Snapshot

Method: ELECTRON MICROSCOPY
Resolution: 2.30 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

Validation slider image for 9W78

This is version 1.0 of the entry. See complete history.

Literature

The complex between sarbecovirus Rc-o319-RBD and R.cor bat ACE2

Wang, J., Xiong, X.

To be published.

Macromolecule Content

Total Structure Weight: 112.03 kDa
Atom Count: 7,299
Modeled Residue Count: 868
Deposited Residue Count: 945
Unique protein chains: 2

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Spike protein S1	A [auth D]	214	Sarbecovirus	Mutation(s): 0

Find similar proteins by:

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
Angiotensin-converting enzyme	B [auth C]	731	Rhinolophus cornutus	Mutation(s): 0 Gene Names: RcACE2 EC: 3.4
UniProt
Find proteins for A0A7R7AIC6 (Rhinolophus cornutus) Explore A0A7R7AIC6 Go to UniProtKB: A0A7R7AIC6
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	A0A7R7AIC6
Glycosylation
Glycosylation Sites: 6	Glycosylation Focus chain B [auth C]
Sequence Annotations Expand
Reference Sequence

Oligosaccharides

Entity ID: 3
Molecule	Chains	Length	2D Diagram	Glycosylation	D Interactions
2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose	C [auth A], D [auth B], E	2		N-Glycosylation	Interactions Focus chain C [auth A] Focus chain D [auth B] Focus chain E Interactions & Density Focus chain C [auth A] Focus chain D [auth B] Focus chain E
Glycosylation Resources
GlyTouCan: G42666HT GlyCosmos: G42666HT GlyGen: G42666HT

Entity ID: 4
Molecule	Chains	Length	2D Diagram	Glycosylation	D Interactions
alpha-D-mannopyranose-(1-2)-alpha-D-mannopyranose-(1-3)-[alpha-D-mannopyranose-(1-6)]beta-D-mannopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose	F	6		N-Glycosylation	Interactions Focus chain F Interactions & Density Focus chain F
Glycosylation Resources
GlyTouCan: G56014GC GlyCosmos: G56014GC GlyGen: G56014GC

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
NAG (Subject of Investigation/LOI) Query on NAG Download:Ideal Coordinates CCD File SDF format, chain G [auth C] SDF format, chain H [auth C] MOL2 format, chain G [auth C] MOL2 format, chain H [auth C] mmCIF format, chain G [auth C] mmCIF format, chain H [auth C]	G [auth C], H [auth C]	2-acetamido-2-deoxy-beta-D-glucopyranose C₈ H₁₅ N O₆ OVRNDRQMDRJTHS-FMDGEEDCSA-N		Interactions Focus chain G [auth C] Focus chain H [auth C] Interactions & Density Focus chain G [auth C] Focus chain H [auth C]

Experimental Data & Validation

Experimental Data

Method: ELECTRON MICROSCOPY
Resolution: 2.30 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

EM Software:

Task	Software Package	Version
MODEL REFINEMENT	PHENIX
RECONSTRUCTION	cryoSPARC

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2025-10-29

Deposition Author(s):

Funding Organization	Location	Grant Number
National Natural Science Foundation of China (NSFC)	China	82341085

Revision History (Full details and data files)

Version 1.0: 2025-10-29
Type: Initial release
