9VWC | pdb_00009vwc

Structure of V.cholerae dGTPase H114A octamer bound to dGTP and dAMP

PDB DOI: https://doi.org/10.2210/pdb9VWC/pdb
EM Map EMD-65393: EMDB EMDataResource

Classification: HYDROLASE
Organism(s): Vibrio cholerae
Expression System: Escherichia coli
Mutation(s): Yes

Deposited: 2025-07-16 Released: 2026-07-22
Deposition Author(s): Shi, M., Li, P.P., Li, Q.J., Gao, A.
Funding Organization(s): Not funded

Experimental Data Snapshot

Method: ELECTRON MICROSCOPY
Resolution: 2.96 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

Validation slider image for 9VWC

This is version 1.0 of the entry. See complete history.

Literature

Structure of Vdg octamer

Shi, M.

To be published.

Macromolecule Content

Total Structure Weight: 373.96 kDa
Atom Count: 26,216
Modeled Residue Count: 3,216
Deposited Residue Count: 3,216
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Deoxyguanosinetriphosphate triphosphohydrolase-like protein	A, B, C, D, E A, B, C, D, E, F, G, H	402	Vibrio cholerae	Mutation(s): 1 Gene Names: dgt, D6U24_19295, ERS013200_04025, KIN13_18180
UniProt
Find proteins for A0A0H6GV99 (Vibrio cholerae) Explore A0A0H6GV99 Go to UniProtKB: A0A0H6GV99
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	A0A0H6GV99
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
DGT (Subject of Investigation/LOI) Query on DGT Download:Ideal Coordinates CCD File SDF format, chain J [auth A] SDF format, chain L [auth B] SDF format, chain N [auth C] SDF format, chain P [auth D] SDF format, chain R [auth E] SDF format, chain T [auth F] SDF format, chain V [auth G] SDF format, chain X [auth H] MOL2 format, chain J [auth A] MOL2 format, chain L [auth B] MOL2 format, chain N [auth C] MOL2 format, chain P [auth D] MOL2 format, chain R [auth E] MOL2 format, chain T [auth F] MOL2 format, chain V [auth G] MOL2 format, chain X [auth H] mmCIF format, chain J [auth A] mmCIF format, chain L [auth B] mmCIF format, chain N [auth C] mmCIF format, chain P [auth D] mmCIF format, chain R [auth E] mmCIF format, chain T [auth F] mmCIF format, chain V [auth G] mmCIF format, chain X [auth H]	J [auth A] L [auth B] N [auth C] P [auth D] R [auth E] J [auth A], L [auth B], N [auth C], P [auth D], R [auth E], T [auth F], V [auth G], X [auth H]	2'-DEOXYGUANOSINE-5'-TRIPHOSPHATE C₁₀ H₁₆ N₅ O₁₃ P₃ HAAZLUGHYHWQIW-KVQBGUIXSA-N		Interactions Focus chain J [auth A] Focus chain L [auth B] Focus chain N [auth C] Focus chain P [auth D] Focus chain R [auth E] Focus chain T [auth F] Focus chain V [auth G] Focus chain X [auth H] Interactions & Density Focus chain J [auth A] Focus chain L [auth B] Focus chain N [auth C] Focus chain P [auth D] Focus chain R [auth E] Focus chain T [auth F] Focus chain V [auth G] Focus chain X [auth H]
D5M (Subject of Investigation/LOI) Query on D5M Download:Ideal Coordinates CCD File SDF format, chain I [auth A] SDF format, chain K [auth B] SDF format, chain M [auth C] SDF format, chain O [auth D] SDF format, chain Q [auth E] SDF format, chain S [auth F] SDF format, chain U [auth G] SDF format, chain W [auth H] MOL2 format, chain I [auth A] MOL2 format, chain K [auth B] MOL2 format, chain M [auth C] MOL2 format, chain O [auth D] MOL2 format, chain Q [auth E] MOL2 format, chain S [auth F] MOL2 format, chain U [auth G] MOL2 format, chain W [auth H] mmCIF format, chain I [auth A] mmCIF format, chain K [auth B] mmCIF format, chain M [auth C] mmCIF format, chain O [auth D] mmCIF format, chain Q [auth E] mmCIF format, chain S [auth F] mmCIF format, chain U [auth G] mmCIF format, chain W [auth H]	I [auth A] K [auth B] M [auth C] O [auth D] Q [auth E] I [auth A], K [auth B], M [auth C], O [auth D], Q [auth E], S [auth F], U [auth G], W [auth H]	2'-DEOXYADENOSINE-5'-MONOPHOSPHATE C₁₀ H₁₄ N₅ O₆ P KHWCHTKSEGGWEX-RRKCRQDMSA-N		Interactions Focus chain I [auth A] Focus chain K [auth B] Focus chain M [auth C] Focus chain O [auth D] Focus chain Q [auth E] Focus chain S [auth F] Focus chain U [auth G] Focus chain W [auth H] Interactions & Density Focus chain I [auth A] Focus chain K [auth B] Focus chain M [auth C] Focus chain O [auth D] Focus chain Q [auth E] Focus chain S [auth F] Focus chain U [auth G] Focus chain W [auth H]

Experimental Data & Validation

Experimental Data

Method: ELECTRON MICROSCOPY
Resolution: 2.96 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

EM Software:

Task	Software Package	Version
MODEL REFINEMENT	PHENIX	1.17.1_3660
RECONSTRUCTION	cryoSPARC

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2026-07-22

Deposition Author(s):

Funding Organization	Location	Grant Number
Not funded		--

Revision History (Full details and data files)

Version 1.0: 2026-07-22
Type: Initial release
