9V5P | pdb_00009v5p

Human DNMT1 (aa 698-1616) in complex with hemimethylated dsDNA and inhibitor DMT207

• PDB DOI: https://doi.org/10.2210/pdb9V5P/pdb
• NAKB: 9V5P
• EM Map EMD-64791: EMDB EMDataResource

• Classification: TRANSFERASE
• Organism(s): Homo sapiens
• Expression System: Spodoptera frugiperda
• Mutation(s): No


• Deposited: 2025-05-26 Released: 2026-04-08
• Deposition Author(s): Li, Z.
• Funding Organization(s): National Natural Science Foundation of China (NSFC)

---

Experimental Data Snapshot

• Method: ELECTRON MICROSCOPY
• Resolution: 2.85 Å
• Aggregation State: PARTICLE
• Reconstruction Method: SINGLE PARTICLE

Literature

Discovery of a Novel DNMT1 Inhibitor with Improved Efficacy in Treating beta-Thalassemia.

Shen, Y., Wei, J., Tang, S., Wu, D., Zong, L., Ma, S., Xiong, Q., Gong, R., Xu, S., Peng, C., Feng, Q., Liu, S., Liu, Q., Ye, Y., Zhao, Q., Luo, C., Huang, P., Li, Z., Kong, X., Lan, X.

(2026) Adv Sci (Weinh) 13: e13469-e13469

• PubMed: 41347631
• DOI: https://doi.org/10.1002/advs.202513469
• Primary Citation Related Structures:
  9V5P


• PubMed Abstract:


  β-thalassemia is a recessively inherited blood disorder affecting millions worldwide. Pharmacological induction of fetal hemoglobin (HbF) is an effective therapeutic strategy, yet existing DNA methyltransferase (DNMT) inhibitors, although effective HbF inducers, currently are not approved for β-thalassemia treatment. Here, we report that DMT207, a novel non-nucleoside DNMT1 inhibitor, robustly reactivates HbF in HUDEP-2 cells and adult primary erythroblasts with minimal toxicity. In a mouse model of β-thalassemia, DMT207 effectively elevates the levels of mouse fetal- and embryonic-type hemoglobin, promotes the maturation of erythroid cells, and alleviates the splenomegaly. Further multi-omics analyses expose γ-globin as one of the most sensitive genes with promoter demethylation and transcriptional activation following DMT207 treatment. Mechanistically, DMT207 traps DNMT1 into a catalytically inactive conformation and concurrently enhances its interaction with UHRF1, which partially contributes to DNMT1 degradation. These findings highlight the therapeutic potential of DMT207 for β-thalassemia and support its further preclinical development.

---

Organizational Affiliation:
• Department of Systems Biology for Medicine, School of Basic Medical Sciences, Department of Liver Surgery and Transplantation, Liver Cancer Institute, Zhongshan Hospital, Fudan University, 130 Dong'An Road, Shanghai, 200032, China.
School of Pharmaceutical Science and Technology, Hangzhou Institute for Advanced Study, University of Chinese Academy of Sciences, No.1 Xiangshan Road, Hangzhou, 310024, China.
Institute of Drug Discovery, China-New Zealand Joint Laboratory on Biomedicine and Health, Guangdong Provincial Key Laboratory of Stem Cell and Regenerative Medicine, Guangzhou Institutes of Biomedicine and Health, Chinese Academy of Sciences, 190 Kaiyuan Avenue, Guangzhou, 510530, China.
The State Key Laboratory of Pharmaceutical Biotechnology, School of Life Sciences, Nanjing University, Nanjing, 210023, China.
GMU-GIBH Joint School of Life Sciences, The Guangdong-Hong Kong-Macao Joint Laboratory for Cell Fate Regulation and Diseases, Guangzhou Medical University, Guangzhou, 511436, China.
Department of Hepatobiliary Surgery and Transplantation, Liver Cancer Institute, Zhongshan Hospital, Institutes of Biomedical Sciences, Key Laboratory of Carcinogenesis and Cancer Invasion of Ministry of Education, Key Laboratory of Medical Epigenetics and Metabolism, Zhongshan Hospital, Fudan University, Shanghai, 200032, China.
Innovation Center for Diagnostics and Treatment of Thalassemia, Nanfang Hospital, Southern Medical University, Guangzhou, Department of Medical Genetics, School of Basic Medical Sciences, Southern Medical University, Guangzhou, Guangdong, 510515, China.
State Key Laboratory of Drug Research, Shanghai Institute of Materia Medica, Chinese Academy of Sciences, 555 Zuchongzhi Road, Shanghai, 201203, China.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors.

Biological Assembly Evidence: electron microscopy

Macromolecule Content

• Total Structure Weight: 112.27 kDa
• Atom Count: 7,015
• Modeled Residue Count: 852
• Deposited Residue Count: 943
• Unique protein chains: 1
• Unique nucleic acid chains: 2

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
DNA (cytosine-5)-methyltransferase 1	A	919	Homo sapiens	Mutation(s): 0  Gene Names: DNMT1, AIM, CXXC9, DNMT EC: 2.1.1.37
UniProt & NIH Common Fund Data Resources
Find proteins for P26358 (Homo sapiens) Explore P26358  Go to UniProtKB:  P26358
PHAROS:  P26358 GTEx:  ENSG00000130816

Entity ID: 2
Molecule	Chains	Length	Organism	Image
DNA (5'-D(*CP*CP*TP*TP*CP*CP*GP*TP*AP*AP*GP*T)-3')	B [auth E]	12	Homo sapiens

Entity ID: 3
Molecule	Chains	Length	Organism	Image
DNA (5'-D(*AP*CP*TP*TP*AP*(5CM)P*GP*GP*AP*AP*GP*G)-3')	C [auth B]	12	Homo sapiens

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
A1EQ2	G [auth E]	(2~{R})-2-[3,5-dicyano-1-[2-[2-(dimethylamino)ethyl-methyl-amino]-2-oxidanylidene-ethyl]-4-ethyl-pyrrolo[2,3-b]pyridin-6-yl]sulfanyl-2-(4-methoxyphenyl)ethanamide C27 H31 N7 O3 S YGWNLAWKHHOTHY-XMMPIXPASA-N
SAH	F [auth A]	S-ADENOSYL-L-HOMOCYSTEINE C14 H20 N6 O5 S ZJUKTBDSGOFHSH-WFMPWKQPSA-N
ZN	D [auth A], E [auth A]	ZINC ION Zn PTFCDOFLOPIGGS-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: ELECTRON MICROSCOPY
• Resolution: 2.85 Å
• Aggregation State: PARTICLE
• Reconstruction Method: SINGLE PARTICLE

EM Software:

Task	Software Package	Version
MODEL REFINEMENT	PHENIX	1.14_3260
RECONSTRUCTION	cryoSPARC

Structure Validation

Entry History

& Funding Information

Deposition Data

• Released Date: 2026-04-08
Deposition Author(s): Li, Z.

---

Funding Organization	Location	Grant Number
National Natural Science Foundation of China (NSFC)	China	82473951

Revision History

• Version 1.0: 2026-04-08
  Type: Initial release
