9URI | pdb_00009uri

apo form of polyphosphate kinase 1 (PPK1)

PDB DOI: https://doi.org/10.2210/pdb9URI/pdb
EM Map EMD-64458: EMDB EMDataResource

Classification: TRANSFERASE
Organism(s): Escherichia coli K-12
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2025-04-30 Released: 2026-03-04
Deposition Author(s): Jiang, W.J., Zhao, J., Wei, W.
Funding Organization(s): Not funded

Experimental Data Snapshot

Method: ELECTRON MICROSCOPY
Resolution: 3.09 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

Validation slider image for 9URI

This is version 1.0 of the entry. See complete history.

Literature

Structural Insights into PPK1 Catalyzed Triple Phosphoryl Transfer Underlying Polyphosphate Biosynthesis

Jiang, W.J., Zhao, J., Wei, W.

To be published.

Macromolecule Content

Total Structure Weight: 320.32 kDa
Atom Count: 20,568
Modeled Residue Count: 2,488
Deposited Residue Count: 2,736
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Polyphosphate kinase	A, B, C, D	684	Escherichia coli K-12	Mutation(s): 0 Gene Names: ppk, b2501, JW2486 EC: 2.7.4.1
UniProt
Find proteins for P0A7B1 (Escherichia coli (strain K12)) Explore P0A7B1 Go to UniProtKB: P0A7B1
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P0A7B1
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: ELECTRON MICROSCOPY
Resolution: 3.09 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2026-03-04

Deposition Author(s):

Funding Organization	Location	Grant Number
Not funded		--

Revision History (Full details and data files)

Version 1.0: 2026-03-04
Type: Initial release
