9U3H | pdb_00009u3h

Serine Beta-lactamase OXA-48 in complex with dual MBL/SBL inhibitor FB1-12

PDB DOI: https://doi.org/10.2210/pdb9U3H/pdb

Classification: HYDROLASE
Organism(s): Klebsiella pneumoniae
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2025-03-18 Released: 2026-03-25
Deposition Author(s): Li, G.-B., Liang, G.-Q.
Funding Organization(s): National Natural Science Foundation of China (NSFC)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.18 Å
R-Value Free:
0.279 (Depositor), 0.280 (DCC)
R-Value Work:
0.216 (Depositor), 0.218 (DCC)
R-Value Observed:
0.218 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 9U3H

Ligand Structure Quality Assessment

This is version 1.0 of the entry. See complete history.

Literature

Serine Beta-lactamase OXA-48 in complex with dual MBL/SBL inhibitor FB1-12

Li, G.-B., Liang, G.-Q.

To be published.

Macromolecule Content

Total Structure Weight: 113.8 kDa
Atom Count: 8,304
Modeled Residue Count: 968
Deposited Residue Count: 968
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Beta-lactamase	A, B, C, D	242	Klebsiella pneumoniae	Mutation(s): 0 Gene Names: bla, PHDFNENF_00011 EC: 3.5.2.6
UniProt
Find proteins for A0A866WQ05 (Klebsiella pneumoniae) Explore A0A866WQ05 Go to UniProtKB: A0A866WQ05
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	A0A866WQ05
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
A1ENY (Subject of Investigation/LOI) Query on A1ENY Download:Ideal Coordinates CCD File SDF format, chain H [auth D] SDF format, chain G [auth C] SDF format, chain F [auth B] SDF format, chain E [auth A] MOL2 format, chain H [auth D] MOL2 format, chain G [auth C] MOL2 format, chain F [auth B] MOL2 format, chain E [auth A] mmCIF format, chain H [auth D] mmCIF format, chain G [auth C] mmCIF format, chain F [auth B] mmCIF format, chain E [auth A]	E [auth A], F [auth B], G [auth C], H [auth D]	7-[1-[~{N}-(2-fluoranylethyl)carbamimidoyl]azetidin-3-yl]oxy-2-oxidanyl-3,4-dihydro-1,2-benzoxaborinine-8-carboxylic acid C₁₅ H₁₉ B F N₃ O₅ GBFZBMDALAIOHB-UHFFFAOYSA-N		Interactions Focus chain E [auth A] Focus chain F [auth B] Focus chain G [auth C] Focus chain H [auth D] Interactions & Density Focus chain E [auth A] Focus chain F [auth B] Focus chain G [auth C] Focus chain H [auth D]

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
KCX Query on KCX	A, B, C, D	L-PEPTIDE LINKING	C₇ H₁₄ N₂ O₄		LYS

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.18 Å
R-Value Free: 0.279 (Depositor), 0.280 (DCC)
R-Value Work: 0.216 (Depositor), 0.218 (DCC)
R-Value Observed: 0.218 (Depositor)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 105.131	α = 90
b = 58.518	β = 105.02
c = 106.135	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
SCALA	data scaling
PHASER	phasing
HKL-3000	data reduction

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2026-03-25

Deposition Author(s):

Funding Organization	Location	Grant Number
National Natural Science Foundation of China (NSFC)	China	--

Revision History (Full details and data files)

Version 1.0: 2026-03-25
Type: Initial release
