 9TJU | pdb_00009tju

Ternary complex of E. coli leucyl-tRNA synthetase bound to tRNA(leu) and Leucinol in the editing state


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.78 Å
  • R-Value Free:
    0.235 (Depositor), 0.226 (DCC)
  • R-Value Work:
    0.203 (Depositor), 0.196 (DCC)
  • R-Value Observed:
    0.205 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 9TJU

Ligand Structure Quality Assessment


This is version 1.1 of the entry. See complete history.

Literature

The ZN domain acts as a dynamic switch coordinating multiple-step aminoacylation in bacterial leucyl-tRNA synthetase.

Hoffmann, G., Dulic, M., Gruic-Sovulj, I., Palencia, A.

(2026) Nucleic Acids Res 54

  • DOI: https://doi.org/10.1093/nar/gkag786
  • Primary Citation Related Structures:
    9TJT, 9TJU, 9TJV, 9TJW

  • PubMed Abstract:

    Aminoacyl-tRNA synthetases (AARSs) safeguard translational fidelity by coordinating amino acid activation and tRNA charging within distinct catalytic and editing domains. In leucyl-tRNA synthetase (LeuRS), the small, centrally located zinc-binding domain (ZN domain) sits at the crossroads of these functional centres, yet its role has remained enigmatic. Here, we present crystal structures of the Escherichia coli LeuRS-tRNALeu complex that capture the ZN domain in a previously unobserved conformation, revealing the pre-activation state. By integrating structural data with kinetic analysis, we propose a model for the aminoacylation reaction in which the ZN domain functions as a dynamic molecular switch that coordinates the different catalytic steps of the reaction cycle. We show that the ZN domain first acts as a wedge to prime the synthetic active site while locking the 3'-end tRNALeu in the editing domain. It subsequently reorients to stabilize the tRNA acceptor stem for aminoacyl transfer, before releasing it for proofreading. These findings resolve the mechanism of long-range domain communication in LeuRS and identify a discrete, druggable intermediate for the design of next-generation antimicrobials.


  • Organizational Affiliation:
    • Institute for Advanced Biosciences (IAB), Structural Biology of Novel Targets in Human Diseases, INSERM U1209, CNRS UMR5309, University of Grenoble Alpes, 38000 Grenoble, France.

Macromolecule Content

  • Total Structure Weight: 128.23 kDa
  • Atom Count: 9,097
  • Modeled Residue Count: 900
  • Deposited Residue Count: 967
  • Unique protein chains: 1
  • Unique nucleic acid chains: 1

Macromolecules


Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Leucine--tRNA ligase880Escherichia coliMutation(s): 0
Gene Names: leuS, b0642, JW0637
EC: 6.1.1.4
UniProt
Find proteins for P07813 (Escherichia coli (strain K12))
Explore P07813
Go to UniProtKB:  P07813
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP07813
Sequence Annotations
Expand
Reference Sequence
Find similar nucleic acids by:  (by identity cutoff)
Entity ID: 2
MoleculeChains LengthOrganismImage
tRNA(leu)87Escherichia coli
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 4 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
PGE

Query on PGE



Download:Ideal Coordinates CCD File
G [auth A],
I [auth A]
TRIETHYLENE GLYCOL
C6 H14 O4
ZIBGPFATKBEMQZ-UHFFFAOYSA-N
DCL
(Subject of Investigation/LOI)

Query on DCL



Download:Ideal Coordinates CCD File
E [auth A]2-AMINO-4-METHYL-PENTAN-1-OL
C6 H15 N O
VPSSPAXIFBTOHY-LURJTMIESA-N
EDO

Query on EDO



Download:Ideal Coordinates CCD File
C [auth A],
D [auth A],
H [auth A]
1,2-ETHANEDIOL
C2 H6 O2
LYCAIKOWRPUZTN-UHFFFAOYSA-N
ACT

Query on ACT



Download:Ideal Coordinates CCD File
F [auth A]ACETATE ION
C2 H3 O2
QTBSBXVTEAMEQO-UHFFFAOYSA-M

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.78 Å
  • R-Value Free:  0.235 (Depositor), 0.226 (DCC)
  • R-Value Work:  0.203 (Depositor), 0.196 (DCC)
  • R-Value Observed: 0.205 (Depositor)
Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 76.694α = 90
b = 119.545β = 90
c = 141.639γ = 90
Software Package:
Software NamePurpose
BUSTERrefinement
autoPROCdata reduction
STARANISOdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Grenoble Instruct-ERIC Center (ISBG)France27604
iNEXT-DiscoveryEuropean Union45625
Agence Nationale de la Recherche (ANR)FranceANR-20-AMRB-0003
Agence Nationale de la Recherche (ANR)FranceANR-22-CE44-0040

Revision History  (Full details and data files)

  • Version 1.0: 2026-08-05
    Type: Initial release
  • Version 1.1: 2026-08-19
    Changes: Database references
