9T5C | pdb_00009t5c

Naked mole-rat 80S ribosome in post-translocation non-rotated state


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 2.89 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 9T5C

This is version 1.1 of the entry. See complete history

Literature

Cryo-EM structure of the naked mole-rat ribosome reveals a stabilized split 28S rRNA.

Gul, M.Rossi, A.Spahn, C.M.T.Lewin, G.R.Kudryashev, M.

(2026) Nat Commun 17

  • DOI: https://doi.org/10.1038/s41467-026-75143-0
  • Primary Citation Related Structures:
    9T5C

  • PubMed Abstract:

    The naked mole-rat (Heterocephalus glaber) is a long-lived mammal with resistance to cancer and hypoxia, suggesting the evolution of robust proteostasis networks. The ribosome, central for protein synthesis, is key to cellular stress responses and has an unusual feature: the 28S rRNA split; however, the details of its organization remain unknown. Here, we present high-resolution cryo-EM structures of the naked mole-rat 80S ribosome in four states of the elongation cycle. The structures reveal a conserved overall architecture and rRNA modification landscape compared to other mammals, and provide an atomic-level view of the distinct break in the 28S rRNA. This cleavage event, located in the D6 expansion segment, is structurally stabilized by a network of interactions with surrounding ribosomal proteins, maintaining the integrity of the large subunit. Our comparative analysis revealed that this compensatory network preserves a canonical architecture that is nearly indistinguishable from intact mouse and human ribosomes. These findings resolve the structural basis of this distinct cleavage, showing that it is a stable, integrated feature whose function is likely linked to more subtle regulatory mechanisms, rather than inducing major structural rearrangements.


  • Organizational Affiliation
    • In situ Structural Biology, Max Delbrück Center for Molecular Medicine in the Helmholtz Association (MDC), Berlin, Germany.

Macromolecule Content

  • Total Structure Weight: 3,708.32 kDa
  • Atom Count: 206,683
  • Modeled Residue Count: 16,464
  • Deposited Residue Count: 19,538
  • Unique protein chains: 73
  • Unique nucleic acid chains: 7

Macromolecules


Find similar proteins by:|  3D Structure
Entity ID: 5
MoleculeChains  Sequence LengthOrganismDetailsImage
Large ribosomal subunit protein uL2E [auth LA]257Heterocephalus glaberMutation(s): 0
UniProt
Find proteins for A0A0P6J3A4 (Heterocephalus glaber)
Explore A0A0P6J3A4
Go to UniProtKB:  A0A0P6J3A4
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A0P6J3A4
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 6
MoleculeChains  Sequence LengthOrganismDetailsImage
Large ribosomal subunit protein uL4F [auth LC]419Heterocephalus glaberMutation(s): 0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 7
MoleculeChains  Sequence LengthOrganismDetailsImage
Large ribosomal subunit protein uL18G [auth LD]297Heterocephalus glaberMutation(s): 0
UniProt
Find proteins for A0AAX6P0W2 (Heterocephalus glaber)
Explore A0AAX6P0W2
Go to UniProtKB:  A0AAX6P0W2
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0AAX6P0W2
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 8
MoleculeChains  Sequence LengthOrganismDetailsImage
Large ribosomal subunit protein eL6H [auth LE]296Heterocephalus glaberMutation(s): 0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 9
MoleculeChains  Sequence LengthOrganismDetailsImage
Large ribosomal subunit protein uL30I [auth LF]270Heterocephalus glaberMutation(s): 0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 10
MoleculeChains  Sequence LengthOrganismDetailsImage
60S ribosomal protein L7aJ [auth LG]266Heterocephalus glaberMutation(s): 0
UniProt
Find proteins for A0A0P6K8Y4 (Heterocephalus glaber)
Explore A0A0P6K8Y4
Go to UniProtKB:  A0A0P6K8Y4
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A0P6K8Y4
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 11
MoleculeChains  Sequence LengthOrganismDetailsImage
Large ribosomal subunit protein uL6K [auth LH]192Heterocephalus glaberMutation(s): 0
UniProt
Find proteins for G5C3U8 (Heterocephalus glaber)
Explore G5C3U8
Go to UniProtKB:  G5C3U8
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupG5C3U8
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 12
MoleculeChains  Sequence LengthOrganismDetailsImage
60S ribosomal protein L10L [auth LI]214Heterocephalus glaberMutation(s): 0
UniProt
Find proteins for A0AAX6QHL6 (Heterocephalus glaber)
Explore A0AAX6QHL6
Go to UniProtKB:  A0AAX6QHL6
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0AAX6QHL6
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 13
MoleculeChains  Sequence LengthOrganismDetailsImage
Large ribosomal subunit protein uL5M [auth LJ]178Heterocephalus glaberMutation(s): 0
UniProt
Find proteins for A0A0P6IWW8 (Heterocephalus glaber)
Explore A0A0P6IWW8
Go to UniProtKB:  A0A0P6IWW8
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A0P6IWW8
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 14
MoleculeChains  Sequence LengthOrganismDetailsImage
60S ribosomal protein L13N [auth LL]211Heterocephalus glaberMutation(s): 0
UniProt
Find proteins for A0AAX6P3F5 (Heterocephalus glaber)
Explore A0AAX6P3F5
Go to UniProtKB:  A0AAX6P3F5
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0AAX6P3F5
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 15
MoleculeChains  Sequence LengthOrganismDetailsImage
Large ribosomal subunit protein eL14O [auth LM]217Heterocephalus glaberMutation(s): 0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 16
MoleculeChains  Sequence LengthOrganismDetailsImage
60S ribosomal protein L15P [auth LN]204Heterocephalus glaberMutation(s): 0
UniProt
Find proteins for A0AAX6PQU7 (Heterocephalus glaber)
Explore A0AAX6PQU7
Go to UniProtKB:  A0AAX6PQU7
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0AAX6PQU7
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 17
MoleculeChains  Sequence LengthOrganismDetailsImage
60S ribosomal protein L13a isoform X1Q [auth LO]203Heterocephalus glaberMutation(s): 0
UniProt
Find proteins for A0AAX6Q4S4 (Heterocephalus glaber)
Explore A0AAX6Q4S4
Go to UniProtKB:  A0AAX6Q4S4
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0AAX6Q4S4
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 18
MoleculeChains  Sequence LengthOrganismDetailsImage
Large ribosomal subunit protein uL22R [auth LP]184Heterocephalus glaberMutation(s): 0
UniProt
Find proteins for A0A0P6JH89 (Heterocephalus glaber)
Explore A0A0P6JH89
Go to UniProtKB:  A0A0P6JH89
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A0P6JH89
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 19
MoleculeChains  Sequence LengthOrganismDetailsImage
60S ribosomal protein L18S [auth LQ]188Heterocephalus glaberMutation(s): 0
UniProt
Find proteins for G5B890 (Heterocephalus glaber)
Explore G5B890
Go to UniProtKB:  G5B890
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupG5B890
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 20
MoleculeChains  Sequence LengthOrganismDetailsImage
Ribosomal protein L19T [auth LR]196Heterocephalus glaberMutation(s): 0
UniProt
Find proteins for G5BRW3 (Heterocephalus glaber)
Explore G5BRW3
Go to UniProtKB:  G5BRW3
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupG5BRW3
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 21
MoleculeChains  Sequence LengthOrganismDetailsImage
Large ribosomal subunit protein eL20U [auth LS]176Heterocephalus glaberMutation(s): 0
UniProt
Find proteins for A0A0P6JCV6 (Heterocephalus glaber)
Explore A0A0P6JCV6
Go to UniProtKB:  A0A0P6JCV6
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A0P6JCV6
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 22
MoleculeChains  Sequence LengthOrganismDetailsImage
Large ribosomal subunit protein eL21V [auth LT]160Heterocephalus glaberMutation(s): 0
UniProt
Find proteins for G5ATV5 (Heterocephalus glaber)
Explore G5ATV5
Go to UniProtKB:  G5ATV5
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupG5ATV5
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 23
MoleculeChains  Sequence LengthOrganismDetailsImage
Large ribosomal subunit protein eL22W [auth LU]128Heterocephalus glaberMutation(s): 0
UniProt
Find proteins for A0A0N8ESF8 (Heterocephalus glaber)
Explore A0A0N8ESF8
Go to UniProtKB:  A0A0N8ESF8
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A0N8ESF8
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 24
MoleculeChains  Sequence LengthOrganismDetailsImage
60S ribosomal protein L23X [auth LV]140Heterocephalus glaberMutation(s): 0
UniProt
Find proteins for A0AAX6PVG0 (Heterocephalus glaber)
Explore A0AAX6PVG0
Go to UniProtKB:  A0AAX6PVG0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0AAX6PVG0
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 25
MoleculeChains  Sequence LengthOrganismDetailsImage
60S ribosomal protein L24Y [auth LW]157Heterocephalus glaberMutation(s): 0
UniProt
Find proteins for A0AAX6PSU9 (Heterocephalus glaber)
Explore A0AAX6PSU9
Go to UniProtKB:  A0AAX6PSU9
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0AAX6PSU9
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 26
MoleculeChains  Sequence LengthOrganismDetailsImage
Large ribosomal subunit protein uL23Z [auth LX]156Heterocephalus glaberMutation(s): 0
UniProt
Find proteins for A0AAX6PQW7 (Heterocephalus glaber)
Explore A0AAX6PQW7
Go to UniProtKB:  A0AAX6PQW7
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0AAX6PQW7
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 27
MoleculeChains  Sequence LengthOrganismDetailsImage
60S ribosomal protein L26AA [auth LY]145Heterocephalus glaberMutation(s): 0
UniProt
Find proteins for A0AAX6PRM3 (Heterocephalus glaber)
Explore A0AAX6PRM3
Go to UniProtKB:  A0AAX6PRM3
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0AAX6PRM3
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 28
MoleculeChains  Sequence LengthOrganismDetailsImage
60S ribosomal protein L27BA [auth LZ]136Heterocephalus glaberMutation(s): 0
UniProt
Find proteins for G5BN91 (Heterocephalus glaber)
Explore G5BN91
Go to UniProtKB:  G5BN91
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupG5BN91
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 29
MoleculeChains  Sequence LengthOrganismDetailsImage
60S ribosomal protein L27aCA [auth La]148Heterocephalus glaberMutation(s): 0
UniProt
Find proteins for A0AAX6PG51 (Heterocephalus glaber)
Explore A0AAX6PG51
Go to UniProtKB:  A0AAX6PG51
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0AAX6PG51
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 30
MoleculeChains  Sequence LengthOrganismDetailsImage
Large ribosomal subunit protein eL29DA [auth Lb]160Heterocephalus glaberMutation(s): 0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 31
MoleculeChains  Sequence LengthOrganismDetailsImage
Large ribosomal subunit protein eL30EA [auth Lc]115Heterocephalus glaberMutation(s): 0
UniProt
Find proteins for G5BJ16 (Heterocephalus glaber)
Explore G5BJ16
Go to UniProtKB:  G5BJ16
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupG5BJ16
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 32
MoleculeChains  Sequence LengthOrganismDetailsImage
Large ribosomal subunit protein eL31FA [auth Ld]125Heterocephalus glaberMutation(s): 0
UniProt
Find proteins for A0A0N8ESF6 (Heterocephalus glaber)
Explore A0A0N8ESF6
Go to UniProtKB:  A0A0N8ESF6
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A0N8ESF6
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 33
MoleculeChains  Sequence LengthOrganismDetailsImage
60S ribosomal protein L32GA [auth Le]135Heterocephalus glaberMutation(s): 0
UniProt
Find proteins for A0AAX6QD41 (Heterocephalus glaber)
Explore A0AAX6QD41
Go to UniProtKB:  A0AAX6QD41
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0AAX6QD41
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 34
MoleculeChains  Sequence LengthOrganismDetailsImage
Large ribosomal subunit protein eL33HA [auth Lf]110Heterocephalus glaberMutation(s): 0
UniProt
Find proteins for A0A0P6J939 (Heterocephalus glaber)
Explore A0A0P6J939
Go to UniProtKB:  A0A0P6J939
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A0P6J939
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 35
MoleculeChains  Sequence LengthOrganismDetailsImage
60S ribosomal protein L34IA [auth Lg]117Heterocephalus glaberMutation(s): 0
UniProt
Find proteins for A0AAX6Q439 (Heterocephalus glaber)
Explore A0AAX6Q439
Go to UniProtKB:  A0AAX6Q439
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0AAX6Q439
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 36
MoleculeChains  Sequence LengthOrganismDetailsImage
Large ribosomal subunit protein uL29JA [auth Lh]123Heterocephalus glaberMutation(s): 0
UniProt
Find proteins for A0AAX6PDT5 (Heterocephalus glaber)
Explore A0AAX6PDT5
Go to UniProtKB:  A0AAX6PDT5
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0AAX6PDT5
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 37
MoleculeChains  Sequence LengthOrganismDetailsImage
60S ribosomal protein L36KA [auth Li]105Heterocephalus glaberMutation(s): 0
UniProt
Find proteins for A0AAX6Q2T6 (Heterocephalus glaber)
Explore A0AAX6Q2T6
Go to UniProtKB:  A0AAX6Q2T6
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0AAX6Q2T6
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 38
MoleculeChains  Sequence LengthOrganismDetailsImage
Ribosomal protein L37LA [auth Lj]97Heterocephalus glaberMutation(s): 0
UniProt
Find proteins for A0A0P6JT91 (Heterocephalus glaber)
Explore A0A0P6JT91
Go to UniProtKB:  A0A0P6JT91
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A0P6JT91
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 39
MoleculeChains  Sequence LengthOrganismDetailsImage
Large ribosomal subunit protein eL38MA [auth Lk]70Heterocephalus glaberMutation(s): 0
UniProt
Find proteins for A0A0P6IYP5 (Heterocephalus glaber)
Explore A0A0P6IYP5
Go to UniProtKB:  A0A0P6IYP5
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A0P6IYP5
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 40
MoleculeChains  Sequence LengthOrganismDetailsImage
Large ribosomal subunit protein eL39NA [auth Ll]51Heterocephalus glaberMutation(s): 0
UniProt
Find proteins for A0AAX6NYH3 (Heterocephalus glaber)
Explore A0AAX6NYH3
Go to UniProtKB:  A0AAX6NYH3
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0AAX6NYH3
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 41
MoleculeChains  Sequence LengthOrganismDetailsImage
Ubiquitin-ribosomal protein eL40 fusion proteinOA [auth Lm]128Heterocephalus glaberMutation(s): 0
UniProt
Find proteins for G5C5A6 (Heterocephalus glaber)
Explore G5C5A6
Go to UniProtKB:  G5C5A6
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupG5C5A6
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:  Sequence   |   3D Structure
Entity ID: 42
MoleculeChains  Sequence LengthOrganismDetailsImage
60S ribosomal protein L41PA [auth Ln]25Heterocephalus glaberMutation(s): 0
UniProt
Find proteins for A0A0P6J950 (Heterocephalus glaber)
Explore A0A0P6J950
Go to UniProtKB:  A0A0P6J950
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A0P6J950
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 43
MoleculeChains  Sequence LengthOrganismDetailsImage
60S ribosomal protein L36aQA [auth Lo]106Heterocephalus glaberMutation(s): 0
UniProt
Find proteins for G5BW65 (Heterocephalus glaber)
Explore G5BW65
Go to UniProtKB:  G5BW65
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupG5BW65
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 44
MoleculeChains  Sequence LengthOrganismDetailsImage
60S ribosomal protein L37aRA [auth Lp]92Heterocephalus glaberMutation(s): 0
UniProt
Find proteins for A0AAX6NNU1 (Heterocephalus glaber)
Explore A0AAX6NNU1
Go to UniProtKB:  A0AAX6NNU1
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0AAX6NNU1
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 45
MoleculeChains  Sequence LengthOrganismDetailsImage
Large ribosomal subunit protein eL28SA [auth Lr]137Heterocephalus glaberMutation(s): 0
UniProt
Find proteins for G5BVZ2 (Heterocephalus glaber)
Explore G5BVZ2
Go to UniProtKB:  G5BVZ2
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupG5BVZ2
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 49
MoleculeChains  Sequence LengthOrganismDetailsImage
Small ribosomal subunit protein uS2WA [auth SA]295Heterocephalus glaberMutation(s): 0
UniProt
Find proteins for A0A0P6K1L6 (Heterocephalus glaber)
Explore A0A0P6K1L6
Go to UniProtKB:  A0A0P6K1L6
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A0P6K1L6
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 50
MoleculeChains  Sequence LengthOrganismDetailsImage
Small ribosomal subunit protein eS1XA [auth SB]264Heterocephalus glaberMutation(s): 0
UniProt
Find proteins for G5C1K3 (Heterocephalus glaber)
Explore G5C1K3
Go to UniProtKB:  G5C1K3
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupG5C1K3
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 51
MoleculeChains  Sequence LengthOrganismDetailsImage
Small ribosomal subunit protein uS5YA [auth SC]293Heterocephalus glaberMutation(s): 0
UniProt
Find proteins for A0AAX6QEX7 (Heterocephalus glaber)
Explore A0AAX6QEX7
Go to UniProtKB:  A0AAX6QEX7
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0AAX6QEX7
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 52
MoleculeChains  Sequence LengthOrganismDetailsImage
Small ribosomal subunit protein uS3ZA [auth SD]243Heterocephalus glaberMutation(s): 0
EC: 4.2.99.18
UniProt
Find proteins for G5AS76 (Heterocephalus glaber)
Explore G5AS76
Go to UniProtKB:  G5AS76
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupG5AS76
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 53
MoleculeChains  Sequence LengthOrganismDetailsImage
40S ribosomal protein S4AB [auth SE]263Heterocephalus glaberMutation(s): 0
UniProt
Find proteins for A0A0P6JF61 (Heterocephalus glaber)
Explore A0A0P6JF61
Go to UniProtKB:  A0A0P6JF61
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A0P6JF61
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 54
MoleculeChains  Sequence LengthOrganismDetailsImage
Small ribosomal subunit protein uS7BB [auth SF]204Heterocephalus glaberMutation(s): 0
UniProt
Find proteins for G5B7K7 (Heterocephalus glaber)
Explore G5B7K7
Go to UniProtKB:  G5B7K7
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupG5B7K7
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 55
MoleculeChains  Sequence LengthOrganismDetailsImage
40S ribosomal protein S6CB [auth SG]249Heterocephalus glaberMutation(s): 0
UniProt
Find proteins for A0A0P6J125 (Heterocephalus glaber)
Explore A0A0P6J125
Go to UniProtKB:  A0A0P6J125
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A0P6J125
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 56
MoleculeChains  Sequence LengthOrganismDetailsImage
40S ribosomal protein S7DB [auth SH]194Heterocephalus glaberMutation(s): 0
EC: 3.6.5.3
UniProt
Find proteins for A0AAX6NNW6 (Heterocephalus glaber)
Explore A0AAX6NNW6
Go to UniProtKB:  A0AAX6NNW6
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0AAX6NNW6
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 57
MoleculeChains  Sequence LengthOrganismDetailsImage
40S ribosomal protein S8EB [auth SI]208Heterocephalus glaberMutation(s): 0
UniProt
Find proteins for G5ARV4 (Heterocephalus glaber)
Explore G5ARV4
Go to UniProtKB:  G5ARV4
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupG5ARV4
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 58
MoleculeChains  Sequence LengthOrganismDetailsImage
40S ribosomal protein S9FB [auth SJ]194Heterocephalus glaberMutation(s): 0
UniProt
Find proteins for A0AAX6Q606 (Heterocephalus glaber)
Explore A0AAX6Q606
Go to UniProtKB:  A0AAX6Q606
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0AAX6Q606
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 59
MoleculeChains  Sequence LengthOrganismDetailsImage
Small ribosomal subunit protein eS10GB [auth SK]165Heterocephalus glaberMutation(s): 0
UniProt
Find proteins for A0A0P6IZJ7 (Heterocephalus glaber)
Explore A0A0P6IZJ7
Go to UniProtKB:  A0A0P6IZJ7
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A0P6IZJ7
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 60
MoleculeChains  Sequence LengthOrganismDetailsImage
Small ribosomal subunit protein uS17HB [auth SL]158Heterocephalus glaberMutation(s): 0
UniProt
Find proteins for A0A0P6J0Q6 (Heterocephalus glaber)
Explore A0A0P6J0Q6
Go to UniProtKB:  A0A0P6J0Q6
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A0P6J0Q6
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 61
MoleculeChains  Sequence LengthOrganismDetailsImage
40S ribosomal protein S13IB [auth SN]151Heterocephalus glaberMutation(s): 0
UniProt
Find proteins for A0AAX6PGK5 (Heterocephalus glaber)
Explore A0AAX6PGK5
Go to UniProtKB:  A0AAX6PGK5
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0AAX6PGK5
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 62
MoleculeChains  Sequence LengthOrganismDetailsImage
Small ribosomal subunit protein uS11JB [auth SO]151Heterocephalus glaberMutation(s): 0
UniProt
Find proteins for A0A0N8ESF7 (Heterocephalus glaber)
Explore A0A0N8ESF7
Go to UniProtKB:  A0A0N8ESF7
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A0N8ESF7
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 63
MoleculeChains  Sequence LengthOrganismDetailsImage
40S ribosomal protein S15KB [auth SP]145Heterocephalus glaberMutation(s): 0
UniProt
Find proteins for A0AAX6Q6L0 (Heterocephalus glaber)
Explore A0AAX6Q6L0
Go to UniProtKB:  A0AAX6Q6L0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0AAX6Q6L0
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 64
MoleculeChains  Sequence LengthOrganismDetailsImage
40S ribosomal protein S16LB [auth SQ]146Heterocephalus glaberMutation(s): 0
UniProt
Find proteins for A0AAX6PUA9 (Heterocephalus glaber)
Explore A0AAX6PUA9
Go to UniProtKB:  A0AAX6PUA9
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0AAX6PUA9
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 65
MoleculeChains  Sequence LengthOrganismDetailsImage
40S ribosomal protein S17MB [auth SR]135Heterocephalus glaberMutation(s): 0
UniProt
Find proteins for A0AAX6PIW5 (Heterocephalus glaber)
Explore A0AAX6PIW5
Go to UniProtKB:  A0AAX6PIW5
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0AAX6PIW5
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 66
MoleculeChains  Sequence LengthOrganismDetailsImage
40S ribosomal protein S18NB [auth SS]152Heterocephalus glaberMutation(s): 0
UniProt
Find proteins for A0AAX6PA22 (Heterocephalus glaber)
Explore A0AAX6PA22
Go to UniProtKB:  A0AAX6PA22
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0AAX6PA22
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 67
MoleculeChains  Sequence LengthOrganismDetailsImage
40S ribosomal protein S19OB [auth ST]145Heterocephalus glaberMutation(s): 0
UniProt
Find proteins for A0AAX6QEV3 (Heterocephalus glaber)
Explore A0AAX6QEV3
Go to UniProtKB:  A0AAX6QEV3
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0AAX6QEV3
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 68
MoleculeChains  Sequence LengthOrganismDetailsImage
40S ribosomal protein S20PB [auth SU]119Heterocephalus glaberMutation(s): 0
UniProt
Find proteins for A0AAX6QEN2 (Heterocephalus glaber)
Explore A0AAX6QEN2
Go to UniProtKB:  A0AAX6QEN2
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0AAX6QEN2
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 69
MoleculeChains  Sequence LengthOrganismDetailsImage
40S ribosomal protein S21QB [auth SV]83Heterocephalus glaberMutation(s): 0
UniProt
Find proteins for G5C8F1 (Heterocephalus glaber)
Explore G5C8F1
Go to UniProtKB:  G5C8F1
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupG5C8F1
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 70
MoleculeChains  Sequence LengthOrganismDetailsImage
40S ribosomal protein S15a isoform X1RB [auth SW]130Heterocephalus glaberMutation(s): 0
UniProt
Find proteins for A0AAX6PNI7 (Heterocephalus glaber)
Explore A0AAX6PNI7
Go to UniProtKB:  A0AAX6PNI7
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0AAX6PNI7
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 71
MoleculeChains  Sequence LengthOrganismDetailsImage
40S ribosomal protein S23SB [auth SX]143Heterocephalus glaberMutation(s): 0
UniProt
Find proteins for A0AAX6P1S3 (Heterocephalus glaber)
Explore A0AAX6P1S3
Go to UniProtKB:  A0AAX6P1S3
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0AAX6P1S3
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 72
MoleculeChains  Sequence LengthOrganismDetailsImage
40S ribosomal protein S24TB [auth SY]133Heterocephalus glaberMutation(s): 0
UniProt
Find proteins for A0AAX6PA11 (Heterocephalus glaber)
Explore A0AAX6PA11
Go to UniProtKB:  A0AAX6PA11
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0AAX6PA11
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 73
MoleculeChains  Sequence LengthOrganismDetailsImage
40S ribosomal protein S25UB [auth SZ]125Heterocephalus glaberMutation(s): 0
UniProt
Find proteins for A0AAX6PPX8 (Heterocephalus glaber)
Explore A0AAX6PPX8
Go to UniProtKB:  A0AAX6PPX8
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0AAX6PPX8
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 74
MoleculeChains  Sequence LengthOrganismDetailsImage
40S ribosomal protein S26VB [auth Sa]115Heterocephalus glaberMutation(s): 0
UniProt
Find proteins for A0AAX6NNU4 (Heterocephalus glaber)
Explore A0AAX6NNU4
Go to UniProtKB:  A0AAX6NNU4
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0AAX6NNU4
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 75
MoleculeChains  Sequence LengthOrganismDetailsImage
40S ribosomal protein S27WB [auth Sb]84Heterocephalus glaberMutation(s): 0
UniProt
Find proteins for A0AAX6NNV5 (Heterocephalus glaber)
Explore A0AAX6NNV5
Go to UniProtKB:  A0AAX6NNV5
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0AAX6NNV5
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 76
MoleculeChains  Sequence LengthOrganismDetailsImage
Small ribosomal subunit protein eS28XB [auth Sc]69Heterocephalus glaberMutation(s): 0
UniProt
Find proteins for G5B4M2 (Heterocephalus glaber)
Explore G5B4M2
Go to UniProtKB:  G5B4M2
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupG5B4M2
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 77
MoleculeChains  Sequence LengthOrganismDetailsImage
40S ribosomal protein S29YB [auth Sd]56Heterocephalus glaberMutation(s): 0
UniProt
Find proteins for A0AAX6NS13 (Heterocephalus glaber)
Explore A0AAX6NS13
Go to UniProtKB:  A0AAX6NS13
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0AAX6NS13
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 78
MoleculeChains  Sequence LengthOrganismDetailsImage
Ubiquitin-like protein fubi and ribosomal protein S30ZB [auth Se]133Heterocephalus glaberMutation(s): 0
UniProt
Find proteins for A0AAX6PHM7 (Heterocephalus glaber)
Explore A0AAX6PHM7
Go to UniProtKB:  A0AAX6PHM7
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0AAX6PHM7
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 79
MoleculeChains  Sequence LengthOrganismDetailsImage
Small ribosomal subunit protein RACK1AC [auth Sg]317Heterocephalus glaberMutation(s): 0
UniProt
Find proteins for A0A0P6J231 (Heterocephalus glaber)
Explore A0A0P6J231
Go to UniProtKB:  A0A0P6J231
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A0P6J231
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 80
MoleculeChains  Sequence LengthOrganismDetailsImage
Large ribosomal subunit protein uL3BC [auth LB]403Heterocephalus glaberMutation(s): 0
UniProt
Find proteins for A0A0P6IYN5 (Heterocephalus glaber)
Explore A0A0P6IYN5
Go to UniProtKB:  A0A0P6IYN5
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A0P6IYN5
Sequence Annotations
Expand
Reference Sequence
Find similar nucleic acids by:  Sequence
Entity ID: 1
MoleculeChains LengthOrganismImage
mRNAA [auth B]10Heterocephalus glaber
Sequence Annotations
Expand
Reference Sequence
Find similar nucleic acids by:  (by identity cutoff)
Entity ID: 2
MoleculeChains LengthOrganismImage
28S ribosomal RNAB [auth L5]4,731Heterocephalus glaber
Sequence Annotations
Expand
Reference Sequence
Find similar nucleic acids by:  (by identity cutoff)
Entity ID: 3
MoleculeChains LengthOrganismImage
5S ribosomal RNAC [auth L7]120Heterocephalus glaber
Sequence Annotations
Expand
Reference Sequence
Find similar nucleic acids by:  (by identity cutoff)
Entity ID: 4
MoleculeChains LengthOrganismImage
5.8S ribosomal RNAD [auth L8]158Heterocephalus glaber
Sequence Annotations
Expand
Reference Sequence
Find similar nucleic acids by:  (by identity cutoff)
Entity ID: 46
MoleculeChains LengthOrganismImage
18S ribosomal RNATA [auth S2]1,870Heterocephalus glaber
Sequence Annotations
Expand
Reference Sequence
Find similar nucleic acids by:  (by identity cutoff)
Entity ID: 47
MoleculeChains LengthOrganismImage
tRNAUA [auth S6]75Heterocephalus glaber
Sequence Annotations
Expand
Reference Sequence
Find similar nucleic acids by:  (by identity cutoff)
Entity ID: 48
MoleculeChains LengthOrganismImage
tRNAVA [auth S7]75Heterocephalus glaber
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
ZN

Query on ZN



Download:Ideal Coordinates CCD File
IL [auth Lg],
JL [auth Lp],
TO [auth Sa]
ZINC ION
Zn
PTFCDOFLOPIGGS-UHFFFAOYSA-N
MG

Query on MG



Download:Ideal Coordinates CCD File
AD [auth L5]
AE [auth L5]
AF [auth L5]
AG [auth L5]
AH [auth L5]
AD [auth L5],
AE [auth L5],
AF [auth L5],
AG [auth L5],
AH [auth L5],
AI [auth L5],
AJ [auth L5],
AK [auth L5],
AL [auth L8],
AM [auth S2],
AN [auth S2],
AO [auth S2],
BD [auth L5],
BE [auth L5],
BF [auth L5],
BG [auth L5],
BH [auth L5],
BI [auth L5],
BJ [auth L5],
BK [auth L5],
BL [auth L8],
BM [auth S2],
BN [auth S2],
BO [auth S2],
CC [auth B],
CD [auth L5],
CE [auth L5],
CF [auth L5],
CG [auth L5],
CH [auth L5],
CI [auth L5],
CJ [auth L5],
CK [auth L5],
CL [auth LI],
CM [auth S2],
CN [auth S2],
CO [auth S2],
DC [auth L5],
DD [auth L5],
DE [auth L5],
DF [auth L5],
DG [auth L5],
DH [auth L5],
DI [auth L5],
DJ [auth L5],
DK [auth L5],
DL [auth LN],
DM [auth S2],
DN [auth S2],
DO [auth S2],
EC [auth L5],
ED [auth L5],
EE [auth L5],
EF [auth L5],
EG [auth L5],
EH [auth L5],
EI [auth L5],
EJ [auth L5],
EK [auth L5],
EL [auth LP],
EM [auth S2],
EN [auth S2],
EO [auth S2],
FC [auth L5],
FD [auth L5],
FE [auth L5],
FF [auth L5],
FG [auth L5],
FH [auth L5],
FI [auth L5],
FJ [auth L5],
FK [auth L5],
FL [auth Le],
FM [auth S2],
FN [auth S2],
FO [auth S2],
GC [auth L5],
GD [auth L5],
GE [auth L5],
GF [auth L5],
GG [auth L5],
GH [auth L5],
GI [auth L5],
GJ [auth L5],
GK [auth L5],
GL [auth Le],
GM [auth S2],
GN [auth S2],
GO [auth S2],
HC [auth L5],
HD [auth L5],
HE [auth L5],
HF [auth L5],
HG [auth L5],
HH [auth L5],
HI [auth L5],
HJ [auth L5],
HK [auth L5],
HL [auth Lg],
HM [auth S2],
HN [auth S2],
HO [auth S2],
IC [auth L5],
ID [auth L5],
IE [auth L5],
IF [auth L5],
IG [auth L5],
IH [auth L5],
II [auth L5],
IJ [auth L5],
IK [auth L5],
IM [auth S2],
IN [auth S2],
IO [auth S2],
JC [auth L5],
JD [auth L5],
JE [auth L5],
JF [auth L5],
JG [auth L5],
JH [auth L5],
JI [auth L5],
JJ [auth L5],
JK [auth L5],
JM [auth S2],
JN [auth S2],
JO [auth S2],
KC [auth L5],
KD [auth L5],
KE [auth L5],
KF [auth L5],
KG [auth L5],
KH [auth L5],
KI [auth L5],
KJ [auth L5],
KK [auth L5],
KL [auth S2],
KM [auth S2],
KN [auth S2],
KO [auth S2],
LC [auth L5],
LD [auth L5],
LE [auth L5],
LF [auth L5],
LG [auth L5],
LH [auth L5],
LI [auth L5],
LJ [auth L5],
LK [auth L5],
LL [auth S2],
LM [auth S2],
LN [auth S2],
LO [auth S2],
MC [auth L5],
MD [auth L5],
ME [auth L5],
MF [auth L5],
MG [auth L5],
MH [auth L5],
MI [auth L5],
MJ [auth L5],
MK [auth L5],
ML [auth S2],
MM [auth S2],
MN [auth S2],
MO [auth S2],
NC [auth L5],
ND [auth L5],
NE [auth L5],
NF [auth L5],
NG [auth L5],
NH [auth L5],
NI [auth L5],
NJ [auth L5],
NK [auth L5],
NL [auth S2],
NM [auth S2],
NN [auth S2],
NO [auth S2],
OC [auth L5],
OD [auth L5],
OE [auth L5],
OF [auth L5],
OG [auth L5],
OH [auth L5],
OI [auth L5],
OJ [auth L5],
OK [auth L5],
OL [auth S2],
OM [auth S2],
ON [auth S2],
OO [auth S2],
PC [auth L5],
PD [auth L5],
PE [auth L5],
PF [auth L5],
PG [auth L5],
PH [auth L5],
PI [auth L5],
PJ [auth L5],
PK [auth L5],
PL [auth S2],
PM [auth S2],
PN [auth S2],
PO [auth S2],
QC [auth L5],
QD [auth L5],
QE [auth L5],
QF [auth L5],
QG [auth L5],
QH [auth L5],
QI [auth L5],
QJ [auth L5],
QK [auth L5],
QL [auth S2],
QM [auth S2],
QN [auth S2],
QO [auth S2],
RC [auth L5],
RD [auth L5],
RE [auth L5],
RF [auth L5],
RG [auth L5],
RH [auth L5],
RI [auth L5],
RJ [auth L5],
RK [auth L5],
RL [auth S2],
RM [auth S2],
RN [auth S2],
RO [auth S2],
SC [auth L5],
SD [auth L5],
SE [auth L5],
SF [auth L5],
SG [auth L5],
SH [auth L5],
SI [auth L5],
SJ [auth L5],
SK [auth L5],
SL [auth S2],
SM [auth S2],
SN [auth S2],
SO,
TC [auth L5],
TD [auth L5],
TE [auth L5],
TF [auth L5],
TG [auth L5],
TH [auth L5],
TI [auth L5],
TJ [auth L5],
TK [auth L5],
TL [auth S2],
TM [auth S2],
TN [auth S2],
UC [auth L5],
UD [auth L5],
UE [auth L5],
UF [auth L5],
UG [auth L5],
UH [auth L5],
UI [auth L5],
UJ [auth L5],
UK [auth L5],
UL [auth S2],
UM [auth S2],
UN [auth S2],
UO [auth LB],
VC [auth L5],
VD [auth L5],
VE [auth L5],
VF [auth L5],
VG [auth L5],
VH [auth L5],
VI [auth L5],
VJ [auth L5],
VK [auth L7],
VL [auth S2],
VM [auth S2],
VN [auth S2],
WC [auth L5],
WD [auth L5],
WE [auth L5],
WF [auth L5],
WG [auth L5],
WH [auth L5],
WI [auth L5],
WJ [auth L5],
WK [auth L7],
WL [auth S2],
WM [auth S2],
WN [auth S2],
XC [auth L5],
XD [auth L5],
XE [auth L5],
XF [auth L5],
XG [auth L5],
XH [auth L5],
XI [auth L5],
XJ [auth L5],
XK [auth L7],
XL [auth S2],
XM [auth S2],
XN [auth S2],
YC [auth L5],
YD [auth L5],
YE [auth L5],
YF [auth L5],
YG [auth L5],
YH [auth L5],
YI [auth L5],
YJ [auth L5],
YK [auth L7],
YL [auth S2],
YM [auth S2],
YN [auth S2],
ZC [auth L5],
ZD [auth L5],
ZE [auth L5],
ZF [auth L5],
ZG [auth L5],
ZH [auth L5],
ZI [auth L5],
ZJ [auth L5],
ZK [auth L8],
ZL [auth S2],
ZM [auth S2],
ZN [auth S2]
MAGNESIUM ION
Mg
JLVVSXFLKOJNIY-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 2.89 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE
EM Software:
TaskSoftware PackageVersion
RECONSTRUCTIONcryoSPARC
MODEL REFINEMENTPHENIX1.21.2_5419

Structure Validation

View Full Validation Report



Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
German Research Foundation (DFG)GermanyKU3222/3-1

Revision History  (Full details and data files)

  • Version 1.0: 2026-06-17
    Type: Initial release
  • Version 1.1: 2026-07-15
    Changes: Database references, Source and taxonomy, Structure summary
