9SA3 | pdb_00009sa3

Human Apolipoprotein E4 (ApoE4) N-terminal domain (space group P212121)

PDB DOI: https://doi.org/10.2210/pdb9SA3/pdb

Classification: LIPID TRANSPORT
Organism(s): Homo sapiens
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2025-08-07 Released: 2026-08-19
Deposition Author(s): Marek, M., Snajdarova, K.
Funding Organization(s): Czech Science Foundation

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.19 Å
R-Value Free:
0.270 (Depositor), 0.271 (DCC)
R-Value Work:
0.214 (Depositor), 0.216 (DCC)
R-Value Observed:
0.217 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 9SA3

This is version 1.0 of the entry. See complete history.

Literature

Human Apolipoprotein E4 (ApoE4) N-terminal domain

Marek, M., Snajdarova, K.

To be published.

Macromolecule Content

Total Structure Weight: 23.71 kDa
Atom Count: 1,219
Modeled Residue Count: 143
Deposited Residue Count: 207
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Apolipoprotein E	A	207	Homo sapiens	Mutation(s): 0 Gene Names: APOE
UniProt & NIH Common Fund Data Resources
Find proteins for P02649 (Homo sapiens) Explore P02649 Go to UniProtKB: P02649
GTEx: ENSG00000130203
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P02649
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.19 Å
R-Value Free: 0.270 (Depositor), 0.271 (DCC)
R-Value Work: 0.214 (Depositor), 0.216 (DCC)
R-Value Observed: 0.217 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 45.412	α = 90
b = 52.923	β = 90
c = 73.758	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
Aimless	data scaling
XDS	data reduction
PHASER	phasing
PDB_EXTRACT	data extraction

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2026-08-19

Deposition Author(s):

Funding Organization	Location	Grant Number
Czech Science Foundation	Czech Republic	GX25-17329X

Revision History (Full details and data files)

Version 1.0: 2026-08-19
Type: Initial release
