9S7Z | pdb_00009s7z

Structure of truncated human 60 kDa lysophospholipase at 2.73 A resolution

PDB DOI: https://doi.org/10.2210/pdb9S7Z/pdb

Classification: HYDROLASE
Organism(s): Homo sapiens
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2025-08-05 Released: 2026-08-19
Deposition Author(s): Rabe von Pappenheim, F., Eulig, N., Mahler, M., Tittmann, K.
Funding Organization(s): Not funded

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.73 Å
R-Value Free:
0.305 (Depositor), 0.302 (DCC)
R-Value Work:
0.262 (Depositor), 0.260 (DCC)
R-Value Observed:
0.264 (Depositor)

Starting Model: in silico
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 9S7Z

This is version 1.0 of the entry. See complete history.

Literature

Structure of the truncated human 60 kDa lysophospholipase at 2.73 A resolution

Rabe von Pappenheim, F., Eulig, N., Mahler, M., Tittmann, K.

To be published.

Macromolecule Content

Total Structure Weight: 239.91 kDa
Atom Count: 15,404
Modeled Residue Count: 2,013
Deposited Residue Count: 2,208
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
60 kDa lysophospholipase	A B [auth E] C [auth F] D E [auth C] A, B [auth E], C [auth F], D, E [auth C], F [auth B]	368	Homo sapiens	Mutation(s): 0 Gene Names: ASPG, C14orf76 EC: 3.1.1.5 (PDB Primary Data), 3.5.1.1 (PDB Primary Data), 3.1.1.47 (PDB Primary Data)
UniProt & NIH Common Fund Data Resources
Find proteins for Q86U10 (Homo sapiens) Explore Q86U10 Go to UniProtKB: Q86U10
GTEx: ENSG00000166183
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q86U10
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.73 Å
R-Value Free: 0.305 (Depositor), 0.302 (DCC)
R-Value Work: 0.262 (Depositor), 0.260 (DCC)
R-Value Observed: 0.264 (Depositor)

Space Group: C 2 2 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 131.149	α = 90
b = 240.214	β = 90
c = 184.992	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
XDS	data reduction
XSCALE	data scaling
MOLREP	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2026-08-19

Deposition Author(s):

Rabe von Pappenheim, F.

Funding Organization	Location	Grant Number
Not funded		--

Revision History (Full details and data files)

Version 1.0: 2026-08-19
Type: Initial release
